Samsung S24C650PLS Manual de usuario

User manual

S22C650D

S22C650K

S23C650D

S23C650K

S24C650PL

S24C650PLS

S27C650D

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00301A-07

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Symbols

11 Electricity and Safety

12 Installation and Safety

14 Operation and Safety

17 Correct posture to use the product

PREPARATIONS 18 Checking the Contents

18 Removing the Packaging

19 Checking the Components

20 Parts

20 Frontal Buttons

22 Reverse Side

24 Right Side View

25 Installation

25 Attaching the Stand

26 Adjusting the Product Tilt and Height

26 Rotating the Monitor

27 Installing a Wall-mount Kit or Desktop Stand

28 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

29 Before Connecting

29 Pre-connection Checkpoints

29 Connecting the Power

Table Of Contents

Table Of Contents 3

30 Connecting and Using a PC

30 Connecting to a PC

37 Driver Installation

38 Setting Optimum Resolution

39 Changing the Resolution Using a PC

SCREEN SETUP 43 Brightness

43 Configuring Brightness

44 Contrast

44 Configuring Contrast

45 Sharpness

45 Configuring Sharpness

46 SAMSUNG MAGIC Bright

46 Configuring SAMSUNG MAGIC Bright

48 Image Size

48 Changing the Image Size

50 HDMI Black Level

50 Configuring the HDMI Black Level Settings

51 Response Time

51 Configuring Response Time

52 H-Position & V-Position

52 Configuring H-Position & V-Position

53 Coarse

53 Adjusting Coarse

54 Fine

54 Adjusting Fine

CONFIGURING TINT 55 Red

55 Configuring Red

56 Green

56 Configuring Green

Table Of Contents

Table Of Contents 4

57 Blue

57 Configuring Blue

58 Color Tone

58 Configuring the Color Tone Settings

59 Gamma

59 Configuring Gamma

RESIZING OR

RELOCATING THE

SCREEN

60 Language

60 Changing the Language

61 Menu H-Position & Menu V-Position

61 Configuring Menu H-Position & Menu V-

Position

62 Display Time

62 Configuring Display Time

63 Transparency

63 Changing Transparency

SETUP AND RESET 64 Reset

64 Initializing Settings (Reset)

65 Eco Saving

65 Configuring Eco Saving

66 Off Timer

66 Configuring Off Timer

67 Turn Off After

67 Configuring Turn Off After

68 PC/AV Mode

68 Configuring PC/AV Mode

70 Key Repeat Time

70 Configuring Key Repeat Time

71 Source Detection

71 Configuring Source Detection

Table Of Contents

Table Of Contents 5

72 Customized Key

72 Configuring Customized Key

INFORMATION MENU AND

OTHERS

73 INFORMATION

73 Displaying INFORMATION

74 Configuring Brightness and Contrast in

the Initial Screen

75 Configuring Volume in the Initial Screen

INSTALLING THE

SOFTWARE

76 Magic Tune

76 What is MagicTune?

76 Installing the Software

77 Removing the Software

78 MultiScreen

78 Installing the Software

79 Removing the Software

80 MagicRotation

80 Installing the Software

82 Removing the Software

TROUBLESHOOTING

GUIDE

83 Requirements Before Contacting

Samsung Customer Service Center

83 Testing the Product

83 Checking the Resolution and Frequency

83 Check the following.

86 Q & A

SPECIFICATIONS 88 General

94 PowerSaver

95 Standard Signal Mode Table

APPENDIX 103 Contact SAMSUNG WORLD WIDE

Table Of Contents

Table Of Contents 6

109 Responsibility for the Pay Service (Cost

to Customers)

109 Not a product defect

109 A Product damage caused by customer's fault

109 Others

110 Correct Disposal

110 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

111 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 103) if the inside of the monitor needs

cleaning. (Service fee will be charged.)

3.93

inches

(10 cm)

3.93

inches

(10 cm)

3.93 inches(10 cm)

Before Using the Product

Safety Precautions

Symbols

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance

has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution Personal injury or damage to properties may result if instructions are not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.
