Samsung S19C450MW Manual de usuario

User manual

S19C450BW

S19C450MW

S19C450BR

S19C450MR

S20C450B

S22C450B

S22C450M

S22C450BW

S22C450MW

S23C450B

S23C450M

S24C450BL

S24C450B

S24C450M

S24C450BW

S24C450MW

S27C450B

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00294A-10

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

7 Symbols for safety precautions

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Electricity and Safety

11 Installation and Safety

13 Operation and Safety

16 Correct posture to use the product

PREPARATIONS 17 Checking the Contents

17 Removing the Packaging

18 Checking the Components

19 Parts

19 Frontal Buttons

21 Reverse Side

22 Installation

22 Attaching the Stand

23 Adjusting the Product Tilt and Height

23 Rotating the Monitor

24 Installing a Wall-mount Kit or Desktop Stand

25 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

26 Before Connecting

26 Pre-connection Checkpoints

26 Connecting the Power

Table Of Contents

Table Of Contents 3

27 Connecting and Using a PC

27 Connecting to a PC

30 Driver Installation

31 Setting Optimum Resolution

32 Changing the Resolution Using a PC

SCREEN SETUP 36 Brightness

36 Configuring Brightness

37 Contrast

37 Configuring Contrast

38 Sharpness

38 Configuring Sharpness

39 SAMSUNG MAGIC Bright

39 Configuring SAMSUNG MAGIC Bright

40 SAMSUNG MAGIC Angle

40 Configuring SAMSUNG MAGIC Angle

41 SAMSUNG MAGIC Upscale

41 Configuring SAMSUNG MAGIC Upscale

42 Image Size

42 Changing the Image Size

44 H-Position & V-Position

44 Configuring H-Position & V-Position

45 Coarse

45 Adjusting Coarse

46 Fine

46 Adjusting Fine

CONFIGURING TINT 47 Red

47 Configuring Red

48 Green

48 Configuring Green

Table Of Contents

Table Of Contents 4

49 Blue

49 Configuring Blue

50 Color Tone

50 Configuring the Color Tone Settings

51 Gamma

51 Configuring Gamma

RESIZING OR

RELOCATING THE

SCREEN

52 Language

52 Changing the Language

53 Menu H-Position & Menu V-Position

53 Configuring Menu H-Position & Menu V-

Position

54 Display Time

54 Configuring Display Time

55 Transparency

55 Changing Transparency

SETUP AND RESET 56 Reset

56 Initializing Settings (Reset)

57 Eco Saving

57 Configuring Eco Saving

58 Off Timer

58 Configuring Off Timer

59 Turn Off After

59 Configuring Turn Off After

60 PC/AV Mode

60 Configuring PC/AV Mode

61 Key Repeat Time

61 Configuring Key Repeat Time

62 Source Detection

62 Configuring Source Detection

Table Of Contents

Table Of Contents 5

63 Customized Key

63 Configuring Customized Key

INFORMATION MENU AND

OTHERS

64 INFORMATION

64 Displaying INFORMATION

65 Configuring Brightness and Contrast in

the Initial Screen

66 Configuring Volume in the Initial Screen

INSTALLING THE

SOFTWARE

67 Magic Tune

67 What is MagicTune?

67 Installing the Software

68 Removing the Software

69 MultiScreen

69 Installing the Software

70 Removing the Software

71 MagicRotation

71 Installing the Software

73 Removing the Software

TROUBLESHOOTING

GUIDE

74 Requirements Before Contacting

Samsung Customer Service Center

74 Testing the Product

74 Checking the Resolution and Frequency

74 Check the following.

77 Q & A

SPECIFICATIONS 79 General

91 PowerSaver

93 Standard Signal Mode Table

APPENDIX 111 Contact SAMSUNG WORLD WIDE

Table Of Contents

Table Of Contents 6

117 Responsibility for the Pay Service (Cost

to Customers)

117 Not a product defect

117 A Product damage caused by customer's fault

117 Others

118 Correct Disposal

118 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

119 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

Symbols for safety precautions

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 111) if the inside of the monitor needs

cleaning. (Service fee will be charged.)

3.93

inches

(10 cm)

3.93

inches

(10 cm)

3.93 inches(10 cm)

Before Using the Product

Safety Precautions

Electricity and Safety

The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

An electric shock or fire may result.

Do not plug many products into the same power socket.

Otherwise, the socket may overheat and cause a fire.

Do not touch the power plug with wet hands.

Otherwise, an electric shock may result.

Insert the power plug all the way in so it is not loose.

An unstable connection may cause a fire.

Ensure you connect the power plug to a grounded power socket. (type 1

insulated devices only).

An electric shock or injury may result.

Do not bend or pull the power cord with force. Do not weigh the power cord

down with a heavy object.

A damaged power cord may cause an electric shock or fire.

Do not place the power cord or product near heat sources.

An electric shock or fire may result.

Remove foreign substances such as dust around the plug pins and power socket

with a dry cloth.

Otherwise, a fire may result.
