Securitytronix ST-IP-DVF-1 Manual de usuario

ST-IP-DVF-1

ST-IP-DVF-2

HD Mini Network Dome Camera Quick Start Guide

Version 1.0.0

Welcome

Thank you for purchasing our Networkcamera.

This Quick Start Guide is designed to get yoursystem up and running as easily as possible.

This document applies to both the ST-IP-MD36-1 and ST-IP-MD36-2 camera models (1mp & 2mp).

Please read the following safeguard and warnings carefully before you use this camera.

Please keep this document for futurereference.

Important Safeguards and Warnings

1．Electrical safety

All installation and operation should conform to your local electrical safetycodes.

The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the

Limited power source is rated 12V DC, DC5V or AC24V in the IEC60950-1. (Power supply

requirement is subject to the camera label).

Please prevent the line cord from being crushed or damaged, especially at the plug, power socket and

the junction from the camera.

Note: Do not connect a PoE power source AND a power supply to the camera at the same time;

it may result in camera damage.

We assume no liability or responsibility for fires or electrical shock caused byimproper handling or

installation.

We are not liable for any problems caused by unauthorized modification or attemptedrepair.

2．Environment

Don’t aim the camera at strong light (such as lighting, sunlight and so on) to focus; otherwise it

may cause overexposure, which will affect the longevity of the CCD or CMOS imager.

Please transport, use and store the camera within the range of allowed humidity and temperature. Don’t

keep the camera in a place which is wet, dusty, extremely hot, and extremely cold and with strong

electromagnetic radiation or unstablelighting.

Please do not allow water and other liquids to enter the camera, to prevent the internal

components from being damaged.

Please allow adequate ventilation around the camera to prevent heataccumulation.

Please pack the camera with the standard factory packaging or material with the same quality

when transporting the camera.

Avoid bumps and humidity during transportation, storage and installation.

3. Operation and Daily Maintenance

Please do not dismantle the camera; Doing so may void your warranty.

It is recommended to use this camera with a surge-protection device.

The grounding holes of the product are recommended to be grounded to further enhance the reliability of

the camera.

Do not touch the CCD (CMOS) optic component directly. You can use an air blower to clean the dust

or dirt on the lens surface. Please use a dry cloth wetted by alcohol to wipe away the dust gently if it is

necessary to clean.

Always use a dry, soft cloth to clean the camera. If there is too much dust, please use the water to dilute

mild detergent first and then use it to clean the camera. Finally use the dry cloth to clean the camera.

Don’t use volatile solvents like alcohol, benzene, thinner etc or strong detergents with abrasiveness,

otherwise it will damage the surface coating or reduce the working performance of the camera.

The dome cover is an optical element, please don’t touch or wipe cover surface directly during

installation and use, please refer to the following methods to clean a dirty lens:

Stained with dirt:

Use an oil-free soft brush to gently remove it.

Stained with grease or fingerprints:

Use a soft cloth to wipe the dome gently to dry it, then use oil-free cotton cloth or paper soaked with

alcohol or detergent to wipe from the lens center to outward. It is ok to change the cloth and wipe

several times to get all of the dirt off.

Warning

Please use the standard accessories provided by SecurityTronix and make sure the camera is

installed and repaired by professional engineers.

Do not use more than one power supply modes for the camera, otherwise it may cause damage to the

camera.

Statement

Please refer to the actual product for more details; this manual is just forreference.

Please contact the supplier or customer service if there is any problem occurred when using the

camera.

Please contact the customer service for the latest procedures and supplementary documentation.

There may be deviations between the actual value of some data and the value provided in the manual

due to the reasons such as the real environment is not stable and so on.

Please refer to the disk for more details, check and download corresponding user’s manual and tool.

Before installation, please open the package and check all the components areincluded.

Contact your local retailer ASAP if something is broken in yourpackage.

Accessory Name Amount

Network Camera Unit 1

Quick Start Guide 1

Installation Accessories Bag 1

CD 1

Table of Contents

Structure........................................................................................................................ 1

1.1 Components....................................................................................................... 1

1.2 Physical Properties ............................................................................................ 2

1.3 Alarm Setup....................................................................................................... 3

Camera Installation........................................................................................................ 4

2.1 Installation Steps................................................................................................ 4

2.2 Micro SD Card Installation.................................................................................. 6

2.3 Lens Adjustment ................................................................................................ 7

Network Configuration................................................................................................... 8

3.1 Modify IP Address.............................................................................................. 8

3.2 Login WEB Interface.......................................................................................... 9

Structure

Note:

The following diagram is for reference only, to illustrate the camera component and cable port

functions.

Camera component and cable port function may differ according to different models, please refer to

the actual camera for details.

1.1 Components

Refer to the following figure for hardware configuration. See Figure 1-1.

Figure 1-1 Component functions

Please refer to the following sheet for detailedinformation.

Component Component Name

Component 1 Dome camera module

Component 2 Dome enclosure

Port Port Name Note

Port 3Power input port Connect to DC 12V power, input power.

Port 4I/O port Alarm signal input/output (optional,

not supported by ST-IP-DVF-1 / 2)

Port 5Internet access port Network data in/out and PoE.

Note:

Some cameras do not support PoE.

Port 6Audio input port

Input audio signal, receive analog audio

signal from a microphone (optional, not

supported by ST-IP-DVF-1 / 2).

Port 7Audio output port Output audio signal to speakers (optional,

not supported by ST-IP-DVF-1 / 2)

Please refer to the following sheet for detailed information about I/Oport.

Port

Name Port

Sequence Port name Function Description

I/O Port

1ALARM_IN1 Alarm input port, receive on-off signal of

external alarm source.

2ALARM_OUT1 Alarm output port, output alarm signal to

alarm camera.

3ALARM_GND Connect ground

Please refer to the following two figures for dimension information. The unit is mm. See Figure1-2

Figure 1-2 Dimension illustration

Note:

Alarm is not supported by ST-IP-DVF-1 / 2

Alarm input, output description:

Step 1 Connect alarm input device to the alarm input of I/Ocable.

Step 2 Connect alarm output device to the alarm output of I/O cable, alarm output isNormally

Open circuit output which connects a10K resistor to 3.3Vexternally.

Step 3 Open the Web, set alarm input and output correspondingly. Alarm input on WEB

corresponds to the I/O cable on the camera. When an alarm is triggered,the alarm input

device will generate asignal of high and low level. Set corresponding NO and NCinputs.

Step 4 Set the WEB alarm output. The alarm output corresponds to the alarm port wires of the

camera.

Please refer to the following figure for alarm input information. See Figure1-3.

Alarm input: When the input signal is idle or grounded, the camera can collect the different statuses of

the alarm input port. When the input signal is connected to 3.3V or idle, the camera collects the logic

“1”. When the input signal is grounded, the camera collects the logic“0”.

Figure 1-3

Please refer to the following figure for alarm output information. See Figure1-4

When alarm output is OC, it needs to increase pull-up resistance externally to work normally; output

signal uses a high and low level. After external pull-up resistance is increased, the default of the output

signal is high level, and it switches to low level when there is an alarm output.

The working current of alarm output port is recommended as <= 10mA. The max current which is used

to drive external circuit is 80mA, it is advised to add a relay if it is beyond thevalue.

Figure 1-4

Different models may have different ways to install due to different appearance, please refer to the

corresponding figures according to the actualproducts.

Manual Vari-focal Camera

Figure 2-1

Important

Before installing the camera, please make sure the installation surface can support at least 3x

the weight of the camera and the bracket.

Follow the steps listed below to install the camera. Please refer to Figure 2-1 forreference.

Step 1

Use the included hex wrench to open dome enclosure by loosening the 3 hex screws on the exterior

of the camera’s dome.

Step 2

Locate the mounting template sticker and affix it on the ceiling or the wall according to your monitor

area requirements.

Step 3

Drill 3 holes, 3/16” diameter as indicated at the marks on the template. Remove the template and

insert the 3 included plastic expansion anchors in the holes.

Note:

If the cable must exit behind the installationsurface (behind a wall or inside the ceiling), Drill a

¾” cable exit hole in the mounting surface according to the installation template.

If the cable must exit the camera on the surface of the wall or ceiling, use a strong needle-nose

plier or similar tool to pry out and remove the thin metal of the camera’s outer shell, as shown in

Figure 2-1 above; “Remove this for surface-cable use”.

Step 4

Adjust the base of the camera to the proper position and then pull the cable through the cable exit

hole drilled earlier in the ceiling or wall. Line up the TOP direction of the device to the installation

template and then line up the three screw holes in the camera’s base to the three plastic anchors in

the mounting surface. Install the three self-tapping screws firmly into the anchors.

Step 5

Loosen the two thumb screws which secure the lens rotation structure NOTE: Do not remove these

screws. Only loosen them enough for the camera housing to move freely to the correct

viewing position. Adjust the lens to the required viewing angle, then secure the screws of the lens

rotation structure. The lens adjust angle ranges are: flip (0°~+75°), video pan rotation (-15°~+15°),

video rotation angle(-15°~+15°).

Note:

Pay attention to the image rotation direction when aiming the camera vertically past 64 degrees

vertically, to avoid the outer cover blocking the IR light and influencing the IR effect.
