Smart Start AS-2780U Manual de usuario

5-BUTTON AUTOMATIC / MANUAL TRANSMISSION

REMOTE STARTER

INDUSTRY CANADA USER NOTICE:

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2)

this device must accept any interference, including interference that may cause undesired operation of

the device.

To reduce potential radio interference to other users, the antenna type and its gain should be so chosen

that the equivalent isotropically radiated power (EIRP) is not more than that required for successful

communication.

NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized

modifications to this equipment. Such modifications could void the user's authority to operate the

equipment.

AS-2780U

User Guide

WWARNING !!

It is the responsibility of the vehicle operator to ensure that their

vehicle is parked in a safe and responsible manner.

1. a) Manual transmission:

When leaving the vehicle, it is the user’s

responsibility to ensure that the gearshift lever is in the

NEUTRAL

position and the parking brake is engaged in order to avoid accidents

upon remote starting.

b) Automatic transmission: When leaving the vehicle,

it is the user’s

responsibility to ensure that the gearshift lever is in “Park” in order to

avoid accidents upon remote starting.

(Note: Make sure that the automatic vehicle cannot start in "Drive".)

2. It is the user's responsibility to ensure that the remot

e starter is

disabled or put into valet mode before servicing.

Designed & engineered in Canada

P.2 User Guide

Table of Contents

Government regulations ..................................................................................................................3

Introduction .............................................................................................................................3

Using the Remote Control ...............................................................................................................4

Vehicle Presets .................................................................................................................................4

Heater ...........................................................................................................................................4

Windshield Wipers, Radio & Headlights.......................................................................................4

Arming and disarming the Starter Kill............................................................................................4

Remote-Starting Your Vehicle.........................................................................................................5

Setting Your Vehicle into Ready Mode.........................................................................................5

Remote-starting ............................................................................................................................6

Driving Off.....................................................................................................................................6

Remote Starter Features ..................................................................................................................7

Remote Door Locks ......................................................................................................................7

Remote Trunk Release.................................................................................................................7

Idle Mode ......................................................................................................................................7

Valet Mode....................................................................................................................................8

Panic Mode...................................................................................................................................9

Quick LockoutTM ...........................................................................................................................9

Cold Weather Mode......................................................................................................................9

Extended Run Time......................................................................................................................9

Disable/Enable LED flashing ......................................................................................................10

Constant output ..........................................................................................................................10

Advanced Features: Installation-programmable Options ..........................................................10

Ignition-controlled Door Locks ....................................................................................................10

Secure Lock................................................................................................................................10

Safe Start....................................................................................................................................11

Engine Run Time........................................................................................................................11

Turbo Mode ................................................................................................................................11

“Home ValetTM” Mode .................................................................................................................11

AUX 1 .........................................................................................................................................12

Horn Chirp Timing.......................................................................................................................12

Multi-car Operation .....................................................................................................................12

OEM-Style Alarm........................................................................................................................12

Car Finder...................................................................................................................................13

Intrusion Codes via horn.............................................................................................................13

Troubleshooting Poor Transmitting Range .................................................................................14

Parking Light Flash Table..............................................................................................................14

User guide P.3

Government regulations

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates and can radiate

radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

xReorient or relocate the receiving antenna.

xIncrease the separation between the equipment and receiver.

xConnect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

xConsult the dealer or an experienced radio/TV technician for help.

This device complies with the Industry Canada Radio Standards Specification RSS 210. Its use is

authorized only on a no-interference, no-protection basis; in other words, this device must not be

used if it is determined that it causes harmful interferences to services authorized by IC. In

addition, the user of this device must accept any radio interface that may be received, even if this

interference could affect the operation of the device.

Warning! Changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate this device.

Introduction

This is a state-of-the-art remote car starter system. The system is packed with advanced features

such as priority access to the driver’s door (commodity features), the Safe Start children safety

feature and SmartStart™.

SmartStart™ is a groundbreaking technology that enables your remote starter features to be

accessed by your smartphone. Features include keyless entry, trunk release, panic, remote

start/stop toggle and alarm notifications1. Note: SmartStart™ must be professionally installed. For

more information, see your nearest authorised Directed Canada dealer.

With many advanced functions, this product will satisfy any one of your expectations from high-end

commodity and security systems, without neglecting any standard feature commonly offered by

entry-level starters.

1Certain conditions apply. See your authorised Directed Canada dealer.

P.14 User Guide

Troubleshooting Poor Transmitting Range

Many factors may affect the operating range of the transmitter. Some of these are:

xThe condition of the battery in the transmitter.

xThe operating environment (for example: downtown radio-frequency noise, airports, cellular

phone towers…).

xMetal: any type of metal will affect operating range. This includes the vehicle itself.

xThe shape of the vehicle can affect range as well (vans in general have less range).

xThe shape of the roof and A-pillars brings about considerable radio-frequency deflection (in

this case, the signal from the remote control). As a result, the direction in which the vehicle is

facing in relation to the remote control can affect the range. Straight on (standing in front of

the vehicle) generally gives you the greatest range; the second best performance is from the

back. Using the remote control from either side of the vehicle will usually give the lowest

range.

xThe range will be significantly lower in a crowded parking lot than in open space.

xAlways hold the transmitter high, approximately at shoulder height.

xThe operating range will be somewhat lower on vehicles equipped with an aftermarket or

factory alarm.

Parking Light Flash Table

Parking lights flashes

Description

xDoors locked.

Trunk released.

Start signal received from the remote.

xRuntime has expired

2 slow

xShutdown by remote

2 fast

xDoors unlocked

xValet mode is deactivated

3 slow

xRuntime is extended.

3 fast

xValet mode activated.

4 fast

xShutdown by brake

xA remote start was attempted while the brake pedal is engaged.

10 fast

xShutdown by hood

xA remote start was attempted while the hood is open.

ON ÎÎtwice

xCold weather mode deactivated

ON ÎÎ3 times

xCold weather mode activated.

Solid ON

xEngine is running under remote start.

Flash for 30 sec.

xPanic mode is triggered.

Flash for 60 sec.

xAlarm is triggered.

ON ÎÎtwice ÎÎtwice

xA remote start was attempted while the system is in home valet.

User guide P.13

xTo disarm the OEM-style alarm, press the button on the transmitter.

-To stop the horn from sounding if the OEM-style alarm is triggered, press the or

button, or put the system in and out of Valet Mode (page-8)

Car Finder

If configured by your installer, the Car Finder option will help you locate the vehicle by sending a

pulsating signal through the horn. To hear the signal, press and hold the or button. This

will produce a pulsating signal for the time you keep the button pressed.

Intrusion Codes via horn

The system monitors the following:

xDoors

xHood

xIgnition

Note: If an intrusion has occurred the HORN will sound for a maximum of 1minute.

If an intrusion has occurred and pressed, the horn provides an intrusion code corresponding to

the type of intrusion that occurred.

1x = power interruption

4x = Doors intrusion

3x = Hood

6x = Ignition

P.4 User Guide

Using the Remote Control

Your Remote Car Starter is equipped with a 5-button multi-channel remote control. It can operate

two independent vehicles equipped with a Remote Car Starter (see Multi-Car Operation page-12,

for second-car transmitter functions).

The functions of the transmitter are as follows:

(!) AUX: Stops the engine if

pressed for less than 3 seconds

or triggers Panic mode if

pressed for more than 3

seconds.

LOCK: Locks the doors and

arms the STARTER KILL.

START: Remote starts the

engine or gets the system into

Cold Weather mode if pressed

for 3 seconds.

Note: Icon may vary.

UNLOCK: Unlocks the doors

and disarms the STARTER

KILL. Activates the AUX 1

output if priority door access is

configured.

TRUNK: Opens the

TRUNK or activates the

AUX 3 output

Note: Pressing the LOCK and UNLOCK buttons simultaneously will activate the AUX 2 output.

Vehicle Presets

Heater

When leaving the vehicle it is recommended to preset the accessory controls in preparation for the

next remote start. Settings for the blower motor (fan), front and rear, should not be left on HIGH. It

is recommended to leave the settings on LOW or MEDIUM instead.

Windshield Wipers, Radio & Headlights

Certain vehicles require the radio and / or windshield wipers and / or headlights circuits to become

energized while running under remote start. When leaving the vehicle you must ensure that the

windshield wipers and headlights switches are OFF. Leaving the headlights switch ON on certain

types of vehicles could cause them to remain ON even after remote starter shutdown, resulting in a

dead battery.

Arming and disarming the Starter Kill

This added security feature will prevent the vehicle from starting with the Ignition key when the

starter kill is armed. If the system was installed with the starter kill option, you will not be able to

start the vehicle with the key unless the system has been unlocked first or put into Valet Mode

(page-8).

User guide P.5

Note: If the Starter Kill is installed, the vehicle will benefit from a protection against starter

motor damage that could occur after remote-starting the engine should the user, by force of

habit, turn the ignition key to the CRANK position.

The Starter Kill (if installed) can be configured by the installer either to Passive Mode (so as to arm

automatically) or Active Mode (so as to require the user’s intervention for arming). By default, your

Remote Car Starter is configured to Passive Mode.

Passive mode:

To arm the Starter Kill, press the button on the transmitter, OR

1. In Passive Mode, the Starter Kill will automatically arm 1 minute (by default) or 3

minutes (if configured this way) after the ignition is turned OFF or once the last door is

closed (if the doors are monitored).

2. The LED on the antenna will flash quickly during the countdown preceding the activation

of the Starter Kill.

3. Once the activation countdown expires, the LED will send a series of quick double

flashes to indicate that the Starter Kill is now armed.

To disarm the Starter Kill, press the button on the transmitter.

xThe Starter Kill will automatically rearm itself after 1 minute (by default) or 3 minutes (if

configured this way) if no door is left opened (if the doors are monitored) and the ignition

is not turned ON.

Active Mode:

To arm the Starter Kill, press the button on the transmitter.

1. The parking lights will flash once.

2. The LED on the antenna will flash slowly.

3. If remote door locks are installed, this will also lock the doors and arm the OEM-style

alarm.

To disarm the Starter Kill, press the button on the transmitter.

1. The parking lights will flash twice.

2. The LED on the antenna will remain OFF.

3. If remote door locks are installed, this will also unlock the doors.

Remote-Starting Your Vehicle

Setting Your Vehicle into Ready Mode

If your vehicle has a manual transmission you must read the following indications. The unit must

first be set to Ready Mode in order to start the vehicle by remote. If the unit is not set to Ready

Mode, it cannot remote start the vehicle.

Please note that Ready Mode can be enabled by the remote or the handbrake, depending on the

option that was selected by your installer. Therefore, you must follow the appropriate procedure

between the two described below in order to set your vehicle into Ready Mode.

Once the system is set to Ready Mode, the vehicle can be remote started and stopped at any time.

The system will exit Ready Mode if a door, the hood or the trunk is opened, if the brake pedal is

pressed, if the parking brake is disengaged or if the ignition key is turned to the IGNITION ON

(RUN) position.

P.12 User Guide

1. Press the or button.

2. Within 3 seconds, press the and buttons simultaneously for 3 sec.

3. The P-lights will flash once

To take the system out of home valet mode:

xTurn the ignition key to the IGNITION ON (RUN) position.

The system will warn you if someone attempts to start your vehicle while it stands in home valet

mode. The parking lights will:

Turn ON then OFF; then

Flash twice, pause; then

Flash twice again.

AUX 1

Note: This 500 mA negative Aux 1 output can be used for many different applications

Priority door:

This great feature allows the user to unlock solely the driver’s door with a single press of

the button on the transmitter, and to unlock the other doors, if desired, by pressing

the button for a second time.

The output will provide a 1-second negative output when the button is pressed a

second time on the transmitter.

Horn Confirmation:

AUX 1 can be programmed to trigger the horn every time the button is pressed, or

when the button is pressed twice within 3 seconds. When horn confirmation is

activated, panic mode is enabled. If horn confirmation is disabled, panic mode will not

be available.

Horn Chirp Timing

The pulse duration can be configured by your installer (from 5 ms to 200 ms).

Multi-car Operation

This option allows the owner of two vehicles, both equipped with the same Remote Car Starter

model, to control both systems with a single remote control. To control the second vehicle,

simultaneously press the TRUNK button and the button of the function you wish to use.

Note: Your remote control must be configured for second car operation by the installer.

Press TRUNK + LOCK buttons simultaneously: ..LOCK

Press TRUNK + UNLOCK simultaneously: ..........UNLOCK

Press TRUNK + START simultaneously:..............START

Press TRUNK + STOP simultaneously: ................STOP

Press TRUNK + START simultaneously for 3 sec: Cold Weather Mode

OEM-Style Alarm

The OEM-style alarm (if configured by your installer) monitors the doors, hood and ignition switch

of your vehicle. It will sound the horn if a door or the hood is opened, or if the key is turned in the

ignition.

xTo arm the OEM-style alarm, press the button on the transmitter.

-The OEM-style alarm will ONLY arm if the button on the transmitter is pressed.

-The LED on the antenna will flash slowly to indicate that the OEM-style alarm is now armed.

User guide P.11

Safe Start

xSafe start enabled: If this feature is enabled, the user must press the button

twice within 3 seconds to remote-start the vehicle. This will eliminate accidental

remote starts, e.g. when children are playing with the transmitter.

xSwap start: If this feature is enabled, press and simultaneously to remote

start the vehicle. The AUX 2 output can be activated by pressing the button.

Engine Run Time

On a gas engine, the Remote Car Starter can be programmed to run the engine for 3, 15, or

25 minutes (15 minutes by default). On a diesel engine, the Remote Car Starter can be

programmed to run the engine for 8, 20, or 30 minutes (20 minutes by default).

Turbo Mode

If Turbo Mode is configured at installation, it will allow a turbocharger to idle down after the user

leaves the vehicle: the unit will take over the vehicle and keep it running for 60 seconds (or until it

is shut down by remote control), then shut down the engine.

If your vehicle has an automatic transmission, proceed as follows to set the system to Turbo

Mode:

1. With the engine running, make sure to release the brake pedal and press the ,

or button on the transmitter until the parking lights come ON.

Note: SmartStart™ can be setup to use the icon to activate Idle mode.

2. Remove the ignition key from the ignition switch.

The engine will continue running.

3. Exit the vehicle and close all doors, hood and trunk.

4. Press the button; this will lock the doors, arm the OEM-style alarm (if

configured|) and confirm that the vehicle is in Turbo Mode.

5. The engine will shut down after 60 seconds.

If your vehicle has a manual transmission, follow all steps of the Ready Mode routine (page-5) to

activate Turbo Mode. At the last step, press either:

xto lock the doors and have the engine shut down after 60 seconds;

The parking lights will flash 3 times and remain lit.

The OEM-style alarm and starter kill (if configured) will be armed.

xto unlock the doors and have the engine shut down after 60 seconds;

The parking lights will flash 3 times and remain lit.

xto shut down the engine without affecting the doors.

Note: The vehicle will enter Ready Mode once the engine run time expires.

“Home ValetTM” Mode

If configured at installation, this feature will remotely set the vehicle to a no-remote-start mode: if

the vehicle is parked indoors there is no danger of it starting accidentally by remote control. If the

vehicle has a manual transmission, it should be set into ready mode before activating the Home

Valet™.

Note: Once the Home Valet Mode is activated, the vehicle will not start by remote, but the

OEM alarm functions will remain active.

To take the system into home valet mode:

P.6 User Guide

To set the system to Ready Mode:

If Ready Mode is enabled by remote

If Ready Mode is enabled by handbrake

1. Ensure that all the doors, hood and trunk are closed. Make sure that the gear selector is in the neutral

position.

2. With the engine already running, apply the parking

brake once and release the brake pedal.

3. Within 20

sec. of engaging the parking brake,

press and hold , or

on the

transmitter (SmartStart™ uses only ).

The parking lights will flash 3

times quickly and

remain lit.

2. With the engine already running, apply the parking

brake twice within 10sec.

3. Make sure to release the brake pedal.

The parking lights will flash 3 times quickly and

remain lit.

4. Remove the key: the engine will keep on running.

5. Exit the vehicle. All doors should be closed, including the hood and trunk.

NOW THERE ARE THREE POSSIBLE OPTIONS

OPTION 1: No lock

OPTION 2: Manual shut down

(default)

OPTION 3: Automatic shut

down

The engine runs for 8 sec.

before finally shutting down the

engine, without user interaction

The engine keeps going until you press

either;

to lock the doors and shut

down the engine;

to unlock the doors and shut

down the engine;

to shut down the engine without

affecting the doors.

The engine runs for 8 sec. then

locks the doors before

finally

shutting down the engine,

without user interaction.

WARNING: The vehicle is not

armed or locked down.

WARNING: Engine runs until the pre-

programmed run time expires.

WARNING: Do not leave your

keys in the vehicle!

6. The Parking lights will flash twice to indicate Ready mode is set.

Remote-starting

Press the button for approximately 1 second. The parking lights will turn ON to inform you that

the Remote Car Starter has received your signal. Approximately 5 seconds later, the engine will

start. The parking lights will remain ON during the pre-programmed run time of the engine.

If your vehicle has an automatic transmission and it does not start at the first attempt, the system

will shut down, wait a few seconds and try to start the engine again. There will be 3 start attempts

before the system gives up.

Driving Off

With the vehicle running under remote control, press the button to disarm the Starter Kill and/or

the OEM-style alarm (if installed) and unlock the doors. Enter the vehicle and do the following:

xTurn the ignition key to the IGNITION ON (RUN) position. (Do not turn the key to

the CRANK position while the engine is running. This would cause the starter motor to

re-engage.)

xPress the brake pedal to disengage the remote starter unit.

You are now ready to drive off.

Note: On some Push-To-Start (PTS) vehicles, no takeover is possible as pressing the brakes will

shut the engine down. Please talk to your technician to determine if the “Takeover mode” can be

set for your vehicle.

User guide P.7

Remote Starter Features

Remote Door Locks

If your system was installed with the Remote Door Locks option, you will have the convenience of

remote keyless entry.

To lock your doors and arm the starter kill (if installed):

1. Press and hold the button for approx. 1 sec.

2. The parking lights will flash once to confirm that the doors have been locked

To unlock your doors and disarm the starter kill (if installed):

1. Press and hold the button for approx. 1 sec.

2. The parking lights will flash twice to confirm that the doors have been unlocked.

Remote Trunk Release

If your system was installed with the Remote Trunk Release option, you can open your trunk by

pressing the button for 3 seconds on the remote transmitter.

Idle Mode

Convenience feature: Idle Mode allows you to keep the engine running and the doors locked

while you stop, for example, at a convenience store or for a short delivery.

This feature allows you to let the remote starter take over control of the vehicle (i.e. no Key in the

Ignition Switch) while the engine is running.

Activating Idle mode (Automatic transmission):

1. With the engine running, make sure to release the brake pedal and press the ,

or button on the transmitter until the parking lights come ON.

Note: SmartStart™ can be setup to use the icon to activate Idle mode.

2. Remove the ignition key from the ignition switch.

The engine will continue running.

3. Exit the vehicle. All doors, the hood and trunk should be closed

4. Press the button to lock the doors, to arm the starter kill and to arm the alarm. The

engine will be kept running at idle speed.

a. When re-entering the vehicle, the user must reinsert the key into the ignition and

turn it to the ON position (not Crank) without pressing on the brake.

b. Once the key is in the ON position, press on the brake pedal to put the

transmission in gear.

c. Drive off.

If your vehicle has a manual transmission, Idle Mode can be activated through the same routine as

that used for Ready Mode (page-5); at the last step, the button is pressed instead of the other

buttons. This will lock the doors, arm the system and leave the engine running.

NEW FEATURE – Push-To-Start Idle Mode

This feature is a variation of “Idle mode”, but made specifically for Push-To-Start vehicles, with

automatic or manual transmissions. (Consult your installer for availability of this feature.) Follow the

same steps as the normal Idle Mode procedure, except for when re-entering the vehicle while the

engine is running;

1. Press unlock

P.10 User Guide

Example: If your Module is programmed for a runtime of 3 minutes and your vehicle has been

running for 2 minutes already, pressing the button will reset the counter to zero and the Engine

will run for another cycle (in this case, 3 minutes).

Disable/Enable LED flashing

To disable the LED: Press and simultaneously until the parking lights flash three

times.

To Enable the LED: Press and simultaneously until the parking lights flash once.

Constant output

xPressing and holding the button for more than 3 seconds will lock all doors and will

send a constant pulse as long as the button is held down (maximum of 15 seconds).

This constant pulse can be configured to activate certain functionalities such as rolling up

the windows – Please refer to your installer to see if your vehicle is compatible with

this option.

xPressing and holding the button for more than 3 seconds will unlock all doors and will

send a constant pulse as long as the button is held down (maximum of 15 seconds).

This constant pulse can be configured to activate certain functionalities such as rolling

down the windows – Please refer to your installer to see if your vehicle is compatible

with this option.

Advanced Features: Installation-programmable

Options

The Remote Car Starter was designed with flexibility and OEM integration in mind. With its

programmable options, this unit can single-handedly control nearly any electrical system in your

vehicle.

Caution: The programming of your system should be left to a professional. Changing any

one of the settings may affect the operation of your Remote Car Starter. Please note that the

following programmable options may require additional parts and labor.

Ignition-controlled Door Locks

This is an added security feature. If your Remote Car Starter was installed with the Ignition-

Controlled Door Locks option, the doors will automatically be locked as soon as the ignition key is

turned to the IGNITION ON (RUN) position while the brakes are pressed. The remote car starter

will also lock any door that was unlocked and opened (then closed) the next time the brake pedal is

pressed. When the key is turned to the OFF position, the doors will automatically be unlocked.

Secure Lock

(Disabled by default.) Before your vehicle can be remote-started, the factory security system must

first be disarmed. The Secure Lock feature may be required on certain vehicle models with factory

security systems that automatically unlock the doors when the security system is disarmed.

To keep your vehicle protected when the factory security system is disarmed for a remote start,

Secure Lock will relock your doors as soon as the vehicle is started. Once the engine is shut down

by remote or after its runtime has expired, Secure Lock will also rearm your factory security system

and relock the doors.

User guide P.9

Panic Mode

Note: Panic mode can only be activated if the horn has been adequately configured by the

installer.

In an emergency situation, you can activate panic mode by pressing and holding the STOP button

for more than 3 seconds, until the horn starts honking. If the vehicle is under a remote start, the

engine will shutdown automatically before setting off the horn. You can stop the horn by pressing:

(this will lock your doors and deactivate panic mode),or

(this will unlock your doors and deactivate panic mode).

Furthermore, the panic mode can be stopped by activating Valet Mode (page-8)

* Panic Mode will automatically shut down after 30 sec.

Quick LockoutTM

(Also called Secure Panic.) For fast protection in emergency situations, the system will LOCK all

doors when you press the brake pedal while you hear the sound signal. (Quick Lockout is only

available when panic mode has been set off.)

Cold Weather Mode

If the vehicle has a manual transmission, Ready mode (page-5) should be set before entering Cold

Weather mode. When Cold Weather Mode is active, the engine starts every 2 hours and runs for

3 minutes (or for 8 or 20 minutes with diesel engines). Cold Weather Mode automatically ends after

24 hours (or 12 starts).

To enter Cold Weather Mode:

xPress and hold the button for at least 3 seconds

xThe parking lights will flash for 2 seconds, pause, then flash 3 times.

To exit Cold Weather Mode, do any one of the following actions:

xOpen the hood.

xStart the engine by remote.

xTurn the ignition key to the IGNITION ON (RUN) position.

xPress and hold the button until the parking lights come ON for 2 seconds, pause,

and then flash once.

If Safe Start is enabled, you can activate Cold Weather Mode by:

xPressing and releasing the button, then, pressing and holding the button until the

parking lights flash 3 times.

To verify whether the system is in Cold Weather Mode (automatic transmissions only):

xPress the brake pedal:

xIf the vehicle is in cold weather mode, the parking lights will remain ON while the

brake pedal is pressed.

Extended Run Time

With the vehicle running under a remote start, pressing and holding the button for more than 3

seconds will reset the run time counter to zero and restart the run time cycle from the beginning.

xThe horn (if programmed) will honk once;

xThe parking lights will flash slowly 3 times then remain lit.

To stop the vehicle at any moment, simply press the STOP button. This procedure can only be

carried out once per remote start.

P.8 User Guide

2. Open and close all doors.

3. You have 1.5 minutes (or 3 minutes) to press on the brake pedal, to get in gear and

drive off.

Note 1: Pressing on the brake pedal after the allocated period will shut the engine down.

Note 2: The engine will continue running until the user re-enters the vehicle or until the expiration

of the engine run time.

Note 3: If the pre-programmed run-time expires or if the user shuts down the engine remotely, the

vehicle will enter Ready Mode.

Caution!! Do not leave children or pets unattended in a vehicle standing in Idle Mode.

Valet Mode

When the vehicle is in Valet Mode, the remote starter and alarm functionalities are disabled. If the

vehicle needs to be serviced, or if you park it indoors, the Valet Mode will prevent the engine from

being remote-started accidentally.

Any of the following features will put your remote car starter into Valet Mode:

Ignition Valet: This feature allows you to put your system into Valet Mode by using

the ignition key.

Remote valet: This feature allows you to put your system into Valet Mode by using the

transmitter.

To put the system into Valet Mode

To put the system into Valet mode using the KEY (Ignition Valet Mode):

1. Insert the ignition key into the ignition switch. Within 10 sec., turn the key 5 times

successively into the IGNITION/RUN and OFF positions.

2. The parking lights will flash three times.

3. Turn the ignition OFF.

4. The LED on the antenna will come ON solid to indicate that the vehicle has successfully

entered Valet mode.

To put the system into Valet mode using the TRANSMITTER (Remote Valet Mode):

1. Press the and buttons simultaneously until the parking lights flash three times.

2. The LED on the antenna will come ON solid to indicate that the vehicle has successfully

entered Valet mode.

To take the system out of Valet Mode

To take the system out of Valet mode using the KEY (Ignition Valet Mode):

1. Insert the ignition key into the ignition switch. Within 10 sec., turn the key 5 times

successively into the IGNITION/RUN and OFF positions.

2. The parking lights will flash twice.

3. Turn the ignition OFF.

4. The LED on the antenna will flash quickly to indicate that the vehicle is now out of Valet

mode.

To take the system out of Valet mode using the TRANSMITTER (Remote Valet Mode):

1. Press the and buttons simultaneously until the parking lights flash twice.

2. The LED on the antenna will be OFF.

The system will warn you if someone attempts to remote start the vehicle while in Valet Mode. The

parking lights will turn ON then OFF, then Flash twice.

Tabla de contenidos

Otros manuales de Arranque remoto de Smart Start

Smart Start

Smart Start AS-2471TW-FM Manual de usuario

Smart Start

Smart Start ns1074 Manual de usuario

Smart Start

Smart Start AS2272 Manual de usuario

Smart Start

Smart Start AS-1880FM Manual de usuario

Smart Start

Smart Start TRANSMISSION REMOTE STARTER Manual de usuario

Smart Start

Smart Start BC-11 Manual de usuario

Smart Start

Smart Start GS-2260TW Manual de usuario

Manuales populares de Arranque remoto de otras marcas

AstroStart

AstroStart 803U Manual de usuario

Durite

Durite 0-649-20 Manual

EINHELL

EINHELL BT-PS 1000 Manual

Linear

Linear ACCESS AK-21 Especificaciones técnicas

Soundstream

Soundstream TARANTULA RS.2 Manual de usuario

Jaycar Electronics

Jaycar Electronics MB3752 Manual de usuario

Ultra Start

Ultra Start 72 Series Manual de usuario

ADS

ADS FLASHLOGIC FLRSVW1 Manual de usuario

Selecta

Selecta JS012 Manual de usuario

Black Widow Security

Black Widow Security BW RAS 400 Manual de usuario

Vector

Vector Power City DK080706 Suplemento

Code Alarm

Code Alarm CA-535 Manual de usuario

Ozito

Ozito OJS-800 Manual de usuario

Profi-Partner

Profi-Partner 46387 Manual de usuario

EZ STARTER

EZ STARTER EZ-45 Manual de usuario

Viper

Viper 4204 Manual de usuario

Essex Electronics

Essex Electronics KE-1701 Manual de usuario

EINHELL

EINHELL EGS 3600 Manual
