Silvercrest KH 1143 Manual de usuario

KH 1143

6ELECTRIC ALL-PURPOSE

SHARPENER

Electric All-Purpose Sharpener

Operating instructions

KOMPERNASS GMBH

BURGSTRASSE 21 · D-44867 BOCHUM

www.kompernass.com

ID-Nr.: KH1143-08/09-V1

CV_KH1143_RP37663_LB6.qxp 26.08.2009 8:36 Uhr Seite 1

KH 1143

CV_KH1143_RP37663_LB6.qxp 26.08.2009 8:36 Uhr Seite 4

- 3 -

INDEX PAGE

Intended use 4

Items supplied 4

Technical data 4

Appliance description 5

Safety instructions 5

Unpacking 6

Placement 7

Adjustment 7

Sharpening 7

Cleaning and Care 9

Maintenance 9

Disposal 10

Importer 10

Warranty and Service 11

Read these operating instructions carefully before using the appliance for the first time

and preserve this booklet for later reference. Additionally, pass this booklet on to

whoever might acquire the appliance at a future date.

IB_KH1143_RP37663_LB6 26.08.2009 8:45 Uhr Seite 3

- 4 -

Intended use

This appliance is intended for the sharpening of knives, screwdrivers and scissors

in domestic households. This appliance is not intended for commercial or in-

dustrial applications.

Items supplied

1 x Electrical Knife Sharpener

1 x Operating Instructions

Technical data

Power consumption : 20 W max.

Mains voltage: 230 V ~50Hz

Revolutions: 3000 min-1

Protection class: II

C.O. Time: 3 min.

The C.O. Time (Continuous Operation) details how long an appliance may be

used without the motor overheating and being damaged. When the specified

C.O. Time has been reached, the appliance must be switched off until the

motor has cooled itself down to room temperature (approx. 30 minutes).

IB_KH1143_RP37663_LB6 26.08.2009 8:45 Uhr Seite 4

- 5 -

Appliance description

qFunction “Knife with smooth edge”

wFunction “Knife with serrated edge”

eFunction “Scissor sharpening”

rGrinder openings for slot-screwdrivers

tGrindstone

yFunction and protective cap

uAbrade collector

iSwitch

Safety instructions

To avoid potentially fatal electric shocks:

• Protect the appliance against moisture. Use it only in dry rooms, do not

use it outdoors or in damp areas.

• Ensure that the power cable cannot be damaged when the appliance is

in use, particularly not by sharpened knife or scissor blades.

• In order to avoid potentially fatal risks, should the power cable and/or the

plug become damaged, arrange for it/them to be replaced by Customer

Services before continuing to use the appliance.

• NEVER open any housing components, other than those specified herein.

• After use or during extended absences, ALWAYS remove the plug from

the power socket. For as long as the plug is inserted in the wall socket

the appliance itself is under electrical power.

• Ensure that the power plug is at all times easily accessible, so that it can

be quickly and easily removed in the event of potential danger or risk.

IB_KH1143_RP37663_LB6 26.08.2009 8:45 Uhr Seite 5

- 6 -

avoid the risks of accidents and personal injuries:

• Always check to ensure that the appliance is in a serviceable condition

before taking it into use. If there is recognisable damage to the appliance

it may not be used. Arrange for it to be safety-checked by Customers

Services before using it again.

• Take steps to ensure that hair, loose clothing and parts of the body do

not come into contact with the revolving grindstone t.

• Wear protective gloves so as to avoid injury from sharp blades, or, if you

are operating the knife sharpener with the function cap yremoved.

• This appliance is not intended for use by individuals (including children)

with restricted physical, physiological or intellectual abilities or deficiences

in experience and/or knowledge unless they are supervised by a person

responsible for their safety or receive from this person instruction in how the

appliance is to be used. Children should be supervised to ensure that they

do not play with the appliance.

Unpacking

• Check that all items listed are available and that they show no signs of

visible damage.

• Remove all parts from the packaging and all packaging remnants from

the items.

• Retain the packaging, either for storing the appliance or for reuse in the

event of posting it to Customer Services for repair.

• Before the first usage thoroughly clean all component parts as described

in the section "Cleaning and care".

IB_KH1143_RP37663_LB6 26.08.2009 8:45 Uhr Seite 6

- 7 -

Placement

• Place the appliance on a stable and slip-free surface.

• Then insert the plug into the power socket.

Adjustment

• To select the required sharpening function q w e, turn the function

cap yuntil the cap perceptibly engages.

• In the position w“Knife with serrated edge” the relevant symbol points

to the grinder opening – however, the cap engages at that point.

• Hold the switch ipressed down. The grindstone trevolves continuous-

ly until the switch iis released.

Sharpening

• First present the blade when the grindstone tis revolving.

• Always draw the knife or scissors back, from the blade stop, in an even

movement, not in a repetitive back and forth movement – otherwise the

result will be an uneven sharpening.

• Do not apply any great pressure and always sharpen only clean blades,

so as to avoid a premature wearing-out of the grindstone.

• Always sharpen knives and scissors so that the blade is at an acute angle

to the grindstone (as alluded to in the shape of the opening). Sharpening

at the false angle can destroy any blade.

• After sharpening, remove any possible grinding remnants that may be on

the blade with a moist cloth.

IB_KH1143_RP37663_LB6 26.08.2009 8:45 Uhr Seite 7

- 8 -

If you have selected the setting "Knife with smooth edge" q:

• Always sharpen knives with a smooth edge on both sides – for this, left

and right side sharpening guides are available.

• In the left guide hold the knife inclined to the left, and in the right guide

inclined to the right, whilst drawing the blade through.

If you have selected the setting "Knife with serrated edge" w:

• Sharpen these only on the side with the serration – the draw through di-

rection for the knife is dependant on which side of the blade this is on.

• In general, serrated blades can only be sharpened up to a point. Knifes

with a fine sawtoothing (e.g. table knives) do not require sharpening.

If you have selected the setting "Scissor sharpening" e:

• Sharpen both scissor blades one after the other. For this, open the scissors

out and draw both blades, one after the other, through the guide.

Should you wish to grind a slot-screwdriver rflat:

• This is possible in every position of the function cap y. Appropriate to its

width, insert the screwdriver through one of the two grinding openings r

on the front of the function cap (see fold-out side). The end face of the

screwdriver will now be ground level and flat.

Certain edges can possibly be more easily sharpened directly on the grind-

stone t, without the function cap: For these cases, the function cap is re-

movable:

• Turn the function cap yuntil the arrow is at the top.

You can now take off the function cap.

• To replace the function cap y, hold it so that the arrow is once

again at the top. You can now push the cap on and secure it by turning

it to the left or right.

IB_KH1143_RP37663_LB6 26.08.2009 8:45 Uhr Seite 8

- 9 -

Cleaning and Care

To avoid risks of personal injury and damage:

• Before carrying out any maintenance work, first remove the plug from the

wall socket.

• NEVER submerse the appliance in water or other liquids! These could

damage the appliance. Additionally, there is a potentially fatal risk of

electric shock should moisture come into contact with electrical components.

Cleaning the appliance:

• Turn the function cap y, until the arrow is at the top. You can now

remove the function cap and clean the area around the grindstone t

with a dry brush.

• Dismantle the abrade collector uand clean it with a brush and, if

necessary, a lightly moistened cloth.

• Clean the remaining parts of the appliance also with a lightly moistened

cloth, not with abrasive or aggressive detergents. They can damage the

surfaces.

• To replace the function cap y, hold it so that the arrow is once

again at the top. You can now push the cap on and secure it by turning

it to the left or right. To conclude, reassemble the abrade collector u

into the appliance.

Maintenance

• The appliance is maintenance-free. No form of maintenance, either on

or in the appliance, is intended for execution by the user. In the event of

malfunction or apparent damage, make contact with Customer Services.

• For storage, wrap the power cable around the appliance housing.

IB_KH1143_RP37663_LB6 26.08.2009 8:45 Uhr Seite 9

- 10 -

Disposal

Do not dispose of the appliance in your normal domestic waste.

Dispose of the appliance through an approved disposal centre or at your

community waste facility. This device is subject to the European Guidelines

2002/96/EC. Observe the currently applicable regulations. In case of

doubt, please contact your waste disposal centre.

Dispose of all packaging materials in an environmentally friendly

manner.

Importer

KOMPERNASS GMBH

BURGSTRASSE 21

D-44867 BOCHUM

www.kompernass.com

IB_KH1143_RP37663_LB6 26.08.2009 8:45 Uhr Seite 10
