WIRELESS DOORBELL STK 36 B2
IAN 295968
FUNKTÜRKLINGEL
Montage-, Bedienungs- und Sicherheitshinweise
WIRELESS DOORBELL
Assembly, operating and safety instructions
WIRELESS DOORBELL
Monterings-, betjenings- og
sikkerhedshenvisninger
SONNETTE SANS FIL
Instructions de montage, d‘utilisation et
consignes de sécurité
DRAADLOZE DEURBEL
Montage-, bedienings- en
veiligheidsinstructies
GB/IE/NI Assembly, operating and safety instructions Page 5
DK Monterings-, betjenings- og sikkerhedshenvisninger Side 21
FR/BE Instructions de montage, d‘utilisation et
consignes de sécurité Page 36
NL/BE Montage-, bedienings- en veiligheidsinstructies Pagina 52
DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 68
Sie benötigen
You need
Il vous faut
U hebt nodig
Potřebujete
Necesita
Necessita de:
ø 6mm
HG03569
A
1
2
6
8
5
4
73
B
109
GB/IE/NI 5
Introduction...................................................................................... Page 6
Intended use ........................................................................................... Page 6
Technical data ........................................................................................ Page 6
Included items......................................................................................... Page 7
Parts and features................................................................................... Page 8
Safety..................................................................................................... Page 9
General safety information .................................................................... Page 9
Safety instructions for batteries/ rechargeable batteries..................... Page 10
Assembly ............................................................................................ Page 12
Preparing for use ........................................................................ Page 13
Inserting/ replacing the batteries .......................................................... Page 13
Operation........................................................................................... Page 14
Synchronising transmitter/ receiver....................................................... Page 14
Setting the signal type............................................................................ Page 15
Setting the volume .................................................................................. Page 16
Selecting the chime................................................................................. Page 16
Troubleshooting...................................................................................... Page 16
Cleaning and maintenance................................................. Page 17
Disposal................................................................................................ Page 17
Information....................................................................................... Page 19
Simplified EU declaration of conformity................................................ Page 19
Warranty............................................................................................ Page 19
GB/IE/NI6
Wireless Doorbell
Introduction
We congratulate you on the purchase of your new product.
You have chosen a high quality product. The instructions for
use are part of the product. They contain important informa-
tion concerning safety, use and disposal. Before using the product,
please familiarise yourself with all of the safety information and instruc-
tions for use. Only use the product as described and for the specified
applications. If you pass the product on to anyone else, please ensure
that you also pass on all the documentation with it.
Intended use
This product is intended for the wireless transmission of the doorbell
chime. The product is not intended for commercial use.
Technical data
Range: 150m (unobstructed area)
Transmission frequency: 433MHz
GB/IE/NI 7
Transmitting power: <10dBm
Battery types: Receiver: 2x 1.5V (direct current)
(type AA/LR6),
Transmitter: 1x 3 V (direct current)
(type CR2032)
Receiver: Audible signal volume (at maximum volume
setting): min. 73dB (at a distance of 1 m
from the device)
Transmitter: IP rating: IP44
Included items
1 Transmitter
1 Receiver
2 Batteries 1.5V (direct current), type AA (receiver)
1 Batteries 3V (direct current), type CR2032 (transmitter)
4 Screws (for transmitter and for mounting the receiver on a wall)
3 Dowels
5 Exchangeable name plates (for the doorbell)
1 Doorbell cover
1 Operating instructions
GB/IE/NI8
Parts and features
Receiver (Figs. A/B):
1Signal indicator
2Speaker
3Signal type selector button (optical, acoustic, optical and acoustic
signal)
4Melody selection button
5Stand
6Volume button
7Synchronisation button
8Hanger
9Battery compartment
10 Battery compartment cover
Transmitter (Figs. C/D):
11 Chime button
12 Signal indicator
13 Name plate
14 Battery compartment
15 Holder (for wall mounting)
Mounting (Figs. E/ F):
16 Screw
17 Dowel
GB/IE/NI 9
18 Screw (for transmitter)
19 Protective foil
Safety
Read all safety information and instructions. Failure
to comply with the safety information and instructions may cause fire
and/ or serious injury.
YOU SHOULD STORE ALL SAFETY INFORMATION AND
INSTRUCTIONS IN A SAFE PLACE IN CASE YOU NEED TO REFER
TO THEM AGAIN IN THE FUTURE!
General safety information
Children often underestimate risks.
Always keep children away from the product. This is not
a toy.
This product can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given super-
vision or instruction concerning use of the product in a safe way and
understand the hazards involved. Children shall not play with the
GB/IE/NI10
product. Cleaning and user maintenance shall not be made by chil-
dren without supervision.
Check that all parts are in sound condition. If you use damaged
parts when assembling the product, you risk injury.
Check that all parts have been assembled correctly. There is a risk
of injury if the product is not properly assembled.
Keep the product away from open flames or sources of heat (e.g.
burning candles).
Safety instructions for batteries /
rechargeable batteries
DANGER TO LIFE! Keep batteries/ rechargeable batteries out of
reach of children. If accidentally swallowed seek immediate medical
attention.
DANGER OF EXPLOSION! Never recharge non-
recharge
able batteries. Do not short-circu
it batteries/
rechargeable batteries and/or open them. Overheating,
fire or bursting can be the result.
Never throw batteries/ rechargeable batteries into fire or water.
Do not exert mechanical loads to batteries/rechargeable batteries.
