3
A
1
1
2
2
3
3
Z30441A
Z30909
66233_silv_Kuechenwaage_Content_LB7.indd 3 15.06.11 09:48
4
I
S
P
O
T
C
S
D
TARE
TM
Ib’ oz
g
C
10 5
6
7
9
8
AAA 1.5V
AAA 1.5V
AAA 1.5V
AAA 1.5V
B
4
66233_silv_Kuechenwaage_Content_LB7.indd 4 15.06.11 09:48
5GB/CY
Table of Contents
Introduction
Proper Use............................................................ Page 6
Description of parts............................................. Page 6
Technical data...................................................... Page 7
Includes ................................................................ Page 7
Safety Instructions
General Safety Instructions ................................ Page 8
Safety Instructions for Batteries.......................... Page 9
Preparing the product for use
Replacing the batteries (Fig. B) .......................... Page 10
Setting the time (Fig. A)....................................... Page 11
Operation
Weighing (Fig. A) ................................................ Page 11
Incremental weighing (Fig. A) ............................ Page 12
Troubleshooting......................................... Page 12
Cleaning and Maintenance.............. Page 13
Service................................................................ Page 14
Disposal............................................................. Page 14
66233_silv_Kuechenwaage_Content_LB7.indd 5 15.06.11 09:48
6 GB/CY
Introduction
Digital Kitchen Scale
Introduction
Before assembling and using the device for the first
time, take time to familiarise yourself with the product
first. Read the following assembly instructions and
safety instructions carefully. Only use the product as described
and for the designated areas of application. Please keep these
instructions in a safe place. If you hand this product on to a third
party, you must also pass on all documents relating to the product.
Proper Use
This appliance is designed to weigh out and tare quantities of
food. The digital kitchen scale measures the weight of non-
aggressive, non-corrosive and non-abrasive liquids or solids. It
is not intended for weighing medication or prohibited materials.
Any use other than that described above or any modification
of the product is not permissible and will result in damage.
Misuse may also result in other life-threatening risks and injury.
The product is for private use only and is not intended for
medical or commercial use.
Description of parts
Kitchen scale (Figs. A+B):
1LC display
2TARE button (zero reset)
3MODE button
4Battery compartment
L
1
M
D
B
D
I
m
f
o
c
t
h
1
4
1
66233_silv_Kuechenwaage_Content_LB7.indd 6 15.06.11 09:48
7GB/CY
Introduction
t
c
t
d
e
d
t
.
t
s
.
y
.
LC display (Fig. C):
5“TM” = time mode
6“lb’oz” = weight unit indicator (pound:ounce)
7“g” = weight unit indicator (gram)
8“TARE” = tare weight
9“–” = negative value
10 “+/ – ” = battery low display
Technical data
Measuring range: 0–5,000g/0–11lb
Division: 1g /1oz
Batteries: 4x 1.5 V AAA
Dimensions: 210 x 200 x 26mm (L x W x D)
Includes
Immediately after unpacking please check the package contents
for completeness and if all parts and the product are in good
condition. Do not under any circumstances use the product if
the delivery is incomplete.
1 Digital kitchen scale
4 Batteries 1.5V AAA
1 Operating manual
66233_silv_Kuechenwaage_Content_LB7.indd 7 15.06.11 09:48
8 GB/CY
Safety Instructions
Safety Instructions
KEEP ALL THE SAFETY ADVICE AND INSTRUCTIONS IN
A SAFE PLACE FOR FUTURE REFERENCE!
General Safety Instructions
DANGER OF DEATH
AND ACCIDENTS FOR TODDLERS AND
CHILDREN! Never leave children unsuper-
vised with the packaging material. The packaging material
represents a danger of suffocation. Children frequently
underestimate the dangers. Always keep children away
from the packaging material.
DANGER TO LIFE! Batteries can be swal-
lowed, which may represent a danger to life. If a battery
has been swallowed, medical help is required immediately.
Children or persons who lack the knowledge or experience
to use the device or whose physical, sensory or intellectual
capacities are limited must never be allowed to use the
device without supervision or instruction by a person respon-
sible for their safety. Children must never be allowed to play
with the device.
5kg
CAUTION! RISK OF INJURY! Do not place
more than 5kg on the scale. This could damage
the product.
Do not expose the product to
– extreme temperatures,
– strong vibrations,
– heavy mechanical loads,
– direct sunlight
– magnetic fields,
– moisture.
These can damage the product.
66233_silv_Kuechenwaage_Content_LB7.indd 8 15.06.11 09:48
9GB/CY
Safety Instructions
Protect the product from electrostatic charge/discharge.
This could hinder the internal data exchange, which caus-
es errors in the LCD readout.
Check the product for damage before use. Never use a
damaged product.
Never open the housing of the product.
This can result in injury and damage to the product. Repairs
must be carried out by an electrician only.
Do not allow anyone inexperienced to use the product.
Make sure that anyone intending to use the product has
read the operating manual and is capable of operating
the product safely.
Place the product on a solid, horizontal and flat surface.
Magnetic fields may cause the product not to function
properly. If this happens, briefly remove the batteries from
the product and re-insert them.
FOOD-SAFE! The taste and smell of your
food are not detrimentally affected by this
product.
Safety Instructions for Batteries
Remove the battery from the device if they are not going
to be used for a prolonged period.
CAUTION! DANGER OF EXPLOSION!
The batteries must never be recharged!
When inserting the battery, ensure the correct polarity!
This is shown in the battery compartment.
If necessary, clean the batteries and device contacts before
inserting the batteries.
Remove spent batteries immediately from the device. There
is an increased danger of leaks!
Batteries must not be disposed of in the normal domestic
waste!
a
l
l
-
y
.
e
a
l
n
-
y
e
e
66233_silv_Kuechenwaage_Content_LB7.indd 9 15.06.11 09:48
10 GB/CY
Safety Instructions/Preparing the product for use
A
m
s
t
h
N
t
h
I
f
o
1
2
Every consumer is legally obliged to dispose of batteries
in the proper manner!
Keep batteries away from children; do not throw them in
the fire, short-circuit them or take them apart.
If the above instructions are not complied with, the batteries
may discharge themselves beyond their end voltage. There
is then a danger of leaking. If the batteries have leaked
inside your device, you should remove them immediately
in order to prevent damage to the device!
Avoid contact with the skin, eyes and mucous membranes.
Any parts of the body coming into contact with battery
acid should be rinsed off with copious amounts of water
and/ or a doctor contacted if necessary!
Preparing the product for use
Remove the insulation strip from the battery compartment 4.
Replacing the batteries (Fig. B)
Open the battery compartment 4on the back of the scale.
Remove the used batteries, if present.
Insert 4x 1.5 V AAA batteries into the battery compart-
ment 4.
Note: Make sure you fit the batteries the right way round
(polarity). The correct polarity is shown inside the battery
compartment 4.
Close the battery compartment 4.
66233_silv_Kuechenwaage_Content_LB7.indd 10 15.06.11 09:48
11GB/CY
Preparing the product for use/Operation
e
Setting the time (Fig. A)
After you have inserted the batteries, the scale switches auto-
matically into the time mode 5. As soon as the scale has
switched into the time mode 5, the minute value flashes in
the LC display 1. In this event, skip the next to two steps.
If the scale is in the weighing mode, press and keep pressed
the MODE button 3for 3 seconds to switch into the time
mode 5.
Press and keep pressed the TARE button 2to set the time.
Press the MODE button 3to set the desired minute value.
Press and keep pressed the MODE button 3to speed up
the value-setting process.
Press the TARE button 2to confirm your setting. Then the
hour value flashes.
Press the MODE button 3to set the desired hour value.
Press and keep pressed the MODE button 3to speed up
the value-setting process.
Press the TARE button 2to confirm your setting.
Note: If you do not press another button within 20 seconds,
the set value stops to flash and the time is set.
Operation
Weighing (Fig. A)
If the scale is in the time mode 5, press the MODE button 3
once to switch into the weighing mode.
Note: Shortly before the scale switches into the weighing
mode, the scale shows “HELO” in the display for 1–2 sec-
onds.
1. Place the kitchen scale on a solid, flat surface.
2. Press the MODE button 3once to change the weight
unit indicator (g/ lb’oz).
s
e
.
.
e
.
t
-
d
66233_silv_Kuechenwaage_Content_LB7.indd 11 15.06.11 09:48
12 GB/CY
Operation/Troubleshooting
3. Place the substance to be weighed on the scale. The
weight of the substance being weighed is shown in the
LC display 1.
Incremental weighing (Fig. A)
1. Follow steps 1 to 3 of the section on “Weighing” and
press the TARE button 2. The LC display 1shows 0
and the TARE symbol 8appears.
2. Add another substance to be weighed to the scale. The
LC display 1shows the weight of the newly added sub-
stance.
3. If you remove the added substance from the scale, the
LC display 1shows 0.
4. If you remove all of the substances to be weighed from
the scale, the LC display shows a negative value 9.
5. Press the TARE button 2once and the TARE symbol 8
ceases to be displayed.
6. Activate the TARE function only within a range of 3–1,000g.
If there is no substance to be weighed on the scale and if 60
seconds elapses without a button being pressed or no movement
on the scale plate is noted, the scale switches automatically
into the time mode 5.
Troubleshooting
= Fault
= Cause
= Solution
=
= The scale is unstable or not quite plumb.
= Ensure the device is firmly fixed in place and exactly plumb.
66233_silv_Kuechenwaage_Content_LB7.indd 12 15.06.11 09:48
Otros manuales para Z30441A
3
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Idiomas:
Otros manuales de Escala de Silvercrest
Silvercrest
Silvercrest SPWS 180 A1 Manual de usuario
Silvercrest
Silvercrest SBF 75 Manual de usuario
Silvercrest
Silvercrest SDL 300 C2 Manual de usuario
Silvercrest
Silvercrest H14271A Manual de usuario
Silvercrest
Silvercrest SKWH 5 A1 Hoja de información del producto
Silvercrest
Silvercrest SKWG 5 A1 Manual de usuario
Silvercrest
Silvercrest SPWS 180 B2 Manual de usuario
Silvercrest
Silvercrest Ernesto Retro EKWR 5 A1 Manual de usuario
Silvercrest
Silvercrest H14271A Manual de usuario
Silvercrest
Silvercrest Z31332A Manual de usuario
Silvercrest
Silvercrest SKWD A1 Manual de usuario
Silvercrest
Silvercrest SPWS 180 E1 Manual de usuario
Silvercrest
Silvercrest SPW 180 D4 Hoja de instrucciones
Silvercrest
Silvercrest H14271A Manual de usuario
Silvercrest
Silvercrest SPWS 180 A1 Hoja de información del producto
Silvercrest
Silvercrest 385530 2107 Manual de usuario
Silvercrest
Silvercrest SNAW 1000 D2 Manual de usuario
Silvercrest
Silvercrest SPWD 180 F1 Hoja de información del producto
Silvercrest
Silvercrest SPWG 180 G1 Hoja de información del producto
Silvercrest
Silvercrest SDL 300 C2 Manual de usuario
