Samsung SyncMaster 403Tn Manual de usuario

Install Pro

rams

SyncMaster 403Tn

Failure to follow directions noted by this symbol could result in bodily harm or damage to

equipment.

Prohibited Important to read and understand at all times

Do not disassemble Disconnect the plug from the outlet

Do not touch Grounding to prevent an electric shock

Power

When not used for an extended period of time, set your computer to DPMS.

If using a screen saver, set it to the active screen mode.

Do not use a damaged or loose plug.

zThis may cause an electric shock or fire.

Do not pull the plug out by the wire nor touch the plug with wet hands.

zThis may cause an electric shock or fire.

Use only a properly grounded plug and receptacle.

zAn improper ground may cause electric shock or equipment damage.

Do not excessively bend the plug and wire nor place heavy objects upon them,

which could cause damage.

zThis may cause an electric shock or fire.

Do not connect too many extension cords or plugs to an outlet.

zThis may cause fire.

Installation

Put your monitor in a location with low humidity and a minimum of dust.

zFailure to do so may cause an electric shock or fire inside the monitor.

Do not drop the monitor when moving it.

zThis may cause damage to the product or human body.

Place the monitor on a flat and stable surface.

zThe monitor may cause injury by falling.

Set down the monitor carefully.

zThe monitor could be damaged or broken.

Do not place the monitor face down.

zThe TFT-LCD surface may be damaged.

Installing a wall bracket must be done by a qualified professional.

zInstallation by unqualified personnel may result in injury.

zAlways use the mounting device specified in the owner's manual.

Leave a space for ventilation between the product and the wall.

zPoor ventilation may cause the interior temperature to rise and lead to fire.

Clean

When cleaning the monitor case or the surface of the TFT-LCD screen, wipe with a

slightly moistened, soft fabric.

Do not spray water or detergent directly on the monitor.

zThis may cause damage, electric shock or fire.

Use the recommended detergent with a smooth cloth.

If the connector between the plug and the pin is dusty or dirty, clean it properly

with a dry cloth.

zA dirty connector may cause an electric shock or fire.

Contact the Service Center or Customer Center for interior cleaning once a

year.

zKeep the product's interior clean. Dust which has accumulated in the interior

over an extended period of time may cause malfunction or fire.

Others

Do not remove cover (or back).

zThis may cause an electric shock or fire.

zRefer servicing to qualified service personnel.

If your monitor does not operate normally - in particular, if there are any

unusual sounds or smells coming from it - unplug it immediately and

contact an authorized dealer or service.

zThis may cause an electric shock or fire.

Be careful not to let water drip into the monitor or expose the monitor to

moisture.

zThis may cause malfunction, an electric shock or fire.

zEspecially avoid operating the monitor near water or outdoors where it could

be exposed to snow or rain.

If the monitor is dropped or the casing is damaged, turn the monitor off and

unplug the power cord.

zThe monitor may malfunction, causing an electric shock or fire.

zThen contact the Service Center .

Disconnect the plug from the outlet during storms or lightening or if it is not

used for a long period of time.

zFailure to do so may cause an electric shock or fire.

Do not try to move the monitor by pulling only the wire or the signal cable.

zThis may cause a breakdown, electric shock or fire due to damage to the

cable.

Do not move the monitor right or left by pulling only the wire or the signal

cable.

zThis may cause a breakdown, electric shock or fire due to damage to the

cable.

Do not cover the vents on the monitor cabinet.

zBad ventilation may cause a breakdown or fire.

Do not place water containers, chemical products or small metal objects on

the monitor.

zThis may cause malfunction, an electric shock or fire.

zIf a foreign substance enters the monitor, unplug the power cord and

contact the Service Center.

Do not use or store inflammable substances near the monitor.

zThis may cause an explosion or fire.

Never insert anything metallic into the monitor openings.

zThis may cause an electric shock, fire or injury.

Do not insert metal objects such as utensils, wire or drill bits, or things that

catch fire easily, such as pieces of paper or matches, into the vents or the

headphone or A/V ports on the monitor.

zThis may cause malfunction, an electric shock or fire.

zAlways contact the Service Center if foreign substances/objects enter into

the monitor.

If you view a fixed screen for an extended period of time, residual image or

blurriness may appear.

zChange the mode to energy save or set a screensaver to moving picture

when you need to be away from the monitor for an extended period of time.

Be careful when adjusting the stand angle.

zApplying too much force may cause the monitor topple over or fall, resulting

in injury.

zYour hand or finger(s) may get caught between the monitor and the stand,

causing injury.

Adjust the resolution and frequency to the levels appropriate for the model.

zInappropriate resolution may cause undesirable picture quality.

40 inch - 1280 X 768

Sitting too close to the monitor on a continuous basis may damage

eyesight.

To ease eye strain, take at least a five-minute break after every hour of using

the monitor.

Do not use the monitor where it may be exposed to strong vibrations.

zExposure to strong vibrations may be fire hazard and shorten the life of the

monitor.

When moving the monitor, turn the power switch off and unplug the power

cord.

Make sure that all cables, including the antenna cable and cables connected

devices, are disconnected before moving the monitor.

zFailure to disconnect cables may damage it and lead to fire or an electric

shock.

When you remove batteries from the remote, be careful that they are not

swallowed by children. Keep batteries out of the reach of children.

zIf swallowed, see a doctor immediately.

When replacing batteries, place the batteries in the correct +/- polarity

position as indicated on battery holder.

zIncorrect polarity may cause a battery to break or leak and could lead to fire,

injury, or contamination (damage).

Use only specified standard batteries. Do not use new and used batteries

together.

zThis may cause a battery to break or leak and could lead to fire, injury, or

contamination (damage).

Please make sure the following items are included with your monitor.

If any items are missing, contact your dealer.

Contact a local deale

to bu

tional items.

Unpacking

Monitor

Manual

Quick Setup Guide Warranty Card

(Not available in all locations)

User's Guide, MDC software,

Natural Color software,

icNet software

Cable

D-Sub Cable Power Cord RS232C Cable

LAN Cable

Sold se

aratel

Wall Mount KIT S

eaker Set Stand KIT

Bracket VESA Bracket Screw (22EA)

MACHINE : M5 x L22

DVI Cable

Others

Remote Control Batteries

(

AAA X 2

)

Cove

-hole

BNC to RCA

Ada

ter

ack Semi Stand Screw (4EA)

MACHINE : M4 x L15

Front

1. MENU 6. PIP

2. Navigate button (Up-Down button) 7. Power button

3. Adjust button (Left-Right button)/

Volume button

8. Power indicator

4. ENTER 9. Remote Control Sensor

5. SOURCE

1. MENU

Use this button to open the on-screen menu and exit from the menu screen or close screen

adjustment menu.

2. Navigate button (Up-Down button)

Moves from one menu item to another vertically or adjusts selected menu values.

3. Adjust button (Left-Right button) / Volume button

Moves from one menu item to another horizontally or adjusts selected menu values.

Also adjusts the audio volume.

4. ENTER

Activates a highlighted menu item.

5. SOURCE

Switches from PC mode to Video mode.

Changing the source is allowed only in external devices that are connected to the monitor

at the time.

To switch Screen modes:

[PC] [BNC] [DVI] [AV] [S-Video] [Component] [MagicNet]

>>Click here to see an animation clip

6. PIP

Push the PIP button to turn PIP screen On/Off.

More than one PIP couldn't be overlapped on screen as BNC and the component use the

same terminal.

>>Click here to see an animation clip

• PC / DVI

: AV / S-Video / Component Mode

• BNC

: AV / S-Video Mode
