Samsung DV431AEP Manual de usuario

Electric Dryer

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service or accessory

parts, please register your product at or

contact

www.samsung.com/register

DV431AE*

This manual is made with 100% recycled paper.

DV431AEP-03021E_EN_v7.indd 1DV431AEP-03021E_EN_v7.indd 1 11/25/2011 12:56:58 AM11/25/2011 12:56:58 AM

2_ Features

features

1. Extra Large Capacity

Ultra drying capabilities are at your fingertips! Now you can dry extra-large loads. Our ultra

large 10 kg dryer circulates more air through your clothes, drying them faster for a wrinkle-

free result.

2. Sanitize course

This course allows you to sanitize garments by permeating high temperature heat deep into

the fabric during the drying cycle. Use this course to keep your bedding and curtains clean.

When selecting this cycle, 99.9 % of all bacteria is eliminated through high temperature heat.

Use this cycle for clothing, bedding, towels, or other items needing sanitization.

3. Various Drying Cycles & Fuzzy Logic Algorithm

Simply turn the Jog Dial to select one of the 13 automatic drying cycles, including cotton,

heavy duty and towels, or let the Fuzzy Logic Control measure the degree of dampness and

automatically set the drying time. Precision drying has never been easier than with Samsung.

4. Energy Saving

Energy efficiency has been optimized to minimize unnecessary power consumption.

5. Easy Reversible Door

Our dryers will fit just about anywhere and without a door conflict. The direction of our easy

reversible door can be changed with just four screws.

6. Pedestal with Storage Drawers

An optional 15” pedestal is available to raise the dryer for easier loading and unloading. It

also offers a built-in storage drawer that can hold a 100 oz. bottle of detergent

7. Stacking (MODEL NO: SK-5A/XAA)

Samsung’s Washers and Dryers can be stacked to maximize usable space.

The Dryer legs need to be removed to stack the Washer and Dryer. You can purchase an

optional stacking kit from your Samsung retailer.

8. 4-way Vent

You can install the exhaust vent in the following four (4) positions: back, either side, bottom.

DV431AEP-03021E_EN_v7.indd Sec9:2DV431AEP-03021E_EN_v7.indd Sec9:2 11/25/2011 12:57:15 AM11/25/2011 12:57:15 AM

Safety information _3

safety instructions

Congratulations on your new Samsung Dryer. This manual contains valuable

information on the installation, use, and care of your appliance. Please take the

time to read this manual to take full advantage of your dryer’s many benefits and

features.

WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS

Warnings and Important Safety Instructions in this manual do not cover all possible conditions and

situations that may occur. It is your responsibility to use common sense, caution, and care when installing,

maintaining, or operating your dryer.

Always contact your manufacturer about problems or conditions you do not understand.

IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS

WARNING

Hazards or unsafe practices that may result in severe personal injury or

death.

Follow the information in this manual to minimize the risk of fire or explosion or

to prevent property damage, personal injury, or death.

Do not store or use gasoline or other flammable vapors and liquids near this or

any other appliance.

CAUTION

Hazards or unsafe practices that may result in minor personal injury or

property damage.

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions explicity.

Make sure the machine is grounded to prevent electric shock.

Call the service center for help.

• Clothes dryer installation must be performed by a qualified installer.

• Install the clothes dryer according to the manufacturer’s instructions and local codes.

• Do not install a clothes dryer with flexible plastic venting materials. If flexible metal

(foil type) duct is installed, it must be of a specific type identified by the appliance

manufacturer as suitable for use with clothes dryers. Flexible venting materials are

known to collapse, be easily crushed, and trap lint. These conditions will obstruct

clothes dryer airflow and increase the risk of fire.

• To reduce the risk of severe injury or death, follow all installation instructions.

WARNING - Risk of Fire

DV431AEP-03021E_EN_v7.indd Sec1:3DV431AEP-03021E_EN_v7.indd Sec1:3 11/25/2011 12:57:15 AM11/25/2011 12:57:15 AM

4_ Safety information

safety instructions

This appliance is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and

spread out so that the heat is dissipated.

INSTRUCTION ABOUT THE WEEE MARK

Correct Disposal of This Product (Waste Electrical & Electronic

Equipment)

(Applicable in the European Union and other European countries with separate

collection systems)

This marking on the product, accessories or literature indicates that the product and its

electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other

household waste at the end of their working life. To prevent possible harm to the environment or

human health from uncontrolled waste disposal, please separate these items from other types of

waste and recycle them responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or

their local government office, for details of where and how they can take these items for

environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the

purchase contract. This product and its electronic accessories should not be mixed with other

commercial wastes for disposal.

WARNING

DV431AEP-03021E_EN_v7.indd Sec1:4DV431AEP-03021E_EN_v7.indd Sec1:4 11/25/2011 12:57:15 AM11/25/2011 12:57:15 AM

Safety information _5

SEVERE WARNING SIGNS FOR INSTALLATION

The installation of this appliance must be performed by a qualified technician or service

company.

- Failure to do so may result in electric shock, fire, an explosion, problems with the

product, or injury.

Keep all packaging materials well out of the reach of children, as packaging materials can

be dangerous to children.

- If a child places a bag over its head, it may result in suffocation.

This appliance must be properly grounded.

Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.

- This may result in electric shock, fire, an explosion, or problems with the product

Do not install or keep the product exposed to the outdoor elements.

WARNING

DV431AEP-03021E_EN_v7.indd Sec1:5DV431AEP-03021E_EN_v7.indd Sec1:5 11/25/2011 12:57:15 AM11/25/2011 12:57:15 AM

6_ Safety information

safety instructions

SEVERE WARNING SIGNS FOR USING

Do not let children or pets on or into the product. In addition, when disposing of this

product, disassemble the door lock (lever).

- This may result in children falling and injuring themselves.

- If children become locked in the product, there is a danger of suffocation.

Do not try to access the inside of the product when the drum is rotating.

Do not sit on the product or lean against the door.

- This may result in the product turning over and resulting in injury.

Dry the laundry only after it was spun by an appropriate washing machine.

Do not dry unwashed items in the tumble dryer.

Do not drink the condensed water.

Never stop a tumble dryer before the end of the drying cycle unless all items are quickly

removed and spread out so that the heat is dissipated.

Do not dry laundry contaminated by inflammable materials such as gasoline, kerosene,

benzene, thinner, alcohol, etc.

- This may result in electric shock, fire or explosion.

Do not let pets chew or play with the dryer.

- This may result in electric shock or injury.

When disposing of the product, separate the door and the power cord before disposing of

the product.

- Failing to do so may result in damage to the power code or an injury.

The product you have purchased is designed for domestic use only.

The use for business purposes qualifies as product misuse. In this case, the product will not

be covered by the standard warranty provided by Samsung and no responsibility can be

attributed to Samsung for malfunctions or damages resulting from such misuse.

Do not repair, replace, or attempt to service any part of the appliance unless specifically

recommended in the user-repair instructions. You must also have the skills necessary to

service this appliance.

Do not attempt to repair, disassemble, or modify the appliance yourself.

- Do not use any fuse(such as cooper, steel wire, etc.) other than the standard fuse.

- When repairing or reinstalling the appliance is required, contact your nearest service

center.

- Failure to do so may result in electric shock, fire, problems with the product, or injury.

WARNING

DV431AEP-03021E_EN_v7.indd Sec1:6DV431AEP-03021E_EN_v7.indd Sec1:6 11/25/2011 12:57:15 AM11/25/2011 12:57:15 AM

Safety information _7

CAUTION SIGNS FOR USING

Do not stand on top of the appliance or place objects (such as laundry, lighted candles,

lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.

- This may result in electric shock, fire, problems with the product, or injury.

Do not touch the glass door and inside of the drum during or just after drying as it is hot.

- This may result in burns.

Do not press the buttons using sharp objects such as pins, knifes, fingernails, etc.

- This may result in electric shock or injury.

Do not use dry cleaning detergent directly and do not wash, rinse, or spin laundry

contaminated by dry cleaning detergent.

- This may result in spontaneous combustion or ignition due to the heat of the oxidation of

the oil.

Do not dry laundry containing forming rubber (latex) or similar rubber textures.

- If forming rubber is heated, it may start a fire.

Do not dry laundry contaminated by vegetable oil or cooking oil as a large amount of the oil

will not be removed when washing the laundry. In addition, use the Cool Down cycle so that

the laundry is not heated.

- The oxidization heat of the oil may start a fire.

Make sure that the pockets of all clothing to be washed are empty.

- Hard, sharp objects, such as coins, safety pins, nails, screws, or stones can cause

extensive damage to the appliance.

Do not wash clothing with large buckles, buttons, or other heavy metal.

Do not use softener or a static electricity remover unless recommended by the

manufacturer.

- This may result in damage to the laundry.

Do not use the dryer near dangerous powders such as coal dust, wheat flour, etc.

- This may result in electric shock, fire or an explosion.

Do not place inflammable materials near the product.

- This may result in toxic gases from the product, damage to parts, electric shock, fire or

an explosion.

- The appliance should not be placed behind lockable doors etc.

SEVERE WARNING SIGNS FOR CLEANING

Do not clean the appliance by spraying water directly onto it.

Do not use benzene, thinner or alcohol to clean the appliance.

- This may result in discolouration, deformation, damage, electric shock or fire.

Before cleaning or performing maintenance, cut off the power supply to the appliance.

- Failure to do so may result in electric shock or fire.

Clean the filter case before and after using the dryer.

Clean the inside of the product on a regular basis by asking an authorized service engineer.

Clean the condenser with water once a month.

The interior of the dryer should be cleaned periodically by qualified service personnel.

CAUTION

WARNING

DV431AEP-03021E_EN_v7.indd Sec1:7DV431AEP-03021E_EN_v7.indd Sec1:7 11/25/2011 12:57:15 AM11/25/2011 12:57:15 AM

8_ contents

contents

INSTALLING YOUR DRYER

9Tools needed for installation

9See dryer exterior

10 Ducting requirements

11 Important to installer

11 Location considerations

12 Alcove or closet installation

14 Mobile home installation

14 Exhausting

14 Electrical requirements

14 Grounding

15 Replacement parts and accessories

15 Installation

16 Final installation checklist

17 Dryer exhaust tips

18 Door reversal

OPERATING INSTRUCTIONS, TIPS

19 Overview of the control panel

22 Child lock

22 Drum light

22 My cycle

23 Rack dry

24 Clean the lint filter

24 Load the dryer properly

24 Getting started

CARE AND CLEANING

25 Control panel

25 Tumbler

25 Stainless steel tumbler

25 Dryer exterior

25 Dryer exhaust system

SPECIAL LAUNDRY TIPS

26 Special laundry tips

TROUBLESHOOTING

27 Check these points if your dryer…

28 Information codes

APPENDIX

29 Fabric care chart

30 Protecting the environment

30 Declaration of conformity

30 Specifications

31 Cycle chart

DV431AEP-03021E_EN_v7.indd Sec3:8DV431AEP-03021E_EN_v7.indd Sec3:8 11/25/2011 12:57:15 AM11/25/2011 12:57:15 AM

installing your dryer _9

installing your dryer

UNPACKING YOUR DRYER

Unpack your Dryer and inspect it for shipping damage. Make sure you have received all of the items

shown below. If your Dryer was damaged during shipping, or you do not have all of the items, contact

0330 SAMSUNG (7267864)

To prevent personal injury or strain, wear protective gloves whenever lifting or carrying the unit.

Packing materials can be dangerous to children; keep all packing material (plastic bags, polystyrene,

etc.) well out of the reach of children.

SEE DRYER EXTERIOR

01 installing your dryer

Adjustable legs

Control panel

Door

WARNING

DV431AEP-03021E_EN_v7.indd Sec5:9DV431AEP-03021E_EN_v7.indd Sec5:9 11/25/2011 12:57:16 AM11/25/2011 12:57:16 AM

10_ installing your dryer

DUCTING REQUIREMENTS

• Use a 4-inch (10.2 cm) diameter rigid aluminum or rigid galvanized steel duct.

• Do not use a smaller duct.

• Ducts larger than 4 inches (10.2 cm) in diameter can result in increased lint accumulation.

Lint accumulation should be cleaned regularly.

• If a flexible metal duct must be used, use the type with a stiff sheet metal wall. Do not use a flexible duct

with a thin foil wall. Serious blockage can result if the flexible metal duct is bent too sharply.

• Never install any type of flexible duct in walls, ceilings, or other concealed spaces.

• Only a rigid or flexible metal duct should be used for exhausting.

• Keep the exhaust duct as straight and short as possible.

• Secure joints with duct tape. Do not use screws.

• Do not exhaust dryer into any wall, ceiling, crawl space, or concealed space of a building, gas vent, or

any other common duct or chimney. This could create a fire hazard from lint expelled by the dryer.

• A plastic flexible duct can kink, sag, be punctured, reduce airflow, extend drying times, and affect dryer

operation.

• Exhaust systems longer than recommended can extend drying times, affect machine operation, and

may collect lint.

• The exhaust duct should end with an exhaust hood with a swing-out damper to prevent back drafts and

entry of wildlife. Never use an exhaust hood with a magnetic damper.

• The hood should have at least 12 inches (30.5 cm) of clearance between the bottom of the hood and

the ground or other obstruction. The hood opening should point down.

• Never install a screen over the exhaust outlet.

• To avoid lint buildup, do not exhaust the dryer directly into a window well. Do not exhaust under a house

or porch.

• If exhaust ductwork must run through an unheated area, the duct should be insulated and slope slightly

down towards the exhaust hood to reduce condensation and lint buildup.

• Inspect and clean the interior of the exhaust system at least once a year.

• Check frequently to be sure the exhaust hood damper opens and closes freely.

• Check once per month, and clean at least one time per year. Note: If clothes are not getting dry, then

check ducting for obstructions.

ELECTRIC AND GAS DRYER

Weather Hood Type

Recommended Use only for short-run installation

4” (10.16 cm) 2.5” (6.35 cm)

No. of 90° elbows Rigid Metallic Flexible* Rigid Metallic Flexible*

0 24.4 m (80 ft.) 12.4 m (41 ft.) 22.6 m (74 ft.) 10.1 m (33 ft.)

1 20.7 m (68 ft.) 11.2 m (37 ft.) 18.9 m (62 ft.) 8.8 m (29 ft.)

2 17.4 m (57 ft.) 10.1 m (33 ft.) 15.5 m (51 ft.) 7.6 m (25 ft.)

3 14.3m (47 ft.) 9.0 m (29 ft.) 12.5 m (41 ft.) 6.5 m (21 ft.)

* Do not use non-metallic flexible duct.

installing your dryer

DV431AEP-03021E_EN_v7.indd Sec5:10DV431AEP-03021E_EN_v7.indd Sec5:10 11/25/2011 12:57:16 AM11/25/2011 12:57:16 AM
