SIMATIC
ET 200S distributed I/O
Power module PM-E DC24V HF
(6ES7138-4CA60-0AB0)
Manual
06/2010
A5E02515369-02
Preface
Properties
1
Parameters
2
Diagnostics
3
Configuring
4
Legal information
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the corresponding information is not taken into
account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation for the specific task, in particular its warning notices and
safety instructions. Qualified personnel are those who, based on their training and experience, are capable of
identifying risks and avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be adhered to. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E02515369-02
Ⓟ 06/2010
Copyright © Siemens AG 2010.
Technical data subject to change
Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)
Manual, 06/2010, A5E02515369-02 3
Preface
Purpose of the manual
This manual supplements the
ET 200S Distributed I/O System
Operating Instructions.
General functions for the ET 200S are described in the ET 200S Distributed I/O System
Operating Instructions (http://support.automation.siemens.com/WW/view/en/1144348).
The information in this document along with the operating instructions enables you to
commission the ET 200S.
Basic knowledge requirements
To understand these operating instructions you should have general knowledge of
automation engineering.
Scope of the manual
This manual applies to this ET 200S module. It describes the components that are valid at
the time of publication.
Recycling and disposal
Thanks to the fact that it is low in contaminants, this ET 200S module is recyclable. For
environmentally compliant recycling and disposal of your electronic waste, please contact a
company certified for the disposal of electronic waste.
Additional support
If you have any questions relating to the products described in this manual and do not find
the answers in this document, please contact your local Siemens representative
(http://www.siemens.com/automation/partners).
A guide to the technical documentation for the various SIMATIC products and systems is
available on the Internet. (http://www.siemens.com/simatic-docu).
The online catalog and ordering systems are available on the Internet
(http://www.siemens.com/automation/mall).
Training center
We offer courses to help you get started with the ET 200S and the SIMATIC S7 automation
system. Please contact your regional training center or the central training center in D -
90327, Nuremberg, Germany (http://www.siemens.com/sitrain).
Preface
Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)
4 Manual, 06/2010, A5E02515369-02
Technical Support
You can contact Technical Support for all Industry Automation products by means of the
Internet Web form for the Support Request
(http://www.siemens.com/automation/csi_en_WW/support_request).
Additional information about Siemens Technical Support is available on the Internet
(http://www.siemens.com/automation/csi_en_WW/service).
Service & Support on the Internet
In addition to our documentation, we offer a comprehensive knowledge base on the Internet
(http://www.siemens.com/automation/csi_en_WW/support).
There you will find:
● Our Newsletter, which constantly provides you with the latest information about your
products.
● The right documentation for you using our Service & Support search engine.
● The bulletin board, a worldwide knowledge exchange for users and experts.
● Your local contact for Automation & Drives in our contact database.
● Information about on-site services, repairs, spare parts, and lots more.
Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)
Manual, 06/2010, A5E02515369-02 5
Table of contents
Preface ...................................................................................................................................................... 3
1 Properties .................................................................................................................................................. 7
1.1 Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)...........................................................7
2 Parameters.............................................................................................................................................. 11
2.1 Parameters for PM-E DC24V HF.................................................................................................11
3 Diagnostics.............................................................................................................................................. 13
3.1 Diagnostics using LED display.....................................................................................................13
3.2 Error types....................................................................................................................................14
4 Configuring .............................................................................................................................................. 15
4.1 Configuring the address space ....................................................................................................15
Table of contents
Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)
6 Manual, 06/2010, A5E02515369-02
Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)
Manual, 06/2010, A5E02515369-02 7
Properties 1
1.1 Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)
Properties
● The PM-E DC24V HF power module monitors the supply voltage for all electronic
modules in the voltage group. The supply voltage is fed in by means of the TM-P terminal
module.
● You can use all the electronic modules except the 2DI AC120V ST, 2DI AC230V ST, and
2DO AC24..230V/1A in the voltage group of the PM-E DC24V HF power module.
● The current status of the power module is stored in the status byte in the process input
image (PII). This is updated irrespective of whether the "No Load Voltage" diagnosis has
been enabled.
● The PM-E DC24V HF power module is suitable for fail-safe modules.
● Extended temperature range from 0 to 55°C with vertical installation.
CAUTION
If you do not maintain the indicated load voltage of 24V DC, the result may be
dangerous plant conditions.
The result may be damages to the ET 200S or minor personal injuries.
Only connect the specified load voltage of 24V DC to the TM-P terminal module of the
power module. The connected load voltage must correspond to the supply voltage of the
electronic modules in the voltage group.
Requirements for operation
It is possible to operate the PM-E DC24V HF power module using the following interface
modules as of the order numbers specified.
Interface module as of order number Firmware version (or
higher)
IM 151-1 STANDARD 6ES7151-1AA05-0AB0 V2.2.4
IM 151-1 FO STANDARD 6ES7151-1AB05-0AB0 V2.2.4
IM 151-1 HIGH FEATURE 6ES7151-1BA02-0AB0 V2.2.3
IM 151-3 PN 6ES7151-3AA23-0AB0 V7.0.0
IM 151-3 PN FO 6ES7151-3BB23-0AB0 V7.0.0
IM 151-3 PN HIGH FEATURE 6ES7151-3BA23-0AB0 V7.0.0
IM 151-3 PN HIGH SPEED 6ES7151-3BA60-0AB0 V3.0.0
IM 151-8 PN/DP CPU 6ES7151-8AB01-0AB0 V3.2.0
IM 151-8F PN/DP CPU 6ES7151-8FB01-0AB0 V3.2.0
Properties
1.1 Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)
Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)
8 Manual, 06/2010, A5E02515369-02
Maximum configuration per voltage group
The number of modules that can be connected depends on the total current of all modules in
a voltage group. This total must not exceed the maximum current carrying capacity.
Address space of inputs/outputs
Address space of inputs/outputs by selecting the following as an option:
Options Address space of the inputs Address space of the outputs
Status byte (S) 1 byte --
Option handling (O) 8 bytes 8 bytes
Status byte and option handling
(SO)
9-byte inputs 9 bytes (9th byte not relevant)
General terminal assignment
Note
Terminals A4 and A8 are only available at specified terminal modules.
Terminal assignment for PM-E DC24V HF (6ES7138-4CA60-0AB0)
Terminal Assignment Terminal Assignment Notes
2 L+ 6 L+
3 M 7 M
A4 AUX1 A8 AUX1
L+: Rated load voltage 24 VDC
M: Chassis ground
AUX1: Protective-conductor terminal or potential bus (freely usable
up to 230 VAC)
Properties
1.1 Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)
Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)
Manual, 06/2010, A5E02515369-02 9
Usable terminal modules
Usable terminal modules for PM-E DC24V HF (6ES7138-4CA60-0AB0)
TM-P15C23-A1
(6ES7193-
4CC30-0AA0)
TM-P15C23-A0
(6ES7193-4CD30-
0AA0)
TM-P15C22-01
(6ES7193-4CE10-
0AA0)
Spring terminal
TM-P15S23-A1
(6ES7193-
4CC20-0AA0)
TM-P15S23-A0
(6ES7193-4CD20-
0AA0)
TM-P15S22-01
(6ES7193-4CE00-
0AA0)
Screw-type terminal
TM-P15N23-A1
(6ES7193-
4CC70-0AA0)
TM-P15N23-A0
(6ES7193-4CD70-
0AA0)
TM-P15N22-01
(6ES7193-4CE60-
0AA0)
Fast Connect
$8;
$
8; $$
$$
$8;
$8;
$$
$$
$8;
'&9 '&9
3($8;
0
&RQQHFWLRQH[DPSOHV
Block diagram
'&9
0
3
3
3:5
5HDUSDQHOEXV
(76
EDFNSODQH
EXV
FRQQHFWLRQ
/RDGDQG
UHJHQHUDWLRQ
YROWDJH
PRQLWRULQJ
Figure 1-1 Block diagram of the PM-E DC24V HF power module
Properties
1.1 Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)
Power module PM-E DC24V HF (6ES7138-4CA60-0AB0)
10 Manual, 06/2010, A5E02515369-02
Technical data PM-E DC24V HF (6ES7138-4CA60-0AB0)
Dimensions and weight
Dimension B (mm) 15
Weight Approx. 35 g
Voltages, currents, potentials
Rated load voltage 24 VDC
Overvoltage protection No
Protection with automatic circuit breakers Yes, tripping characteristic B, C
Max. current-carrying capacity 10 A
Short-circuit protection No
Electrical isolation
Between rated load voltage and backplane
bus Yes
Between the power modules Yes
Insulation test voltage 500 VDC
Current consumption
From the load voltage L+ (no load) max. 15 mA
Power dissipation of the module typ. 350 mW
Parameter length 3 bytes
Status, interrupts, diagnostics
Diagnostic function Yes
Group error Red "SF" LED
Load voltage monitoring Green "PWR" LED
Diagnostic information readable Yes
Otros manuales para SIMATIC ET 200S
33
Tabla de contenidos
Otros manuales de Unidad de control de Siemens
Siemens
Siemens SIMOTION D4x5 Series Manual de usuario
Siemens
Siemens SIMATIC RTLS4330G Manual de usuario
Siemens
Siemens SINUMERIK Series Manual de lista de piezas
Siemens
Siemens HLIM Manual de servicio
Siemens
Siemens MEM-1 Manual de usuario
Siemens
Siemens HCP Manual de usuario
Siemens
Siemens 3RA2816-0EW20 Manual de usuario
Siemens
Siemens simovert masterdrives Manual de usuario
Siemens
Siemens SINUMERIK 840D sl Manual de usuario
Siemens
Siemens SIRIUS 3SB3 Manual de usuario
Siemens
Siemens SINAMIC G130 Manual de usuario
Siemens
Siemens SIMATIC Manual de usuario
Siemens
Siemens COM060 Manual de usuario
Siemens
Siemens SIRIUS 3RA2916-1A Manual de usuario
Siemens
Siemens SIMATIC FM 351 Manual de usuario
Siemens
Siemens OLM/P11 V4.0 Manual de usuario
Siemens
Siemens K60 F Series Manual de usuario
Siemens
Siemens SIJECT 16i Manual de usuario
Siemens
Siemens SINUMERIK 840D sl Manual de usuario
Siemens
Siemens SINUMERIK 805 Manual de usuario
Manuales populares de Unidad de control de otras marcas
Festo
Festo Compact Performance CP-FB6-E Manual de lista de piezas
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Manual de usuario
JS Automation
JS Automation MPC3034A Manual de usuario
JAUDT
JAUDT SW GII 6406 Series Guía rápida
Spektrum
Spektrum Air Module System Manual de usuario
BOC Edwards
BOC Edwards Q Series Manual de usuario
