Samsung DV431AEP Manual de servicio

* Samsung received the highest numerical score for clothes washers (2009-2010) and dryers (2008-2010) in the proprietary J.D. Power and

Associates Laundry Appliance StudiesSM. 2010 study based on 10,344 total responses measuring 17 brands and measures opinions of

consumers who purchased their washer or dryer from a retail store or their new-home builder during the previous 24 months. Proprietary study

results are based on experiences and perceptions of consumers surveyed in March-April 2010. Your experiences may vary. Visit jdpower.com.

DV431AEP

7.4 cu. ft. Capacity Electric Steam Dryer

Features

∙Towels Dry Cycle

∙Steam Drying Technology:

-Steam Refresh: Freshens up

clothes and removes odors

-Steam Away: Relaxes wrinkles to

reduce ironing

∙Stainless Steel Drum

∙7.4 cu. ft. Capacity

∙13 Preset Drying Cycles and

6 Options

∙5 Temperature Settings

∙ 4 Way Venting

Convenience

∙Sensor Dry – Detects Moisture and

Adusts Drying Time

∙Reversable See Through Door

∙Drying Rack

∙ Dryer Drum Light

∙Child Lock

∙My Cycle Option

∙Delay Start – Up to 24 Hours

∙Lint Filter Indicator

∙Remaining Time Display

∙Adjustable End of Cycle Signal

∙Optional Pedestals or Stacking

Kit Available

Signature Features

Steam Drying Technology

Steam Refresh and Steam Away

These cycles infuse clothes with steam

to reduce wrinkles, remove odors, and

refresh clothing.

Drying Rack

Provides tumble-free drying for

items such as sneakers, sweaters,

or stuffed animals.

Woolmark®Certied Dry Cycle

A safeguard against shrinking or

damage. Safely care for your favorite

wool items at home.

Stainless

Platinum

(shown) Neat White

(Shown with optional pedestal) 6 Options

13 Cycles

Ranked “Highest in Customer

Satisfaction with Clothes

Dryers” by J.D. Power and

Associates.*

Available Colors

Note: All models with Bright Chrome Trim

Actual color may vary. Design, speciﬁcations, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.

Fabric Care

13 Preset Dry Cycles

Steam Refresh, Steam Wrinkle Away, Normal,

Heavy Duty, Towels, Permanent Press, Bedding

PLUS, Delicates, Wool, Sanitize, Time Dry, Air Fluff,

Quick Dry

6 Options

Mixed Load Bell, Wrinkle Prevent, Delay Start-Up to

24 Hours, My Cycle, Rack Dry, Adjust Time

5 Temperature Settings

High, Medium, Medium Low, Low, Extra Low

5 Dry Levels

Very Dry, More Dry, Normal Dry, Less Dry,

Damp Dry

5 Signal Sound Levels

Louder, , Soft, , Off

Accessories:

Stacking Kit: SK-5A

Vent Kit: DV-1A

Pedestal: WE357A0P, WE357A0W

Warranty

One (1) Year All Parts and Labor

Two (2) Years Control Board

Product Dimensions + Weight

Dimensions: (WxHxD) 27" x 39" x 31 1⁄8"

Weight: 121.6 lbs / 55.2 kg

Shipping Dimensions + Weight

Dimensions: (WxHxD) 29 7⁄8" x 43 1⁄4" x 33 1⁄8"

Weight: 132.2 lbs / 60 kg

Color Model # UPC Code

Stainless Platinum DV431AEP 036725569218

Neat White DV431AEW 036725569232

Matching Washer

Stainless Platinum WF431ABP 036725569195

Neat White WF431ABW 036725560352

Installation Options:

Stacked Side by Side On Pedestals Stacked Depth

(38 2⁄8”)

DV431AEP

7.4 cu. ft. Capacity Electric Steam Dryer

Installing your dryer

Required Dimensions for Installation With Pedestal Required Dimensions for Installation

With Stacking Kit

* Required spacing ** External exhaust elbow requires additional space.

Minimum clearances

for closets and alcove:

Sides - 1 In.(2.5 cm)

Top - 17 In.(43.2 cm)

Rear - 4 In. (10.2 cm)

Closet Front - 2 In. (5.1 cm)

If the washer and dryer are

installed together, the closet

front must have at least a 72 in²

(465cm²) unobstructed air

opening. Your washer alone does

not require a speciﬁc air opening.

1 in.1 in. 27 in.

Recessed Area

2 in. 4 in.

32.25 in.

17 in.

Side View Conﬁned

27 in.

39 in.

53 in.

Closet or Door

48 in.² *

24 in.² *

3 in.

1 in. 32.25 in.

5.5 in.**

2.5 in.

1 in. 27 in.

6 in. *

4 in.

50.8 in. (129 cm) to clear open door

2. With optional pedestal base or stacking kit

1. Alcove or closet installation

32.25 in.

* Samsung received the highest numerical score for clothes washers (2009-2010) and dryers (2008-2010) in the proprietary J.D. Power and

Associates Laundry Appliance StudiesSM. 2010 study based on 10,344 total responses measuring 17 brands and measures opinions of

consumers who purchased their washer or dryer from a retail store or their new-home builder during the previous 24 months. Proprietary study

results are based on experiences and perceptions of consumers surveyed in March-April 2010. Your experiences may vary. Visit jdpower.com.

Features

∙Towels Dry Cycle

∙Steam Drying Technology:

-Steam Refresh: Freshens up

clothes and removes odors

-Steam Away: Relaxes wrinkles to

reduce ironing

∙Stainless Steel Drum

∙7.4 cu. ft. Capacity

∙13 Preset Drying Cycles and

6 Options

∙5 Temperature Settings

∙ 3 Way Venting

Convenience

∙Sensor Dry – Detects Moisture and

Adusts Drying Time

∙Reversable See Through Door

∙Drying Rack

∙ Dryer Drum Light

∙Child Lock

∙My Cycle Option

∙Delay Start – Up to 24 Hours

∙Lint Filter Indicator

∙Remaining Time Display

∙Adjustable End of Cycle Signal

∙Optional Pedestals or Stacking

Kit Available

Signature Features

Steam Drying Technology

Steam Refresh and Steam Away

These cycles infuse clothes with steam

to reduce wrinkles, remove odors, and

refresh clothing.

Drying Rack

Provides tumble-free drying for

items such as sneakers, sweaters,

or stuffed animals.

Stainless

Platinum

(shown) Neat White

DV431AGP

7.4 cu. ft. Capacity Electric Steam Dryer

(Shown with optional pedestal) 6 Options

13 Cycles

Ranked “Highest in Customer

Satisfaction with Clothes

Dryers” by J.D. Power and

Associates.*

Available Colors

Note: All models with Bright Chrome Trim

Woolmark®Certied Dry Cycle

A safeguard against shrinking or

damage. Safely care for your favorite

wool items at home.

Actual color may vary. Design, speciﬁcations, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.

Fabric Care

13 Preset Dry Cycles

Steam Refresh, Steam Wrinkle Away, Normal,

Heavy Duty, Towels, Permanent Press, Bedding

PLUS, Delicates, Wool, Sanitize, Time Dry, Air Fluff,

Quick Dry

6 Options

Mixed Load Bell, Wrinkle Prevent, Delay Start-Up to

24 Hours, My Cycle, Rack Dry, Adjust Time

5 Temperature Settings

High, Medium, Medium Low, Low, Extra Low

5 Dry Levels

Very Dry, More Dry, Normal Dry, Less Dry,

Damp Dry

5 Signal Sound Levels

Louder, , Soft, , Off

Accessories:

Stacking Kit: SK-5A

Vent Kit: DV-1A

Pedestal: WE357A0R, WE357A0W

Warranty

One (1) Year All Parts and Labor

Two (2) Years Control Board

Product Dimensions + Weight

Dimensions: (WxHxD) 27" x 39" x 31 1⁄8"

Weight: 121.6 lbs / 55.2 kg

Shipping Dimensions + Weight

Dimensions: (WxHxD) 29 7⁄8" x 43 1⁄4" x 33 1⁄8"

Weight: 132.2 lbs / 60 kg

Color Model # UPC Code

Stainless Platinum DV431AGP 036725569201

Neat White DV431AGW 036725569225

Matching Washer

Stainless Platinum WF431ABP 036725569195

Neat White WF431ABW 036725560352

Installation Options:

Stacked Side by Side On Pedestals Stacked Depth

(38 2⁄8”)

DV431AGP

7.4 cu. ft. Capacity Electric Steam Dryer

Installing your dryer

Required Dimensions for Installation With Pedestal Required Dimensions for Installation

With Stacking Kit

* Required spacing ** External exhaust elbow requires additional space.

Minimum clearances

for closets and alcove:

Sides - 1 In.(2.5 cm)

Top - 17 In.(43.2 cm)

Rear - 4 In. (10.2 cm)

Closet Front - 2 In. (5.1 cm)

If the washer and dryer are

installed together, the closet

front must have at least a 72 in²

(465cm²) unobstructed air

opening. Your washer alone does

not require a speciﬁc air opening.

1 in.1 in. 27 in.

Recessed Area

2 in. 4 in.

32.25 in.

17 in.

Side View Conﬁned

27 in.

39 in.

53 in.

Closet or Door

48 in.² *

24 in.² *

3 in.

1 in. 32.25 in.

5.5 in.**

2.5 in.

1 in. 27 in.

6 in. *

4 in.

50.8 in. (129 cm) to clear open door

2. With optional pedestal base or stacking kit

1. Alcove or closet installation

32.25 in.
