Samson Go Mic Manual de usuario

Go Mic Mobile

Professional Wireless System for Mobile Filmmaking

Quick Start Guide

Go Mic Mobile

Important Safety Information

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE COVER

(OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

This lightning ﬂash with arrowhead

symbol within an equilateral

triangle is intended to alert the user

to the presence of non-insulated

“dangerous voltage” within the product’s

enclosure that may be of sufﬁcient magnitude

to constitute a risk of electric shock.

The exclamation point within an

equilateral triangle is intended

to alert the user to the presence

of important operating and

maintenance instructions in the literature

accompanying the appliance.

ATTENTION

RISQUE D’ÉLECTROCUTION !

NE PAS OUVRIR !

WARNING

TO PREVENT FIRE OR SHOCK HAZARD. DO NOT USE THIS PLUG WITH AN EXTENSION

CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED

TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE

THIS APPLIANCE TO RAIN OR MOISTURE. TO PREVENT ELECTRICAL SHOCK, MATCH WIDE

BLADE PLUG TO WIDE SLOT AND FULLY INSERT.

Samson Technologies Corp.

278-B Duffy Ave

Hicksville, NY 11801

www.samsontech.com

If you want to dispose this product, do not mix it with general household waste. There is

a separate collection system for used electronic products in accordance with legislation

that requires proper treatment, recovery and recycling.

Private households in the 28 member states of the EU, in Switzerland and Norway may

return their used electronic products free of charge to designated collection facilities or to a

retailer (if you purchase a similar new one).

For Countries not mentioned above, please contact your local authorities for a correct method of

disposal.

By doing so you will ensure that your disposed product undergoes the necessary treatment,

recovery and recycling and thus prevent potential negative effects on the environment and

human health.

Owner’s Manual

ENGLISH

FRANÇAISDEUTSCHEESPAÑOLITALIANOPOLSKI

Important Safety Information

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings.

Install in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such

as radiators, heat registers, stoves, or

other apparatus (including ampliﬁers)

that produce heat.

9. Do not defeat the safety purpose of

the polarized or grounding type plug.

A polarized plug has two blades with

one wider than the other. A grounding

type plug has two blades and a third

grounding prong. The wide blade or the

third prong are provided for your safety.

If the provided plug does not ﬁt into

your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked

on or pinched particularly at the plugs,

convenience receptacles, and at the

point where they exit from the apparatus.

11. Only use attachments/accessories

speciﬁed by the manufacturer.

12. Use only with the cart, stand, tripod,

bracket, or table speciﬁed by the

manufacturer, or sold with the apparatus.

When a cart is used, use caution when

moving the cart/apparatus combination to

avoid injury from tip-over.

13. Unplug the apparatus during lightning

storms, or when unused for long periods

of time.

14. Refer all servicing to qualiﬁed personnel.

Service is required when the apparatus

has been damaged in any way, such as

power supply cord or plug is damaged,

liquid has been spilled or objects have

fallen into the apparatus, has been

exposed to rain or moisture, does not

operate normally, or has been dropped.

15. This appliance shall not be exposed to

dripping or splashing water and no object

ﬁlled with liquid such as vases shall be

placed on the apparatus.

16. Caution-to prevent electrical shock,

match wide blade plug wide slot fully

insert.

17. Please keep a good ventilation

environment around the entire unit.

18. The direct plug-in adapter is used as

disconnect device, the disconnect device

shall remain readily operable.

19. Batteries (battery pack or batteries

installed) shall not be exposed to

excessive heat such as sunshine, ﬁre or

the like.

Go Mic Mobile

Important Safety Information

FCC Notice

1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including interference that may

cause undesired operation.

2. Changes or modiﬁcations not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

FCC Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio com-

munications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

RF Exposure Statement (SAR)

This device is designed and manufactured not to exceed the emission limits for exposure to

radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Gov-

ernment.

The exposure standard for wireless device employs a unit of measurement known as the Speciﬁc

Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. Tests for SAR are conduct-

ed using standard operating positions accepted by the FCC with the device transmitting at its

highest certiﬁcated power level in an tested frequency bands.

To maintain compliance with the FCC RF exposure requirements.

The maximum summation of SAR was:0.90W/Kg 1g Body SAR for GMM,0.61W/Kg 1g Body

SAR for HXD2,0.48W/Kg 1g Body SAR for PXD2.

WARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive

heat such as sunshine, ﬁre or the like.

Hereby, Samson Technologies Corp., declares that this Go Mic Mobile Wireless System is in

compliance with the essential requirements and other relevant provisions of Directive 2014/53/

EU. The declaration of conformity may be consulted at:

http://www.samsontech.com/site_media/support/manuals/GMM_DOC.pdf

Owner’s Manual

ENGLISH

FRANÇAISDEUTSCHEESPAÑOLITALIANOPOLSKI

Introduction

Congratulations on purchasing the Samson Go Mic Mobile Wireless System. The Go

Mic Mobile is a dual wireless system designed to deliver professional quality audio

for mobile video. Pair and mix two transmitters to the GMM and turn your mobile

device into a complete video production studio. It is the ideal solution for mobile

journalists, ﬁlmmakers, videographers or anyone looking to add wireless audio to

their video projects.

The Go Mic Mobile includes all the cables needed to connect the Go Mic Mobile

Receiver (GMM) to a smartphone or digital camera (with an audio input). The Go

Mic Mobile will work with iOS, Android, Mac OS and Windows devices. The locking

mount arms enable the Go Mic Mobile receiver to mount directly onto the rear of a

smartphone out of the way of the phone’s lens. The arms can be removed to attach

the receiver to a tablet (using the included hook-and-loop strips) or afﬁx to a camera

using the included shoe mount adapter.

In these pages, you’ll ﬁnd a detailed description of the features of the Go Mic

Mobile wireless system, instructions for its setup and use, and speciﬁcations. If your

wireless system was purchased in the United States, you’ll also ﬁnd a registration

card enclosed—don’t forget to follow the instructions so that you can receive

technical support and so that we can send you updated information about this and

other Samson products in the future. Also, be sure to check out our website (www.

samsontech.com) for complete information about our full product line.

We recommend you keep the following records for reference, as well as a copy of your

sales receipt.

Transmitter & Receiver Serial number: _________________________________

Date of purchase: ___________________________________________________

If you have any questions or comments regarding the Go Mic Mobile Wireless

Microphone System or any other products from Samson, do not hesitate to contact us

at [email protected].

With proper care and maintenance, your Go Mic Mobile Wireless System will operate trouble-

free for many years. Should your Go Mic Mobile Wireless System ever require servicing, a

Return Authorization (RA) number must be obtained before shipping your unit to Samson.

Without this number, the unit will not be accepted. Please visit www.samsontech.com/ra for

an RA number prior to shipping your unit. Please retain the original packing materials and,

if possible, return the unit in its original carton. If your Go Mic Mobile Wireless System was

purchased outside of the United States, contact your local distributor for warranty details

and service information.

Go Mic Mobile

Charging the Go Mic Mobile Receiver Battery

Getting the most out of the rechargeable battery:

• Completely charge the batteries before ﬁrst use

• Fully charge the battery before it will be used.

• After the battery is charged, unplug the adapter from

the outlet.

• The optimal temperature range for using and

storing the battery is 50°F - 86°F (10°C - 30°C).

The battery performance and operation may

decrease in temperatures below 50°F (10°C).

• To extend the battery life, power off the Go Mic Mobile

receiver when not in use.

The Go Mic Mobile Receiver has an internal lithium-ion rechargeable battery. The

receiver is charged via the Mini USB jack located on the side of the receiver.

To charge the receiver, use the included USB charging cable and AC adapter.

Charging may also be done with 3rd party AC 5V adapters, or by connecting the units

to a standard computer USB port.

The total full charge time is 3 hours if you use a fast charger or a fast-charging

USB port (with a lightning symbol next to it), but if connected to a “standard

computer USB port” it will take 10 hours. The max run time from a full battery is

approximately 7–13 hours.

Note: The Go Mic Mobile receiver does not recharge from the Micro USB port, so

the battery level will decrease if plugged into a computer. If you want to power the

receiver while it is connected to a device, you will also need to connect the Mini USB

port to the computer or AC adapter.

Owner’s Manual

ENGLISH

FRANÇAISDEUTSCHEESPAÑOLITALIANOPOLSKI

1. Power/Pair Switch - Press less

than 5 seconds to turn the unit

on or off. Press and hold for

more than 5 seconds to enter

pairing mode.

Note: The Go Mic Mobile

receiver and transmitter are pre-

paired from the factory.

2. Analog Output Select Switch - Sets

the wiring of the analog output.

The OUT 1 & 2 positions are for

connecting to a smartphone’s

TRRS headset input. The

Headphone/Line output is for

connecting the receiver to a

camera, mixer or headphones.

3. VOL Control - This slider sets the

level of the audio signal sent to the receiver’s digital and analog outputs.

4. MIX / 2 CH Switch - Sets the receiver audio output to either mixed mono or split

left and right.

5. CH 1 & CH 2 Indicators - When lit white, the LEDs indicate the receiver is paired

with a transmitter. When the transmitter input or the receiver output is clipped,

the LEDs flash red.

6. Battery Level Indicator - This indicator lights green when the battery is charged,

lights red when the battery is low, and orange when the battery is charging.

7. Power Indicator - This indicator lights green when the Go Mic Mobile Receiver is

powered on.

8. USB AUDIO Output - Use this output when connecting to a digital audio input.

9. OUT Jack - Use this 3.5mm jack when connecting to an analog input or

headphones.

10. USB CHARGE Port - Use this Mini USB jack to connect the Go Mic Mobile

Receiver to the included AC adapter to charge the receiver’s internal battery.

11. Lock Screw - Turn left to loosen the screw and adjust the mounting arm. Turn

right to lock the mounting arm in place.

Go Mic Mobile Receiver (GMM) Callouts

Go Mic Mobile

12. Adjustable Mounting

Arm - This mounting arm

is adjustable to affix

the GMM Receiver to a

smartphone. To adjust,

loosen the Lock Screw

on the top of the GMM

Receiver. To fix the arm

in place, tighten the Lock

Screw.

Note: The Adjustable

Mounting Arm can be

removed by loosening

the Lock Screw, sliding

the arm to the closed

position, then unscrew the

Lock Screw completely

and remove. Now slide

the Mounting Arm out of

the GMM Receiver and

replace the Lock Screw.

13. Fixed Mounting Arm - This fixed mounting

arm is used to mount the GMM Receiver

to a smartphone. A 1/4”-20 adapter

is included to mount the GMM to a

standard camera tripod. To remove the

fixed mounting arm, unscrew the two

Phillips screws.

14. Cold Shoe Adapter - This removable shoe

mount adapter is used to affix the GMM

Receiver to a camera or mobile filming

case.

15. Hook and Loop Area - Use the included

self adhesive hook and loop pieces

to affix the GMM to a tablet. Before

attaching the GMM to a tablet, remove

the standard mounting arms and/or cold

shoe adapter.

Go Mic Mobile Receiver (GMM) Callouts

Owner’s Manual

ENGLISH

FRANÇAISDEUTSCHEESPAÑOLITALIANOPOLSKI

HXD2 Handheld Transmitter Callouts

1. Status Indicator - This LED displays

the operation mode.

2. Power/Pair Switch - Press <5 seconds

to turn the unit on or off. Press >5

seconds to enter pairing mode.

3. Battery Cover - Unscrew the battery

cover and slide down to open the

Go Mic Mobile Handheld battery

compartment.

4. Battery Holder - Open the battery

holder by pressing the tab and lifting

the cover. Insert two standard AA

(LR6) batteries here, being sure to

observe the plus and minus polarity

markings shown.

WARNING: Do not insert the batteries

backwards; doing so can cause

severe damage to the transmitter

and will void your warranty.

5. Input GAIN Control - This control

adjusts the transmitter input

sensitivity. This input sensitivity

control has been factory preset

to provide optimum level for the

particular microphone capsule

provided with the Go Mic Mobile

system and so we recommend that

this not be adjusted manually. If

necessary, however, you can use the

supplied plastic screwdriver to raise

or lower the input level.

6. Plastic Screwdriver - Used to adjust

the input GAIN control.

Go Mic Mobile

1. Input Connector - Connect the input device

via the mini-XLR connector. The PXD2 is

supplied with a lavalier microphone.

2. Status Indicator - This LED displays the

operation mode

3. Power/Pair Switch - Press <5 seconds to turn

the unit on or off. Press >5 seconds to enter

pairing mode.

4. Input GAIN Control - This control adjusts the

transmitter input sensitivity.

5. Battery Holder - Insert two standard AA (LR6)

batteries here, being sure to observe the plus

and minus polarity markings shown.

WARNING: Do not insert the batteries

backwards; doing so can cause severe

damage to the PXD2 and will void your

warranty.

6. Plastic Screwdriver - Used to adjust the input

GAIN control.

PXD2 Belt Pack Transmitter Callouts

12 3

Otros manuales para Go Mic

Tabla de contenidos

Idiomas:

Otros manuales de Sistema de micrófono de Samson

Samson

Samson Stage 266: Dual Handheld Wireless System Manual de usuario

Samson

Samson VHF Micro VHF Micro TRUE DIVERSITY WIRELESS Manual de usuario

Samson

Samson CONCERT SERIES IV Manual de usuario

Samson

Samson VLX Manual de usuario

Samson

Samson VHF Series Manual de usuario

Samson

Samson EXPEDITION XP40iw Manual de usuario

Samson

Samson XPD2m Manual de usuario

Samson

Samson AIRLINE CR77 Manual de usuario

Samson

Samson Airline 77 Manual de usuario

Samson

Samson UHF Micro 32 Manual de usuario

Samson

Samson Stage 212 Manual de usuario

Samson

Samson AirLine Manual de usuario

Samson

Samson Airline 77 Manual de usuario

Samson

Samson AirLine Manual de usuario

Samson

Samson Concert99 Manual de usuario

Samson

Samson CT7 Manual de usuario

Samson

Samson UHF 801 Manual de usuario

Samson

Samson AIRLINE CR77 Manual de usuario

Samson

Samson Stage v166 Manual de usuario

Samson

Samson XPD2 Manual de usuario

Samson

Samson Airline 77 Manual de usuario

Samson

Samson WSM Wireless System Manager for Windows 95 Manual de usuario

Samson

Samson CONCERT 99 Manual de usuario

Samson

Samson Concert88 Manual de usuario

Manuales populares de Sistema de micrófono de otras marcas

Paso

Paso R824 Manual de usuario

Naxa

Naxa NAM-982 Manual de usuario

Motorola

Motorola PMNN4461 Manual de usuario

Xvive

Xvive U3 Manual de usuario

Tekon

Tekon DUOS Manual de usuario

Heyuan Intelligence

Heyuan Intelligence IOT-G2S-01 Manual de usuario

Devine

Devine WMD-IE Manual de usuario

LG LF-D7150 Manual de usuario

GE S768DAV Manual de usuario

LD U305 HBH 2 Manual de usuario

Chainway

Chainway URA8 Manual de usuario

ORATOR

ORATOR D860TD Manual de usuario

Sennheiser

Sennheiser Evolution Wireless Digital EW-DX EM 2 Manual de usuario

Alpha Technologies

Alpha Technologies RBMS Manual de usuario

SWIT Electronics Co.,LTD.

SWIT Electronics Co.,LTD. CW-S150 Manual de usuario

Shure

Shure UA844 Manual de usuario

Panasonic

Panasonic SHFX70 - DVD HOME THEATER WIRELESS SYSTEM Manual de usuario

Pyle

Pyle PDWM5000 Manual de usuario
