Securitytronix ST-HD-D2812M-2MP Manual de usuario

INSTALLATION MANUAL

www.nacebrands.com www.securitytronix.com

Professional Motorized Varifocal Camera

ST-HD-D2812M-2MP

Description:

The ST-HD-D2812M-2MP is a professional-grade dome color camera

with IR and motorized zoom capabilities, and 1080p resolution. A

2.8mm to 12mm motorized lens makes zooming and focusing during

installation fast and simple, and its ability to send HD video over

coaxial cable makes the ST-HD-D2812M-2MP a cost effective high-

definition surveillance solution for any budget.

Specifications:

Image Sensor

1/2.8” CMOS

Resolution

1920(H) x 1080(V) @25fps

Scanning System

Progressive

Auto Electronic Shutter

1/3s ~ 1/100,000s

Minimum Illumination

[email protected]; 0Lux (IR on)

Video Output

1-channel BNC HD-CVI high definition video output / CVBS standard definition

video output (Can switch)

Day/Night

Auto(ICR) / Color / B/W

Noise Reduction

2D/3D

Lens

2.8mm - 12mm, Motorized

IR LED

2PCS

IR Distance

Up to 98 feet

Power Supply

DC12V 1A

Power Consumption

8.5W (IR on)

Working Environment

-20°f ~ 133°f / Less than 95% RH

Ingress Protection

IP66

Dimensions

φ 4.8”x3.5”

Weight

1lbs

CAUTION: To reduce the risk of electrical shock, do not open this unit.

No user serviceable parts are inside.

CAUTION: To prevent electric shocks and risk of fire hazards, do not

use other than specified power source.

Unpacking

Package Contents:

(1) ST-HD-D2812M-2MP Motorized Varifocal IR Camera

(1) Installation Manual

Note: The ST-HD-D2812M-2MP requires a 12VDC 1A power supply such

as the ST-PS12VDC1A.

Ensure that all accessories and documentation are removed from the

container before discarding packing material.

Inspect the front, sides, and rear of the equipment for shipping

damage. Make sure the equipment is clean, and no connectors are

broken, damaged, or loose. If equipment appears to be damaged or

defective please contact your distributor or SecurityTronix at:

(800) 688-9282, press 3for tech support, then press 2for CCTV.

Setup & Installation

!! ATTENTION !!

The installer must comply with electrical safety standards.

There must be sufficient space between the camera’s power

supply and video line and any high voltage equipment and/or

cables.

To help ensure the camera’s life and proper operation do not

point the camera towards the sun or strong light.

Do not install the camera in an environment where the

temperature is above 130°f.

Do not install the camera near a magnetic field or a high-

power motor.

Do not mount the camera near a radiator or heater.

The installation site and material must fully support the

weight of the product.

Only use a dry cloth to clean the camera. If there is dirt that is

difficult to remove wipe gently with a mild detergent. Never

use strong or abrasive detergents.

A 12VDC power supply must be used. Using an AC or other

incorrect power supply will damage the camera.

Only qualified installers are allowed to install and test the

camera.

The camera is a low voltage product. If installed outdoors

proper safety and lightning grounding are required.

Be sure the grounding, wiring, input power, and voltage are

correctly set prior to powering up and using.

Making Connections

1. Connect the DC power supply cable to the camera’s power

connector.

2. Connect the camera to the CVR with a 75Ω coaxial video

cable.

3. Connect power supply’s AC plug to a suitable AC power

outlet.

ST-HD-D2812M-2MP

Zoom & Focus

The ST-HD-D2812M-2MP features motorized zoom and focus, and is

controlled from the CVR via COC (control over coax).

Using the on-screen PTZ controller of the CVR, press the ZOOM -/+

buttons to reach the desired level of zoom. The camera will then auto-

focus. If fine-tuning of focus is necessary, press the FOCUS -/+ buttons

until the desired focus is achieved.

Switching to Analog Output

If SD (standard definition) analog output is desired, disconnect power

from the camera, then connect the labeled brown and white wires on

the camera to each other before powering the camera back on.

To switch back to HD-CVI output, disconnect power from the camera,

and disconnect the labeled brown and white wires on the camera

from each other before powering the camera back on.

On-Screen Display

To enter the OSD, click the MENU OPEN button on the CVR’s on-

screen PTZ controller, then click ENTER. Navigate the OSD using the

PTZ controller’s up, down, left, and right arrows. Confirm selections by

pressing ENTER.

Troubleshooting

Issue

Solution

No picture after applying

power.

(1) Check that all plugs and cables are securely connected

to the proper connectors.

(2) Ensure that the power supply is providing the correct

voltage and current.

Picture is consistently

tinted or distorted.

(1) Check that the coaxial video cable from the camera to

the CVR is securely connected at both ends.

(2) Connect the camera to an alternate working coaxial

video cable between the camera and CVR.

(3) Re-terminate the coaxial video cable between the

camera and CVR with new BNC connectors.

Picture has ripples or

rolling lines.

(1) Check to see if the power supply is experiencing AC

ripple; if so, a filter may be required. (2) Determine if the

monitor is faulty. (3) Determine if other peripheral

equipment is causing ripple, and if so, make the necessary

adjustments.

The picture is tinted /

continuously changing

Colors.

Fluorescent lights’ magnetic field may cause color roll. (1)

Check that the coaxial video cable between the camera

and CVR is not too close to fluorescent lights; increase

distance as needed. (2) Reduce the number of fluorescent

lights near the camera.

For further assistance and troubleshooting, please contact

SecurityTronix tech support at:

(800) 688-9282, press 3for Tech Support, then press 2for CCTV.

Version 1.2 (4/10/15)
