Socket D700 Instrucciones de funcionamiento

Programming Guide

1D Imager - D700, S700, DS800, D800, and S800

Model

D700 Black

D700 Gray

D700 Red

D700 White

Model

S700 Blue

S700 Green

S700 Red

S700 White

S700 Yellow

Model

S800 Black

Model

DS800 Black

Model

D800 Black

Compatible with CHS 7Ci.

Table of Contents

Companion App 3

resets 3

Bluetooth Connection Mode 4

prefix/suffix 5

vibrate/Beep Modes 6

Active Modes 7

Presentation modes 8

HID Keyboard Language Settings 9-10

Automatic Reconnection 11

Bluetooth Connection Roles 12

Data Mode - For SPP Mode Only 13

Programming 14

1D symbologies

UPC/EAN 15-25

Code 128 26

gs1-128 26

Code 39 27-28

Convert Code 39 to Code 32 (Italian Pharma Code) 29

Code 32 Prefix 29

Code 93 30

Interleaved 2 of 5 31

Codabar 32-33

MSI 34-35

GS1 DataBar 36-37

sample barcodes 38

Companion App

Make sure the scanner is not connected to a host computer or device before scanning a com-

mand barcode.

Factory Reset

Configures the scanner to factory defaults. The scanner powers off after scanning this barcode.

Scan QR code with mobile device

to download app.

Scan QR code with mobile device

to download app.

Set up your scanner with Socket Mobile Companion App.

• Easy to follow instructions for pairing scanners

• Check scanner status

• Check warranty and register scanners

Learn more about Application Mode.

resets

Pairing Reset

If the scanner is paired with a device, unpair it before trying to connect to a different device.

Step 1: Scan barcode (for serial number that begins 1931 and above only).

Or follow steps to manually reset scanner:

A. Power on the scanner.

B. Press and hold down the scan button.

C. Press and hold down the power button.

D. After you hear 3 beeps, release both buttons.

The scanner will unpair and automatically power off.

Step 2: Remove or forget the scanner from the Bluetooth list

on the host device.

The scanner is now discoverable.

Both steps above must be done to complete the unpairing.

Bluetooth Connection Mode

Make sure the scanner is not connected to a host computer or device before scanning a com-

mand barcode.

Scan command barcode(s) to configure the scanner.

Basic Mode (HID) (default)

(All host devices)

Configures the scanner to Human Interface Device (HID) mode. The scanner will be discoverable as a

keyboard to other Bluetooth devices.

Application Mode (MFi-SPP) for Apple Devices

*Required for Apple iOS applications developed with Socket Mobile SDK.

Application Mode (Auto Connect-SPP) for Windows or Android 8.0 and later

*Congures the scanner to Serial Port Prole. Not compatible with 7Ci.

Application Mode (SPP) for Windows or Android version 7.0 and lower

*Congures the scanner to Serial Port Prole (SPP).

*For compatible applications developed with Socket Mobile SDK:

https://www.socketmobile.com/partners/app-partners

You can configure the scanner to automatically add a prefix and/or suffix to each scan of data.

Scanner is allowed 1 prefix and 2 suffixes.

For custom prefix and suffix, contact support@socketmobile.com.

Note: Scanning multiple commands in a single instance will overwrite (not append) the previous

command.

Sufx – Carriage Return (default)

Configures the scanner to add a carriage return after decoded data.

Sufx – Tab

Configures the scanner to add a tab after decoded data.

Sufx – Carriage Return and Line Feed

Configures the scanner to add a carriage return and line feed after decoded data.

Data As Is

Configures the scanner to return only the decoded data (i.e., no prefix or suffix).

Prefix/Suffix

Make sure the scanner is not connected to a host computer or device before scanning a com-

mand barcode.

Vibrate “On” (default)

Enable the scanner to vibrate to indicate a successful scan.

Vibrate “Off”

Disable the scanner from vibrating to indicate a successful scan.

Beep “On” (default)

Enable the scanner to beep to indicate a successful scan.

Beep “Off”

Disable the scanner from beeping to indicate a successful scan.

Vibrate/Beep Modes

Scan one of the barcodes to reconfigure the scanner to remain powered on for a longer time.

These settings drain the battery faster. Please ensure the scanner is charged daily.

2 hours (default)

Scanner powers off in 2 hours when idle/inactive while connected and 5 minutes when disconnected.

Continuous Power for 4 hours

Configures the scanner to remain on for 4 hours.

Continuous Power for 8 hours

Configures the scanner to remain on for 8 hours.

Scanner Always On

Configures the scanner to never power off.

Active Modes

Presentation Modes

Scan one of the barcodes to configure the scanner to automatically scan barcodes.

These settings drain the battery faster. Please ensure the scanner is charged daily.

Mobile Mode (default)

Reverts back to manual scan mode.

#FNB 41FBA50000#

Auto Mode (recommended)

Configures the scanner to switch to presentation mode when power is detected on the charg-

ing pins. The scanner will remain on presentaion mode until the scan button is pressed to exit the

mode.

#FNB 41FBA50003#

Detect Mode

Configures the scanner to switch to presentation mode when power is detected on the charging

pins. The automatic scan will continue until power is removed.

#FNB 41FBA50002#

Stand Mode

Scanner is permanently in presentation mode.

#FNB 41FBA50001#

Command barcode is for 2D barcode scanners only: D740/D750/D755/D760/S740/S760

Scan only when the scanner is in Basic Mode (HID profile).

These barcodes are to configure the scanner for different languages using Microsoft Windows key-

board layout.

English (Default)

English UK

French

German

Italian

HID Keyboard Language Settings

Japanese

Polish

Spanish

Swedish

ANSI Emulation

ANSI Emulation can be slower on Windows systems.
