Salter Brecknell B 130 Manual de usuario

p/n AWT35-500632 issue AA July 2010

MODEL B 130

Counting Scale

User Manual

General information and warnings

Special messages

Examples of special messages you will see in this manual are defined below. The

signal words have specific meanings to alert you to additional information or the

relative level of hazard.

DANGER!

THIS IS A DANGER SYMBOL.

DANGER MEANS THAT FAILURE TO FOLLOW SPECIFIC

PRACTICES OR PROCEDURES WILL CAUSE INJURY OR DEATH.

ELECTRICAL WARNING!

THIS IS AN ELECTRICAL WARNING SYMBOL.

ELECTRICAL WARNINGS MEAN THAT FAILURE TO FOLLOW

SPECIFIC PRACTICES OR PROCEDURES MAY RESULT IN

ELECTROCUTION, ARC BURNS, EXPLOSIONS OR OTHER

HAZARDS THAT MAY CAUSE INJURY OR DEATH.

WARNING!

This is a Warning symbol.

Warnings mean that failure to follow specific practices and procedures may

have major consequences such as injury or death.

CAUTION!

This is a Caution symbol.

Cautions give information about procedures that, if not observed, could

result in damage to equipment or corruption to and loss of data.

NOTE: This is a Note symbol. Notes give additional and important information,

hints and tips that help you to use your product.

Installation

Electrical installation

Pluggable equipment

Pluggable equipment must be installed near an easily accessible socket outlet.

Permanently wired equipment - Isolator requirements

Permanently connected equipment must have a readily accessible disconnect

device incorporated in the fixed wiring such as an isolator or circuit breaker with at

least 3mm contact separation.

The isolator MUST NOT be installed into the flexible power cable supplied with the

unit.

DANGER: RISK OF ELECTRICAL SHOCK. NO USER SERVICEABLE

PARTS. REFER TO QUALIFIED SERVICE PERSONNEL FOR

SERVICE.

CAUTION: The power cable must be connected to an earth-grounded

electrical outlet. The electrical supply must have a circuit breaker with an

appropriate rating to protect from over-current conditions.

For your protection, all electrical (110V or 230V) equipment used out of

doors or in wet or damp conditions should be supplied from a correctly

fused power source and protected by an approved ground fault protection

device (RCD, GFCI etc.)

IF IN DOUBT SEEK ADVICE FROM A QUALIFIED ELECTRICIAN.

Safe handling of equipment with batteries

Wet conditions

Under wet conditions, the plug must be connected to the final branch circuit via an

appropriate socket / receptacle designed for washdown use.

Installations within the USA should use a cover that meets NEMA 3R

specifications as required by the National Electrical Code under section 410-57.

This allows the unit to be plugged in with a rain tight cover fitted over the plug.

Installations within Europe must use a socket which provides a minimum of IP56

protection to the plug / cable assembly. Care must be taken to make sure that the

degree of protection provided by the socket is suitable for the environment.

Routine maintenance

Always turn off the machine and isolate from the power supply before starting any

routine maintenance to avoid the possibility of electric shock.

Make sure that it is placed securely on a flat and level surface.

CAUTION: Danger of explosion if battery is incorrectly replaced. Replace

only with the same or equivalent type recommended by the manufacturer.

Dispose of used batteries according to the manufacturer’s instructions.

ATTENTION: Il y a danger d'explosion s'il y a remplacement incorrect de la

batterie, remplacer uniquement avec une batterie du même type ou d'un

type équivalent recommandé par le constructeur. Mettre au rebut les

batteries usagées conformément aux instructions du fabricant.

IMPORTANT: This equipment must be routinely checked for proper

operation and calibration.

Application and usage will determine the frequency of calibration required

for safe operation.

Cleaning the machine

Training

Do not attempt to operate or complete any procedure on a machine unless you

have received the appropriate training or read the instruction books.

To avoid the risk of RSI (Repetitive Strain Injury), place the machine on a surface

which is ergonomically satisfactory to the user. Take frequent breaks during

prolonged usage.

Sharp objects

Do not use sharp objects such as screwdrivers or long fingernails to operate the

keys.

FCC and EMC declarations of compliance

United States

Canada

European Countries

Table 1.1 Cleaning DOs and DON’Ts

DO DO NOT

Wipe down the outside of standard products

with a clean cloth, moistened with water and

a small amount of mild detergent

Attempt to clean the inside of the machine

Use harsh abrasives, solvents, scouring cleaners or

alkaline cleaning solutions

Spray the cloth when using a proprietary

cleaning fluid

Spray any liquid directly on to the display windows

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio

Interference Regulations of the Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils

numériques de la Classe A prescrites dans le Règlement sur le brouillage radioélectrique edicté par le ministère des

Communications du Canada.

WARNING: This is a Class A product. In a domestic environment, this product may cause radio interference in which the user

may be required to take adequate measures.

Connect the red wire to the red battery terminal and the black wire to the black

battery terminal.

Place battery in the compartment with the padding placed as shown and

replace the battery cover and tighten the screw.

Note: To improve battery life, turn off the scale using the power switch.

3.0 Front Panel

The front panel, shown in Figure 1, consists of three display windows

(WEIGHT, PIECE WEIGHT, and COUNT), the keypad, nine annunciators and

the bubble level window.

Figure 1: B130 front panel

Annunciators

Annunciators are bright LEDs next to symbols or text. They appear below the

three displays and each is explained below.

Under the WEIGHT display:

Zero This lights when the weight on the scale is at 0.

Tare This lights when a tare is in effect. Weight displayed is net weight.

kg This lights when the unit of measure in the WEIGHT display is

kilograms.

lb This lights when the unit of measure in the WEIGHT display is

pounds.

Under the PIECE WEIGHT display:

gThis lights when the PIECE WEIGHT unit of measure is grams.

lb This lights when the PIECE WEIGHT unit of measure is pounds.

Under the COUNT display:

Low Batt This lights when the battery power is low. Recharge the battery or

use AC power to continue using the scale.

AC This lights when the AC power is connected to the scale.

CHG This lights when the battery is charging.

B 130

Key Functions

Each of the keys shown in Figure 2 is explained below.

Figure 2: B 130 keypad

0-9Used for keyboard entry of piece weight, sample size, and upper

and lower limit settings.

Units lb/kg Used to switch displayed weights between kg and lb, and piece

weight units between grams and decimal pounds.

Zero Return displayed weights and counts to zero for accurate

weighing and counting. Zero range capability is 5% of scale

capacity.

Enter Used to confirm or save entered data from keyboard.

Tare Used to zero off, up to 100% of capacity, an empty container or

weight, not required in the calculation of an average piece weight.

Use of tare will reduce the scale’s maximum weight capacity, by

the tare value stored.

Accu + Used to add the displayed counts to a piece count accumulator

(Memory +) and only accumulate when there is a percentage of

weight change.

Clear Erase a keyed in value from the display if an error has been

made.

Pcwt (stands for Piece Weight) Used for keyboard entry of a known

average piece weight.

Upper Used to set an upper limit quantity for count check feature.

Lower Used to set lower limit quantity for count check feature.

On/Off Used to turn off display for extended battery life or to reset the

scale to normal weighing mode.

B 130

4.0 Scale Operation

This section covers the various scale operations, such as weighing, counting,

accumulation, etc.

Simple Weighing

1. Turn the scale on and zero the display, if necessary, by pressing the Zero

key. Be sure the scale is displaying weight in your preferred unit of

measure. Change it using the Units key, if necessary.

2. Place item(s) to be weighed on the scale…

Weight of the item(s) is displayed in the WEIGHT window.

3. Remove the item(s) from the scale and repeat steps 1-3 to weigh the

next item(s).

Tare Weighing

If you want to do net weighing, such as weighing objects in a container, follow

these steps:

1. Turn the scale on and zero the display, if necessary, by pressing the Zero

key. Be sure the scale is displaying weight in your preferred unit of

measure. Change it using the Units key, if necessary.

2. Place the item to be tared (usually a container) on the scale…

Weight of the item is displayed in the WEIGHT window.

3. Press the Tare key…

The weight is tared, 0 weight is displayed and the Tare annunciator

lights.

4. Place item(s) to be weighed on the scale…

Net weight of the item(s) is displayed.

5. To remove a tare, remove everything from the scale platform and press

the Tare key…

0 weight is di

splayed and the Tare annunciator light turns off. The unit

is now in gross weighing mode.

6. Repeat the steps above for other tare weighments.
