Sennheiser Evolution e609 Manual de usuario

User manual 2 – 5

Gebrauchsanleitung 6 – 9

Istruzioni per l’uso 10 – 13

Manuel ’utilisation 14 – 17

Manual el usuario 18 – 21

Gebruiksaanwijzing 22 – 25

Thank you for buying this Sennheiser

Evolution microphone.We wish you much

satisfaction and enjoyment from its use.

Made from the highest quality materials

and components, this has been manufactured

to the same exacting standards that have

become the hallmark of SENNHEISER

products over the last fifty years and made

them reference equipment for broadcast,

studio and stage, the world over.

The family of ten Evolution mics shown

opposite cover every vocal and instrument

application and provide you with the most

comprehensive range to select from,

whatever your requirement.

revolution

Welcome to the

EVOLUTION

Amazing SPL in excess of 50 dB on all models

Outstanding feedback rejection.

Advanced shock-mount design minimises handling noise.

Rugged road-proof construction.

Designed and made in Germany.

...and they sound great !

A new family of microphones for

new standards of performance

Connection

The famous Sennheiser

“flat-profile” design,

updated for modern

performance requirements

whilst maintaining all of

the microphone’s classic

features.

Distinctive lateral mounted

capsule for miking guitar

cabs face on and extremely

close to the signal source.

Super-cardioid pick-up

pattern provides isolation from

other on-stage signals.

The lightweight voice coil

construction and rigid dome

diaphragm provide both extended

high frequency performance and a

hard wearing capsule assembly.

Also suitable for drum miking,

particularly toms, where the

microphone’s profile allows the

capsule to be positioned close to the

drum skin.

Frequency Response

Polar Pattern

Frequency response 40Hz…18kHz

Trans ucer principle Pressure gradient

receiver

Pick-up pattern Super-cardioid

Front-to-back-rejection at 1kHz at 120˚ 15dB

Sensitivity (free fiel ,no loa ) 1kHz

1.5mV/Pa ≡ −56.5dB (0dB=1V/Pa)

≡ −76.5dB (0dB=1V/µbar)(USA)

Nominal impe ance at 1kHz 350Ω

Min.terminating impe ance 1kΩ

Sensitivity to magnetic

fiel at 50Hz ≤1µV/µT

Weight 180g

Dimensions 55 x 34 x 134mm

Delivere with pouch an mic clip

English

Product Registration Card

Ensure your:

✓ Warranty Confirmation

✓ Owner Verification

✓ Model Registration

Protect Your Investment

Congratulations on your Sennheiser Audio equipment

purchase.Your Sennheiser equipment is sure to provide years

of listening enjoyment. To receive all the privileges your

purchase entitles you to, please complete and mail your

Product Registration Card today.

Please retain this portion for your records.

Model Number: Serial Number:

Return the attached card within 10 days to ensure:

✓Warranty Confirmation Ensure your right to protection under

the terms and conditions of our limited

warranty.

✓Owner Verification Can serve as verification of ownership in

the event of loss or theft.

✓Model Registration Ensure receipt of information and bene-

fits due t owners of your model.

To register your product on-line or for

up-to-date information on Sennheiser products visit

our Web Site at www.sennheiserusa.com

Product Registration Card

Your name will not be provided to other companies for mailing purposes.

DETACH AND MAIL THIS PORTION TODAY

Date of Purchase: Model Number: Serial Number:

First Name: Middle Initial: Last Name:

Street Address:

City: State: Zip Code:

Telephone: Fax: E-Mail:

Purchase Details:

Purchased at:

Street Address:

City: State: Zip Code:

Telephone: Fax: E-Mail:

Not applicable in Hongkong,Japan,taiwan

Sennheiser electronic · D-30892 Wedemark · Germany

Tel +49-5 30-600-0 · Fax +49-5 30-600-300 · Web site:www.sennheiser.com

Printed in Germany 69730 0398

Sennheiser Electronic Corp.

One Enterprise Drive

P.O.Box 987

Old Lyme,CT 0637

First

Class

Postage

Required
