SCHUNK NST3 series Instrucciones de uso

Translation of Original Operating Manual

VERO-S quick-change pallet system

NST3

Assembly and Operating Manual

Superior Clamping and Gripping

Imprint

01.00|1344367_NST3 |en

Imprint

This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights

reserved. Any reproduction, processing, distribution (making available to third parties),

translation or other usage - even excerpts - of the manual is especially prohibited and

requires our written approval.

Technical changes:

We reserve the right to make alterations for the purpose of technical improvement.

Document number: 1344367

Version: 01.00 |13/05/2019|en

Dear Customer,

thank you for trusting our products and our family-owned company, the leading

technology supplier of robots and production machines.

Our team is always available to answer any questions on this product and other solutions.

Ask us questions and challenge us. We will find a solution!

Best regards,

Your SCHUNK team

H.-D. SCHUNK GmbH & Co.

Spanntechnik KG

Lothringer Str. 23

D-88512 Mengen

Tel. +49–7572-7614-0

Fax +49-7572-7614-1099

[email protected]

schunk.com

Table of Contents

01.00|1344367_NST3 |en

Table of Contents

General .................................................................................................................... 5

1.1

About this manual .................................................................................................... 5

1.1.1

Presentation of Warning Labels.................................................................... 5

1.1.2

Applicable documents................................................................................... 6

1.1.3

Sizes............................................................................................................... 6

1.2

Warranty................................................................................................................... 6

1.3

Scope of delivery ...................................................................................................... 6

1.4

Accessories ............................................................................................................... 7

Basic safety notes .................................................................................................... 8

2.1

Intended use............................................................................................................. 8

2.2

Not intended use ...................................................................................................... 8

2.3

Constructional changes ............................................................................................ 8

2.4

Spare parts................................................................................................................ 9

2.5

Environmental and operating conditions................................................................. 9

2.6

Personnel qualification............................................................................................. 9

2.7

Personal protective equipment.............................................................................. 10

2.8

Notes on safe operation......................................................................................... 11

2.9

Transport ................................................................................................................ 11

2.10

Malfunctions........................................................................................................... 12

2.11

Disposal................................................................................................................... 12

2.12

Fundamental dangers............................................................................................. 12

2.12.1

Protection during handling and assembly .................................................. 13

2.12.2

Protection during commissioning and operation ....................................... 13

2.12.3

Protection against dangerous movements................................................. 14

2.12.4

Notes on particular risks ............................................................................. 14

Technical data ......................................................................................................... 18

Assembly................................................................................................................. 19

4.1

General Installation Notes...................................................................................... 19

4.2

Aligning the clamping station................................................................................. 19

4.2.1

Alignment using T-nuts ............................................................................... 19

4.2.2

Alignment using alignment elements ......................................................... 20

4.3

Mounting and connecting the clamping station .................................................... 21

4.3.1

NST3 400-250 .............................................................................................. 23

4.3.2

NST3 500-300 .............................................................................................. 24

4.4

Clamping pins SPA 40, SPB 40, SPC 40, SPG 40 ...................................................... 26

4.4.1

Information to clamping pin SPG 40........................................................... 28

Table of Contents

01.00|1344367_NST3 |en

4.5

VERO-S tombstones (optional)............................................................................... 29

4.6

Screw tightening torques ....................................................................................... 30

Function .................................................................................................................. 31

5.1

Connections on the clamping station..................................................................... 31

5.2

Unlocking connection ............................................................................................. 32

5.3

TURBO connection ................................................................................................. 33

5.4

VERO-S connecting strip ASL2-G1/8” (optional) .................................................... 34

Operation................................................................................................................ 35

Maintenance and care ............................................................................................. 36

7.1

Leak test.................................................................................................................. 37

Troubleshooting ...................................................................................................... 38

8.1

The clamping areas do not unlock ......................................................................... 38

8.2

The clamping areas do not unlock perfectly .......................................................... 38

8.3

The quick-change pallet systems no longer open quietly...................................... 38

Parts lists................................................................................................................. 39

9.1

Part lists .................................................................................................................. 39

Assembly drawing ................................................................................................... 40

Translation of original declaration of incorporation ................................................. 41

Appendix on Declaration of Incorporation, as per 2006/42/EC, annex II, No. 1 B ..... 42

General

01.00|1344367_NST3 |en

General

About this manual

This manual contains important information for a safe and

appropriate use of the product.

This manual is an integral part of the product and must be kept

accessible for the personnel at all times.

Before starting work, the personnel must have read and

understood this operating manual. Prerequisite for safe working is

the observance of all safety instructions in this manual.

Illustrations in this manual are provided for basic understanding

and may differ from the actual product design.

In addition to these instructions, the documents listed under

(1.1.2, Page 6) are applicable.

Presentation of Warning Labels

To make risks clear, the following signal words and symbols are

used for safety notes.

DANGER

Danger for persons!

Non-observance will inevitably cause irreversible injury or death.

WARNING

Dangers for persons!

Non-observance can lead to irreversible injury and even death.

CAUTION

Dangers for persons!

Non-observance can cause minor injuries.

NOTICE

Material damage!

Information about avoiding material damage.

1.1

1.1.1

General

01.00|1344367_NST3 |en

Applicable documents

•General terms of business*

•Catalog data sheet of the purchased product *

•Assembly and Operating Manual for VERO-S quick-change

pallet system NSE3 *

•Assembly and Operating Manual for VERO-S tombstone VAT /

VAT3 *

The documents marked with an asterisk (*) can be downloaded on

our homepage schunk.com

Sizes

This operating manual applies to the following sizes:

Clamping station

•NST3 400-250

•NST3 500-300

Warranty

The warranty period is 24 months after delivery date from factory

or 500 000 cycles*, if it is used as intended, under the following

conditions:

•Observe the applicable documents, (1.1.2, Page 6)

•Observe the ambient conditions and operating conditions,

(2.5, Page 9)

•Observance of the specified care and maintenance instructions

(7, Page 36)

Parts touching the workpiece and wear parts are not included in

the warranty.

* A cycle consists of a complete clamping procedure ("opening"

and "closing" of the simultaneously actuated clamping modules on

the clamping station).

Scope of delivery

The scope of delivery includes

•Clamping station in the version ordered

•Accessory pack

NST3 400-250: 2 sealing rings G1/8“, 2 sealing nipples G1/8“

NST 500-300: 2 sealing rings G1/8“, 2 sealing nipples G1/8“ NW

7.4, 2 eye bolts M12, bore hole cover plate

1.1.2

1.1.3

1.2

1.3

General

01.00|1344367_NST3 |en

Accessories

(see catalog or data sheets when ordering separately)

•VAT-AE, VAT-DR, VAT-DW, VAT3-AE, VAT3-DR, VAT3-DW

tombstones

•SAT tombstones

•SAT NSF plus tombstones

•SPA, SPB, SPC, SPG clamping pins

•SDE protection cover

•ASL2-G1/8“ connecting strip

•VSK Ø10-NW7.4 locking coupling for air supply

•Torque wrench

1.4

Basic safety notes

01.00|1344367_NST3 |en

Basic safety notes

Intended use

This product is intended solely for positioning and clamping

tombstones or clamping pallets on machine tools or other suitable

technical devices.

•The product may only be used within the scope of its technical

data, (3, Page 18).

•The product is intended for industrial and industry-oriented

use.

•Appropriate use of the product includes compliance with all

instructions in this manual.

Not intended use

The product is not being used as intended if, for example:

•It is used as a pressing tool, a toolholder, a load-handling device

or as lifting equipment.

•It is used for turning applications over 100 rpm without

consulting SCHUNK.

•It is used in working environments that are not permissible.

•People work on machines or technical equipment that do not

comply with the EC Machinery Directive 2006/42/EC,

disregarding the applicable safety regulations.

•The technical data specified by the manufacturer are exceeded

during usage.

Constructional changes

Implementation of structural changes

By conversions, changes, and reworking, e.g. additional threads,

holes, or safety devices can impair the functioning or safety of the

product or damage it.

•Structural changes should only be made with the written

approval of SCHUNK.

2.1

2.2

2.3

Basic safety notes

01.00|1344367_NST3 |en

Spare parts

Use of unauthorized spare parts

Using unauthorized spare parts can endanger personnel and

damage the product or cause it to malfunction.

•Use only original spare parts or spares authorized by SCHUNK.

Environmental and operating conditions

Required ambient conditions and operating conditions

Incorrect ambient and operating conditions can make the product

unsafe, leading to the risk of serious injuries, considerable material

damage and/or a significant reduction to the product's life span.

•Make sure that the product is used only in the context of its

defined application parameters, (3, Page 18).

•Make sure that the product is a sufficient size for the

application.

•Make sure that the contact surfaces of the interface are always

clean.

•Make absolutely sure that no chips of any kind can enter the

interface and that the interface fills with cooling emulsion,

which is particularly possible with a horizontal design of the

clamping station. The best way to ensure both of these

requirements is to use the SDE protection covers. If the

interface should fill with cooling emulsion, initiate the

unlocking process and allow the interface to dry out in an

actuated state or carefully blow out with compressed air using

suitable protective equipment.

•Only use high-quality cooling emulsions with anti-corrosive

additives during processing.

Personnel qualification

Inadequate qualifications of the personnel

If the personnel working with the product is not sufficiently

qualified, the result may be serious injuries and significant

property damage.

•All work may only be performed by qualified personnel.

•Before working with the product, the personnel must have read

and understood the complete assembly and operating manual.

•Observe the national safety regulations and rules and general

safety instructions.

2.4

2.5

2.6

Basic safety notes

01.00|1344367_NST3 |en

The following personal qualifications are necessary for the various

activities related to the product:

Due to its technical training, knowledge and experience, qualified

personnel is able to perform the delegated tasks, recognize and

avoid possible dangers and knows the relevant standards and

regulations.

Instructed persons were instructed by the operator about the

delegated tasks and possible dangers due to improper behaviour.

Due to its technical training, knowledge and experience, service

personnel of the manufacturer is able to perform the delegated

tasks and to recognize and avoid possible dangers.

Personal protective equipment

Use of personal protective equipment

Personal protective equipment serves to protect staff against

danger which may interfere with their health or safety at work.

•When working on and with the product, observe the

occupational health and safety regulations and wear the

required personal protective equipment.

•Observe the valid safety and accident prevention regulations.

•Wear protective gloves to guard against sharp edges and

corners or rough surfaces.

•Wear heat-resistant protective gloves when handling hot

surfaces.

•Wear protective gloves and safety goggles when handling

hazardous substances.

•Wear close-fitting protective clothing and also wear long hair in

a hairnet when dealing with moving components.

Qualified personnel

Instructed person

Service personnel of

the manufacturer

2.7

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Herramientas eléctricas de SCHUNK

SCHUNK

SCHUNK LMG 64 Instrucciones de uso

SCHUNK

SCHUNK TANDEM KSPplus-BWM Instrucciones de uso

SCHUNK

SCHUNK GSP-P 08 Instrucciones de uso

SCHUNK

SCHUNK TANDEM KSH plus Instrucciones de uso

SCHUNK

SCHUNK KSP3-IM 100 Instrucciones de uso

SCHUNK

SCHUNK VERO-S WDM-5X Instrucciones de uso

SCHUNK

SCHUNK PRONTO Instrucciones de uso

SCHUNK

SCHUNK KSO 65 Guía del usuario

SCHUNK

SCHUNK PGF Instrucciones de uso

SCHUNK

SCHUNK DWG 100 Guía de configuración

SCHUNK

SCHUNK PGN-plus-E Series Manual de reparación

SCHUNK

SCHUNK RST-P 060 Instrucciones de uso

SCHUNK

SCHUNK iTENDO2 pad Instrucciones de uso

SCHUNK

SCHUNK TANDEM KSH3 IM 100 Instrucciones de uso

SCHUNK

SCHUNK PZH-plus 30 Instrucciones de uso

SCHUNK

SCHUNK KSC2 40 Manual de usuario

SCHUNK

SCHUNK KSC-D 80 Guía del usuario

SCHUNK

SCHUNK KSX-C Guía del usuario

SCHUNK

SCHUNK TRIBOS SVP-Mini auto Instrucciones de uso

SCHUNK

SCHUNK VERO-S NSE mini 90-25 Instrucciones de uso

SCHUNK

SCHUNK PGB Series Instrucciones de uso

SCHUNK

SCHUNK TANDEM KSF plus Series Instrucciones de uso

SCHUNK

SCHUNK DWG 100 Guía de configuración

SCHUNK

SCHUNK ROTA NCO 165 Manual de usuario

Manuales populares de Herramientas eléctricas de otras marcas

AEG

AEG OMNI-JS Manual de usuario

SIP

SIP 01533 Manual de usuario

Ribimex

Ribimex PRS499 Manual de usuario

3M Fiber Optic Connector Crimp Tool Manual de usuario

Ryobi

Ryobi P524 Manual de usuario

ROJEK

ROJEK FSN 300A Manual de usuario

Kemper

Kemper 1740PRO Manual de usuario

WABCO

WABCO OptiTire Manual de usuario

EINHELL

EINHELL TE-MS 18/210 Li Manual de usuario

Orgapack

Orgapack OR-T 85 Guía rápida

TOUGHCUT

TOUGHCUT Diamond 400 Manual de usuario

Yaros

Yaros PB-3603 Manual de usuario

Fein

Fein BSS 2.0 E Guía de configuración

Baileigh Industrial

Baileigh Industrial SS-2725 Manual de usuario

Milwaukee

Milwaukee 2674-20 Manual de usuario

Fein

Fein BLs 1.6 Manual de usuario

Princess

Princess Electric Multi Sharpener Manual de usuario

FOREDOM

FOREDOM K.1050 Manual
