SyncMaster 400UXn,460UXn
LCD Monitor
User Manual
Introduction
-- 400UXn --
Package Contents
Note
Please make sure the following items are included with your LCD Display.
If any items are missing, contact your dealer.
Contact a local dealer to buy optional items.
Note
This stand is not for the Floor Standing Type.
Unpacking
LCD Display
Manuals
Quick Setup Guide Warranty Card
(Not available in all loca-
tions)
User's Guide
Cables
D-Sub Cable Power Cord
Others
Remote Control Batteries (AAA X 2)
(Not available in all loca-
tions)
BNC to RCA Adaptor Jack
Sold separately
DVI Cable Wall Mount KIT Semi Stand KIT
Calibrater
BNC Cable LAN Cable For more information on the
use of the calibrater, see Nat-
ural Color Expert Help.
-- 400UXn --
Your LCD Display
Front
MENU button [MENU]
Introduction
Opens the on-screen menu and exits from the menu. Also use to exit the OSD menu
or return to the previous menu.
Navigate buttons (Up-Down buttons)
Moves from one menu item to another vertically or adjusts selected menu values.
Adjust buttons (Left-Right buttons) / Volume buttons
Moves from one menu item to another horizontally or adjusts selected menu val-
ues. When OSD is not on the screen, push the button to adjust volume.
ENTER button [ENTER]
Activates a highlighted menu item.
SOURCE button [SOURCE]
Switches from PC mode to Video mode. Changing the source is only allowed for
external devices that are connected to the LCD Display at the time.
[PC] → [BNC] → [DVI] → [AV] → [S-Video] → [Component] → [HDMI]
→ [MagicInfo]
>> Click here to see an animation clip
PIP
Push the PIP button to turn the PIP screen On / Off.
More than one PIP cannot overlap on screen as BNC and the component use the
same terminal.
>> Click here to see an animation clip
•PC
AV / S-Video / Component / HDMI Mode
•BNC
AV / S-Video / HDMI Mode
•DVI
AV / S-Video / Component Mode
•AV / S-Video
PC / BNC / DVI Mode
•Component
PC / DVI Mode
•HDMI
PC / BNC Mode
Power button [ ]
Use this button for turning the LCD Display on and off.
Power indicator
Shows PowerSaver mode by blinking green
Introduction
Note
See PowerSaver described in the manual for further information regarding power
saving functions. For energy conservation, turn your LCD Display OFF when it
is not needed or when leaving it unattended for long periods.
Remote Control Sensor
Aim the remote control towards this spot on the LCD Display.
Rear
Note
For detailed information concerning cable connections, refer to Connecting Cables under Setup. The
LCD Display 's configuration at the back may vary slightly depending on the LCD Display model.
POWER S/W ON [ │ ] / OFF [O]
Switches the LCD Display On/Off.
POWER IN
The power cord plugs into the LCD Display and
the wall plug.
Introduction
REMOTE OUT/IN
You can use a wired remote control by connecting
it to your LCD Display.
RS232C OUT/IN (RS232C Serial PORT)
MDC(Multiple Display Control) Program Port
DVI / PC / HDMI IN [PC/DVI/BNC AUDIO
IN] (PC/DVI/BNC/HDMI Audio Connection Ter-
minal (Input))
DVI / PC / HDMI IN [HDMI]
Connect the HDMI terminal at the back of your
LCD Display to the HDMI terminal of your dig-
ital output device using a HDMI cable.
DVI / PC / HDMI IN [RGB](PC Video Con-
nection Terminal)
Using a D-Sub Cable (15 pin D-Sub) - PC mode
(Analog PC)
DVI / PC / HDMI IN [DVI(HDCP)] (PC
Video Connection Terminal)
Using a DVI Cable (DVI-D to DVI-D) - DVI
mode (Digital PC)
COMPONENT AUDIO IN [L-AUDIO-R]
(Component Audio Connection Terminal (Input))
BNC/COMPONENT OUT [R/PR, G/Y, B/
PB, H, V] (BNC/Component Connection Termi-
nal (Output))
BNC (Analog PC) Connection: connecting the R,
G, B, H, V ports
Component Connection: connecting the PR, Y,
PB ports
BNC/COMPONENT IN [R/PR, G/Y, B/PB,
H, V](BNC/Component Connection Terminal
(Input))
Introduction
AV AUDIO IN [L-AUDIO-R] (LCD Display
Audio Connection Terminal (Input))
AV OUT [VIDEO](VIDEO Connection Ter-
minal)
AV mode (Output)
AV IN [VIDEO](VIDEO Connection Termi-
nal) (Input)
AV OUT [S-VIDEO] (S-VIDEO Connection
Terminal)
S-VIDEO mode (Output)
AV IN [S-VIDEO](S-VIDEO Connection
Terminal) (Input)
EXT SPEAKER(8 Ω)[- - L - +, - - R - +] (EXT
Speaker Connection Terminal)
AUDIO OUT [L-AUDIO-R] (LCD Display
Audio Connection Terminal (Output))AUDIO
OUT is the terminal for sound output of PC, DVI
or BNC.
LAN (LAN Connection Terminal)
USB(USB Connection Terminal)
Keyboard / Mouse, Mass Storage Device Com-
patible.
Note
The number of LCD Displays that can be con-
nected to loopout may differ depending on the
cables, signal source etc. With cables where there
is no degradation or signal source, up to ten LCD
Displays can be connected.
Note
See Connecting Cables for further information regarding cable connections.
Introduction
-- 400UXn --
Remote Control
Note
The performance of the remote control may be affected by a TV or other electronic device operating
near the LCD Display , causing a malfunction due to interference with the frequency.
ON / OFF
MagicInfo
MDC
LOCK
MagicInfo buttons
+100 DEL
VOL
MUTE
TTX/MIX
MENU
ENTER
P.MODE
AUTO
ENTER/PRE-CH
CH/P
SOURCE
INFO
EXIT
Up-Down Left-Right buttons
S.MODE
STILL
FM RADIO
P.SIZE
SRS
DUAL/MTS
PIP
SOURCE
SWAP
SIZE
REW
Introduction
STOP
PLAY/PAUSE
FF
1. ON / OFF Turns the LCD Display On/Off.
2. MagicInfo MagicInfo Quick Launch Button.
3. MDC MDC Quick Launch Button.
4. LOCK Activates or deactivates all function keys on both the remote con-
trol and the LCD Display except for the Power and LOCK buttons.
5. MagicInfo buttons MagicInfo Quick Launch Button.
• Alphanumeric: Used to enter the Internet address.
• DEL: Functions as the backspace.
• SYMBOL: Used to enter the symbols. (.O_-)
• ENTER: Used to enter values.
6. +100 DEL Press to select channels over 100. For example, to select channel
121, press "+100", then press "2" and "1".
- This fuction does not work for this LCD Display.
7. VOL Adjusts the audio volume.
8. MUTE Pauses (mutes) the audio output temporarily. This is displayed on
the lower left corner of the screen. The audio resumes if MUTE
or - VOL + is pressed in the Mute mode.
9. TTX/MIX TV channels provide text information services via teletext.
- This fuction does not work for this LCD Display.
10. MENU Opens the on-screen menu and exits from the menu screen or
closes the screen adjustment menu.
11. ENTER Activates a highlighted menu item.
12. P.MODE When you press this button, current picture mode is displayed on
the lower center of the screen.
AV / S-Video / Component : P.MODE
The LCD Display has four automatic picture settings that are pre-
set at the factory. Then push button again to circle through avail-
able preconfigured modes. ( Dynamic → Standard → Movie
→ Custom )
PC / DVI / BNC : M/B (MagicBright)
MagicBright is a new feature providing the optimum viewing
environment depending on the contents of the image you are
Introduction
watching. Then push button again to circle through available pre-
configured modes. (Entertain → Internet → Text → Custom )
13. AUTO Adjusts the screen display automatically in PC mode. By changing
the resolution in the control panel, auto function is performed.
14. ENTER/PRE-CH Returns to the immediately previous channel.
- This fuction does not work for this LCD Display.
15. CH/P In TV mode, selects TV channels.
- This fuction does not work for this LCD Display.
16. SOURCE Changes the video source.
17. INFO The current picture information is displayed in the top left corner
of the screen.
18. EXIT Exits from the menu screen.
19. Up-Down Left-Right but-
tons
Moves from one menu item to another horizontally, vertically or
adjusts selected menu values.
20. S.MODE When pressing this button, the current mode is displayed at the
bottom centre of the screen. The LCD Display has a built-in high
fidelity stereo amplifier. Then press the button again to circle
through available preconfigured modes. ( Standard → Music
→ Movie → Speech → Custom )
21. STILL Press the button once to freeze the screen. Press it again to un-
freeze.
22. FM RADIO Turns the FM Radio on/off. In PC/DVI mode, sets the SOUND
to FM Radio. In general Video mode, selects FM Radio, and turns
off the screen. In areas where the signal is weak, noise may occur
during FM radio broadcasts.
- This fuction does not work for this LCD Display.
23. P.SIZE Press to change the screen size.
24. SRS SRS
25. DUAL/MTS DUAL-
STEREO/MONO, DUAL l / DUAL ll and MONO/NICAM
MONO/NICAM STEREO can be operated depending on the
broadcasting type by using the DUAL button on the remote control
while watching TV.
MTS-
You can select MTS (Multichannel Television Stereo) mode.
Audio Type MTS/S_Mode Default
FM Stereo Mono Mono Manual Change
Stereo Mono ↔ Stereo
SAP Mono ↔ SAP Mono
Introduction
