Samsung SDC1A809 Manual de usuario

Condensing Dryer

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

SDC1A809

SDC3K801

This manual is made with 100% recycled paper.

SDC1A809-02805J-05_EN_140507.indd 1SDC1A809-02805J-05_EN_140507.indd 1 2014-05-07  6:29:192014-05-07  6:29:19

English - 2

contents

INSTALLING YOUR DRYER

9Tools needed for installation

9See Dryer Exterior

10 Check before installing

10 Before using the product

10 Important to installer

10 Location considerations

10 Alcove or closet installation

11 Electrical requirements

11 Grounding

12 Installation side by side

12 Final installation checklist

13 Draining water without using the water tank

13 Connecting the drain hose

15 Installation stacking

16 Door Reversal

OPERATING INSTRUCTIONS, TIPS

18 Overview of the control panel

20 Child lock

20 Signal off

21 My cycle

21 Delay End

21 Interior Lamp

22 Rack Dry

23 Load the dryer properly

23 Getting started

CARE AND CLEANING

24 Clean the filter case

24 Clean the condenser

24 Control Panel

24 Tumbler

24 Stainless Steel Tumbler

24 Dryer Exterior

25 Dumping condensed water ( )

25 Cleaning the filter case ( )

26 Cleaning the condenser assembly

SPECIAL LAUNDRY TIPS

27 Special laundry tips

TROUBLESHOOTING

28 Check these points if your dryer…

30 Information codes

APPENDIX

31 Fabric care chart

32 Protecting the environment

32 Declaration of conformity

32 Specifications

33 Cycle chart

34 Consumption data

35 Sheet of household tumble driers

SDC1A809-02805J-05_EN_140507.indd Sec2:2SDC1A809-02805J-05_EN_140507.indd Sec2:2 2014-05-07  6:29:442014-05-07  6:29:44

English - 3

safety information

Congratulations on your new Samsung Dryer. This manual contains important

information on the installation, use, and care of your appliance. Please take the

time to read this manual to take full advantage of your dryer’s many benefits and

features.

WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS

Warnings and Important Safety Instructions in this manual do not cover all possible conditions and

situations that may occur. It is your responsibility to use common sense, caution, and care when installing,

maintaining, or operating your dryer.

Always contact your manufacturer about problems or conditions you do not understand.

IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS

WARNING

Hazards or unsafe practices that may result in severe personal injury or

death.

CAUTION

Hazards or unsafe practices that may result in minor personal injury or

property damage.

CAUTION

To reduce the risk of fire, explosion, electric shock, or personal injury when

using your washer, follow these basic safety precautions:

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions explicity.

Unplug the power plug from the wall socket.

Make sure the machine is grounded to prevent electric shock.

Call the service center for help.

Note

Read operator’s manual

• Clothes dryer installation must be performed by a qualified technician.

• Install the clothes dryer according to the manufacturer’s instructions and local codes.

• To reduce the risk of severe injury or death, follow all installation instructions.

WARNING - Risk of Fire

01 SAFETY INFORMATION

SDC1A809-02805J-05_EN_140507.indd Sec1:3SDC1A809-02805J-05_EN_140507.indd Sec1:3 2014-05-07  6:29:442014-05-07  6:29:44

English - 4

To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow

basic precautions, including the following:

Do not let children (or pets) play in or on your product. The product

door does not open easily from the inside and children may be

seriously injured if trapped inside.

This appliance is not to be used by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person

responsible for their safety.

Children should be supervised to ensure that they do not play with

the appliance.

For use in Europe: This appliance can be used by children aged

from 8 years and above and persons with reduced physical, sensory

or mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in order

to avoid a hazard.

This appliance should be positioned so that the power plug, the

water supply taps, and the drain pipes are accessible.

For appliances with ventilation openings in the base, that a carpet

must not obstruct the openings.

The new hose-sets supplied with the appliance are to be used and

that old hose-sets should not be reused.

CAUTION: In order to avoid a hazard due to inadvertent resetting of

the thermal cut-out, this appliance must not be supplied through an

external switching device, such as a timer, or connected to a circuit

that is regularly switched on and off by the utility.

WARNING

safety information

SDC1A809-02805J-05_EN_140507.indd Sec1:4SDC1A809-02805J-05_EN_140507.indd Sec1:4 2014-05-07  6:29:442014-05-07  6:29:44

English - 5

The tumble dryer is not to be used if industrial chemicals have been

used for cleaning.

The lint trap has to be cleaned frequently, if applicable.

Lint must not to be allowed to accumulate around the tumble dryer.

(not applicable for appliances intended to be vented to the exterior of

the building)

Adequate ventilation has to be provided to avoid the back flow of

gases into the room from appliances burning other fuels, including

open fires.

Do not dry unwashed items in the tumble dryer.

Items that have been soiled with substances such as cooking oil,

acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes

and wax removers should be washed in hot water with an extra

amount of detergent before being dried in the tumble dryer.

Items such as foam rubber (latex foam), shower caps, waterproof

textiles, rubber backed articles and clothes or pillows fitted with foam

rubber pads should not be dried in the tumble dryer.

Fabric softeners, or similar products, should be used as specified by

the fabric softener instructions.

The final part of a tumble dryer cycle occurs without heat (cool down

cycle) to ensure that the items are left at a temperature that ensures

that the items will not be damaged.

Remove all objects from pockets such as lighters and matches.

WARNING: Never stop a tumble dryer before the end of the drying

cycle unless all items are quickly removed and spread out so that the

heat is dissipated.

Exhaust air must not be discharged into a flue which is used for

exhausting fumes from appliances burning gas or other fuels.

The appliance must not be installed behind a lockable door, a sliding

door or a door with a hinge on the opposite side to that of the tumble

dryer, in such a way that a full opening of the tumble dryer door is

restricted.

01 SAFETY INFORMATION

SDC1A809-02805J-05_EN_140507.indd Sec1:5SDC1A809-02805J-05_EN_140507.indd Sec1:5 2014-05-07  6:29:442014-05-07  6:29:44

English - 6

SEVERE WARNING SIGNS FOR INSTALLATION

The installation of this appliance must be performed by a qualified technician or service

company.

- Failure to do so may result in electric shock, fire, an explosion, problems with the

product, or injury.

Plug the power cord into an AC 220~240V/50Hz wall socket or higher and use the socket

for this appliance only. In addition, do not use an extension cord.

- Sharing a wall socket with other appliances using a power strip or extending the power

cord may result in electric shock or fire.

- Ensure that the power voltage, frequency and current are the same as those of the

product specifications. Failure to do so may result in electric shock or fire. Failure Plug

the power plug into the wall socket firmly.

Remove all foreign substances such as dust or water from the power plug terminals and

contact points using a dry cloth on a regular basis.

- Unplug the power plug and clean it with a dry cloth.

- Failure to do so may result in electric shock or fire.

Keep all packaging materials well out of the reach of children, as packaging materials can

be dangerous to children.

- If a child places a bag over its head, it may result in suffocation.

This appliance must be properly grounded.

Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.

- This may result in electric shock, fire, an explosion, or problems with the product

- Never plug the power cord into a socket that is not grounded correctly and make sure

that it is in accordance with local and national codes.

Do not install or keep the product exposed to the outdoor elements.

Do not use a damaged power plug, damaged power cord or loose wall socket.

- This may result in electric shock or fire.

If the plug (power supply cord) is damaged, it must be replaced by the manufacturer or its

service agent or a similar qualified technician in order to avoid a hazard.

This appliance should be positioned to be accessible to the power plug after installation.

Do not pull or excessively bend the power cord.

Do not twist or tie the power cord.

Do not hook the power cord over a metal object, place a heavy object on the power cord,

insert the power cord between objects, or push the power cord into the space behind the

appliance.

- This may result in electric shock or fire.

Do not pull the power cord, when unplugging the power plug.

- Unplug the power plug by holding the plug.

- Failure to do so may result in electric shock or fire.

This appliance must be properly grounded. Never plug the power cord into a receptacle

that is not grounded adequately and in accordance with local and national codes. See

installation instructions for grounding this appliance.

safety information

WARNING

SDC1A809-02805J-05_EN_140507.indd Sec1:6SDC1A809-02805J-05_EN_140507.indd Sec1:6 2014-05-07  6:29:442014-05-07  6:29:44

English - 7

SEVERE WARNING SIGNS FOR USING

Do not let children or pets on or into the product. In addition, when disposing of this

product, disassemble the door lock (lever).

- This may result in children falling and injuring themselves.

- If children become locked in the product, there is a danger of suffocation.

Do not try to access the inside of the product when the drum is rotating.

Do not sit on the product or lean against the door.

- This may result in the product turning over and resulting in injury.

Dry the laundry only after it was spun by an appropriate washing machine.

Do not dry unwashed items in the tumble dryer.

Do not drink the condensed water.

Never stop a tumble dryer before the end of the drying cycle unless all items are quickly

removed and spread out so that the heat is dissipated.

Do not dry laundry contaminated by inflammable materials such as gasoline, kerosene,

benzene, thinner, alcohol, etc.

- This may result in electric shock, fire or explosion.

Do not let pets chew or play with the dryer.

- This may result in electric shock or injury.

When disposing of the product, separate the door and the power cord before disposing of

the product.

- Failing to do so may result in damage to the power code or an injury.

Do not touch the power plug with wet hands.

- This may result in electric shock.

Do not repair, replace, or attempt to service any part of the appliance unless specifically

recommended in the user-repair instructions. You must also have the skills necessary to

service this appliance.

Do not attempt to repair, disassemble, or modify the appliance yourself.

- Do not use any fuse(such as cooper, steel wire, etc.) other than the standard fuse.

- When repairing or reinstalling the appliance is required, contact your nearest service

center.

- Failure to do so may result in electric shock, fire, problems with the product, or injury.

The product you have purchased is designed for domestic use only.

The use for business purposes qualifies as product misuse. In this case, the product will not

be covered by the standard warranty provided by Samsung and no responsibility can be

attributed to Samsung for malfunctions or damages resulting from such misuse.

01 SAFETY INFORMATION

WARNING

SDC1A809-02805J-05_EN_140507.indd Sec1:7SDC1A809-02805J-05_EN_140507.indd Sec1:7 2014-05-07  6:29:442014-05-07  6:29:44

English - 8

CAUTION SIGNS FOR USING

Do not stand on top of the appliance or place objects (such as laundry, lighted candles,

lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.

- This may result in electric shock, fire, problems with the product, or injury.

Do not touch the glass door and inside of the drum during or just after drying as it is hot.

- This may result in burns.

Do not press the buttons using sharp objects such as pins, knifes, fingernails, etc.

- This may result in electric shock or injury.

Do not use dry cleaning detergent directly and do not wash, rinse, or spin laundry

contaminated by dry cleaning detergent.

- This may result in spontaneous combustion or ignition due to the heat of the oxidation of

the oil.

Do not dry laundry containing forming rubber (latex) or similar rubber textures.

- If forming rubber is heated, it may start a fire.

Do not dry laundry contaminated by vegetable oil or cooking oil as a large amount of the oil

will not be removed when washing the laundry. In addition, use the Cool Down cycle so that

the laundry is not heated.

- The oxidization heat of the oil may start a fire.

Make sure that the pockets of all clothing to be washed are empty.

- Hard, sharp objects, such as coins, safety pins, nails, screws, or stones can cause

extensive damage to the appliance.

Do not wash clothing with large buckles, buttons, or other heavy metal.

Do not use softener or a static electricity remover unless recommended by the

manufacturer.

- This may result in damage to the laundry.

Do not use the dryer near dangerous powders such as coal dust, wheat flour, etc.

- This may result in electric shock, fire or an explosion.

Do not place inflammable materials near the product.

- This may result in toxic gases from the product, damage to parts, electric shock, fire or

an explosion.

- The appliance should not be placed behind lockable doors etc.

SEVERE WARNING SIGNS FOR CLEANING

Do not clean the appliance by spraying water directly onto it.

Do not use benzene, thinner or alcohol to clean the appliance.

- This may result in discolouration, deformation, damage, electric shock or fire.

Before cleaning or performing maintenance, unplug the appliance from the wall socket.

- Failure to do so may result in electric shock or fire.

Clean the filter case before and after using the dryer.

Clean the inside of the product on a regular basis by asking an authorized service engineer.

Clean the condenser with water once a month.

The interior of the dryer should be cleaned periodically by qualified service personnel.

safety information

CAUTION

WARNING

SDC1A809-02805J-05_EN_140507.indd Sec1:8SDC1A809-02805J-05_EN_140507.indd Sec1:8 2014-05-07  6:29:442014-05-07  6:29:44

English - 9

installing your dryer

TOOLS NEEDED FOR INSTALLATION

Hire a professional to install this dryer properly. If there is a service call performed as a result of poor setup,

adjustment, and connection, it is considered the responsibility of the installer. If you install the dryer you are

responsible.

Make sure you have everything necessary for proper installation (AC 220~240V/50Hz).

1. A GROUNDED ELECTRICAL OUTLET is required. See Electrical Requirements (See page 11).

2. CONDENSING SYSTEM - Condenses, processes and circulates hot and humid air internally using an

internal heat condenser.

SEE DRYER EXTERIOR

Parts

Hose guide Cable tie Hose connector Long drain hose(2m) Manual book

02 INSTALLING YOUR DRYER

Water tank

Control panel

Door

Levelling feet

Work top

Plug

Filter case

Condenser

SDC1A809-02805J-05_EN_140507.indd Sec3:9SDC1A809-02805J-05_EN_140507.indd Sec3:9 2014-05-07  6:29:442014-05-07  6:29:44

English - 10

CHECK BEFORE INSTALLING

• Do not plug the power cord into the wall outlet before completing the dryer installation.

• Check the appearance of the product for any damaged parts before starting the product installation.

• If there are any parts that appear to be damaged, please contact your nearest Samsung Customer

Service Center.

• When moving the product, do not move the product by yourself.

• Take care of the edges of the dryer as they can be sharp.

• Do not install the dryer in a location exposed to frost. Cold water may damage the product.

• Use the product indoors only.

• Do not place the dryer on one side when lifting it, and do not move the dryer in such a way that the

internal parts shake. This may result in damage to the internal parts of the product.

BEFORE USING THE PRODUCT

• Check if there are any accessories remaining inside the drum.

• Plug in the power cord just before operating the product.

• Do not block the air inlet hole of the cooling grill at the front of the dryer.

• Do not place inflammable objects near the dryer and keep the surroundings clean.

• Keep the dryer level with the ground.

• Do not remove the adjustable levelling feet of the dryer. They are necessary to keep the product level

with the ground.

IMPORTANT TO INSTALLER

Please read the following instructions carefully before installing the dryer. These instructions should be kept

for future reference.

REMOVE THE DOOR FROM ALL DISCARDED APPLIANCES TO AVOID THE DANGER OF A CHILD

SUFFOCATING.

LOCATION CONSIDERATIONS

Because a condensing type has been adopted, which condenses and processes air inside the dryer,

external ventilation is not required.

Therefore, The dryer can be installed and used in any location where the temperature is between 5

and 35 degrees centigrade, unlike a conventional dryer that requires an external exhaust system.

ALCOVE OR CLOSET INSTALLATION

To operate safely and properly, your new Dryer requires minimum clearances of:

Sides – 25 mm Rear – 51 mm

Top – 25 mm Front – 465 mm

If both the washing machine and a dryer are installed together, the front of the alcove or closet must have at

least 465 mm unobstructed air opening.

installing your dryer

WARNING

SDC1A809-02805J-05_EN_140507.indd Sec3:10SDC1A809-02805J-05_EN_140507.indd Sec3:10 2014-05-07  6:29:452014-05-07  6:29:45

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Secadora de Samsung

Samsung

Samsung DV339AG Series Manual de usuario

Samsung

Samsung DV50K7500EV/A3 Manual de usuario

Samsung

Samsung DVG50M7450P Manual de usuario

Samsung

Samsung DV56H9000E Series Manual de usuario

Samsung

Samsung DV231AGW/XAA Manual de usuario

Samsung

Samsung DVE45T6100 Series Manual de usuario

Samsung

Samsung FlexDry DV 55M9600 Series Manual de usuario

Samsung

Samsung DV8 T5 Series Manual de usuario

Samsung

Samsung DV365ETBGWR/A3 Manual de usuario

Samsung

Samsung DV350AE Series Manual de usuario

Samsung

Samsung DV365GTBGSF/AC Manual de usuario

Samsung

Samsung DV9 T 2 Series Manual de usuario

Samsung

Samsung DV5451AEWXAC Manual de usuario

Samsung

Samsung DV42H5600 Series Manual de usuario

Samsung

Samsung DV331AE Series Manual de usuario

Samsung

Samsung DV42H5200EW Manual de usuario

Samsung

Samsung DVG52M8650 Series Manual de usuario

Samsung

Samsung DV448AE series Manual de usuario

Samsung

Samsung DVE45T3200 Series Manual de usuario

Samsung

Samsung DVE50A8800 Series Manual de usuario

Samsung

Samsung DVE53BB8900 Series Manual de usuario

Samsung

Samsung DVG50M7450W/A3 Manual de usuario

Samsung

Samsung DV456 Series Manual

Samsung

Samsung DVG53BB8700 Series Manual de usuario

Manuales populares de Secadora de otras marcas

Bosch

Bosch WTA79200GB Manual de usuario

Amana

Amana W10233410A Manual de usuario

Miele

Miele TWH 780 WP Manual de usuario

Asko

Asko T760 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manual de usuario

Bosch

Bosch Logixx 10 WTB76556GB Hoja de especificaciones

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manual de instrucciones

Electrolux

Electrolux EW2H328R2 Manual de usuario

Beko

Beko DS8433RX1M Manual de usuario

Dawlance

Dawlance Spinner DS 6000 C Manual de usuario

Electrolux

Electrolux TP5080TW Manual de usuario

AEG

AEG TR838P4OB Manual de usuario

Indesit

Indesit IDV 75 Manual de usuario

Infiniton

Infiniton SD-DG85C Manual de usuario

BOMANN

BOMANN WT 5019 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manual de usuario

Asko

Asko T793C Manual de usuario

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario
