Samsung SyncMaster 320P Guía de instalación

대외비

보 존 기 한 3 년

SyncM aster 320P (LBE32PS)

Training M anual

SAMSUNG ELECTRONICS CO.,LTD

Visual Display Division

LCD Monitor Group

Index

Overview

Introduction

Block Diagram

M ain Board Part

Service Board Part

Troubles ooting

DD C Entry

W at To D o after Board Replacement

Overview

1. Background of Development

▶To introduce into airports, cinemas, and ot er public facilities, w ere PDPs

are currently predominant

▶ To create a new market using t e advantages of LCD Monitors

▶To address standardization/officialization by enabling distribution to all regions of a

single model aving no local derivation

▶ To expand t e large LCD product market

Overview

2. Product Features

▶ VMB (Vertical Marketing Business) Model

▶MFM ( (Multi Function Monitor) :

Receives diverse support ot er t an PC (DVI, AV, S- video, Component)

▶ Response Time 8ms PVA adopted

▶ Sound function reinforced by adopting Dolby Virtual, BBE

▶ Picture quality en anced by adopting DNIe, Digital Noise Reduction

▶ RS232 Remote Control (MDC software provided)

▶ Video input: PC(D_SUB,DVI), BNC, DVI, Component, AV, S- Video

▶ Audio input: PC(D_SUB,DVI) Stereo, Video (AV, S- Video), Component, BNC

▶ Image & sound output: PC, BNC, AV, S- Video, Component out, speaker out

▶ 10W x 2 built- in speaker

▶PIP automatic switc timer function: PIP automatically pops- up w en setting time

▶ PIP, OSD menu transparency control

▶ Sleep timer (automatic switc - off) function

▶Wall & Ceiling Mounting (Optional VESA Wall Mount Kit)

▶ Network function supported

BBE (Barcus- Berry Electronics)

Sounds are clearer and finely detailed.

Bass sounds are amplified, but original

sound is recreated wit more clarity and

definition.

Overview

3. Specifications

BE40PS

M del Name SyncMaster 320P

Panel AMLCD 32” ( LTA320W2- L01)

Opt i mum Res l ut i n 1366x 768 (WXGA) 60Hz

Di s pl ay Si ze 32” (16:9)

Br i ght nes s 450cd/m2

C nt r as t Rat i 1000:1

Res p ns e Ti me 8 ms

Vi ewi ng Angl e Left/Rig t/Up/Down : 89/89/89/89

PC I nput D- SUB, DVI

Vi de Sys t em AV, S- Video, Component

P wer C ns umpt i n Less t an 180 W Max.

DPMS Less t an 5 W

S und Out put Max. 10W x 2

Introduction

Introduction(Front)

(Front)

MENU :

Use this button to open the on-screen menu and exit from the menu screen or

close screen adjustment menu.

Up/Down button :

Moves from one menu item to another vertically or adjusts selected menu

values.

Adjust / Volume button :

Moves from one menu item to another horizontally or adjusts selected menu

values. Also adjusts the audio volume.

EN ER :

Activates a highlighted menu item.

SOURCE:

Switches from C mode to Video mode.

Changing the source is allowed only in external devices that are connected to the

monitor at the time. To switch Screen modes:

[ C] -> [BNC] -> [DVI] -> [AV] -> [S-Video] -> [Component]

PIP :

ush the I button to turn I screen On/Off.

More than one I couldn't be overlapped on screen as BNC and the component

use the same terminal.

PC / DVI : AV / S-Video / Component Mode

• BNC: AV / S-Video Mode

• AV / S-Video : C / BNC / DVI Mode

•Component: PC / DVI Mode

POWER: Use this button to turn the monitor on and off.

LED: ower Indicator shows owerSaver mode by green blinking.

Remote Control Sensor: Aim the remote control towards this spot on the

Monitor.

Vie ing the Control Panel

1. MENU 6. PIP

2. Navigate button (Up-Do n button) 7. Po er button

3. Adjust button (Left-Right button)/ Volume button 8. Po er indicator

4. ENTER 9. Remote Control Sensor

5. SOURCE

Introduction

Introduction(Rear)

(Rear)

Vie ing the Connection Panel

Rear

1. RS232C OUT/IN(RS232C Serial Port):

MDC(Multiple Device Control) rogram ort

2. DVI IN(HDCP) (PC Video Connection Ter inal)

: Using DVI Cable (DVI-D to DVI-D)

- DVI mode (Digital C)

3. PC IN(RGB) (PC Video Connection Ter inal)

: Using D-Sub Cable (15 pin D-Sub) - C mode

(Analog C)

4. PC/DVI/BNC AUDIO IN (PC/DVI/BNC Audio

Connection Ter inal (Input))

BNC COMPONENT

5. COMPONENT AUDIO IN [L-AUDIO-R]

(Co ponent Audio Connection Ter inal (Input))

6. BNC/COMPONENT OUT

(BNC/Co ponent Connection Ter inal (Output))

- BNC (Analog PC) Connection :

connecting R, G, B, H, V port

- Co ponent Connection : connecting R, Y, b port

7. BNC/Component IN

(BNC/Co ponent Connection Ter inal (Input))

Vie ing the Connection Panel

Rear

Introduction

Introduction(Rear)

(Rear)

15. POWER S/W

16. POWER IN

17. Kensington Lock

he Kensington lock is a device used to physically fix the

system when using it in a public place.

( he locking device has to be purchased separately.) AV EXT SPEAKER

8.AV AUDIO IN [L-AUDIO-R]

(Monitor Audio Connection Ter inal (Input))

9.AV OUT [VIDEO](VIDEO Connection Ter inal) :

AV mode (Output)

10.AV IN [VIDEO](VIDEO Connection Ter inal)

(Input)

11. AV OUT [S-Video](S-Video Connection Ter inal):

S-Video mode (Output)

12.AV IN [S-Video](S-Video Connection Ter inal)

(Input)

13.EXT SPEAKER(8 Ω) (EXT Speaker Connection

Ter inal)

14.MONITOR [L-AUDIO-R] (Monitor Audio Connection

Ter inal (Output))

- MONITOR OUT is the terminal for sound output of C,

DVI or BNC.

Unpacking

15pi n D- s ub cabl e BN39-00244B

Speaker Wi r e cabl eBN39-00315A =

Adapt r C nnect r 3705-001262

Remote Control BN59-00464A

Accessories

Accessories(Sold Separately)

Unpacking
