Ruijie RG-IS2700-P Series Manual de instalación

RG-IS2700-P Series PoE Switch

RGOS Command Reference

Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification,

transmission, translation or commercial use of this document or any portion of this document, in any form or by any means,

without the prior written consent of Ruijie Networks is prohibited.

Exemption Statement

This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain

the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will

not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

Preface

Thank you for using our products. This manual matches the RGOS Firmware Version 1.00.xx.

Audience

This manual is intended for:

Network engineers

Technical support and servicing engineers

Network administrators

Obtaining Technical Assistance

Ruijie Networks Website: https://www.ruijienetworks.com/

Technical Support Website: https://ruijienetworks.com/support

Case Portal: http://caseportal.ruijienetworks.com

Community: http://community.ruijienetworks.com

Technical Support Email: [email protected]

Skype: [email protected]

Related Documents

Documents

Description

Hardware Installation and Reference

Guide

Describes the functional and physical features and provides the device

installation steps, hardware troubleshooting, module technical specifications,

and specifications and usage guidelines for cables and connectors.

L2 Features Configuration Commands

1. Port Configuration Commands

2. MAC Address Table

3. Jumbo Frame Commands

4. Flow Control Commands

5. Spanning Tree Commands

6. VLAN Commands

7. Q-in-Q Commands

8. Link Aggregation Commands

9. GARP Commands

10.GVRP Commands

11.Port Mirror Commands

12.LLDP Commands

Command Reference Port Configuration Commands

1 Port Configuration Commands

1.1 [no] shutdown

Use "shutdown" command to disable port and use "no shutdown" to enable port. If port is error

disabled for any reason, use "no shutdown" command to recover the port manually.

[no] shutdown

Command

Mode

Privileged EXEC mode

Configuration

Examples

This example shows how to disable one of the ports.

switch(config)# interface gi1

switch(config-if)# shutdown"

1.2 speed

Use "speed" command to change port speed configuration. The speed is only able to configure to the

physical maximum speed. For example, in fast Ethernet port, speed 1000 is not available.

speed (10|100)

speed (1000|)

speed auto[(10|100|10/100)]

speed auto[(1000|)]

Command

Mode

Privileged EXEC mode

Configuration

Examples

This example shows how to modify port speed configuration.

switch(config)# interface gi2

switch(config-if)# speed auto 10/100

1.3 duplex(auto|full|half)

Use "duplex" command to change port duplex configuration.

duplex(auto|full|half)

Command

Mode

Privileged EXEC mode

Configuration

Examples

This example shows how to modify port duplex configuration.

switch(config)# interface gi1

switch(config-if)# duplex full

switch(config-if)# exit

Command Reference Port Configuration Commands

switch(config)# interface gi2

switch(config-if)# duplex half

1.4 description

Use "description" command to give the port a name to identify it easily. If description includes space

character, please use double quotes to wrap it.

description string

Command

Mode

Privileged EXEC mode

Configuration

Examples

This example shows how to modify port descriptions.

switch(config)# interface gi2

switch(config-if)# description "uplink port"

1.5 no description

Use no form to restore description to empty string.

no description

Command

Mode

Privileged EXEC mode

1.6 [no] protected

Use "protected" command to protect port. Protected port is only allowed to communicate with

unprotected port. In other words, protected port is not allowed to communicate with another protected

port. Use no form to make port unprotected.

[no] protected

Command

Mode

Privileged EXEC mode

Configuration

Examples

This example shows how to configure ports gi1 and gi2 as protected ports.

switch(config)# interface range gi1-2

switch(config-if-range)# protected

Command Reference MACAddress Table Commands

2 MAC Address Table Commands

2.1 show mac address- table aging-time

View the aging time of the address table.

show mac address-table aging-time

Command

Mode

User EXEC mode

Configuration

Examples

switch# show mac address-table aging-time

2.2 show mac address-table A:B:C:D:E:F

Displays entries for a specific MAC address (for all or VLAN).

show mac address-table A:B:C:D:E:F [vlan <1-4094>]

Command

Mode

User EXEC mode

Configuration

Examples

switch# show mac address-table 0:1:2:3:4:5 vlan 1

2.3 show mac address- table

View MAC entry on specified interface or VLAN or all dynamic MAC entries in MAC address table.

show mac address-table [vlan <14094>] [interfaces IF_PORTS]

Command

Mode

User EXEC mode

Configuration

Examples

switch# show mac address-table vlan 1 interface gi5

2.4 show mac address- table static

View static MAC entry on specified interface or VLAN or all dynamic MAC entries in MAC address

table.

show mac address-table static [vlan <1-4094>] [interfaces IF_PORTS]

Command

Mode

User EXEC mode

Configuration

Examples

switch# show mac address-table static vlan 1 interface gi5

Command Reference MACAddress Table Commands

2.5 show mac address- table dynamic

View dynamic MAC entry on specified interface or VLAN or all dynamic MAC entries in MAC address

table.

show mac address-table dynamic [vlan <1-4094>] [interfaces IF_PORTS]

Command

Mode

User EXEC mode

Configuration

Examples

switch# show mac address-table dynamic vlan 1 interface gi5

2.6 show mac address- table counters

Display the number of addresses present in MAC address table.

show mac address-table counters

Command

Mode

User EXEC mode

Configuration

Examples

switch# show mac address-table counters

2.7 clear mac address- table dynamic

Delete dynamic MAC entry on specified interface or all dynamic MAC entries in MAC address table.

clear mac address-table dynamic [interfaces IF_PORTS]

Command

Mode

Privileged EXEC mode

Configuration

Examples

switch(config)# clear mac address-table dynamic interfaces gi5

2.8 clear mac address- table dynamic vlan

Delete dynamic MAC entry on specified VLAN dynamic MAC entry in MAC address table.

clear mac address-table dynamic vlan <1-4094>

Command

Mode

Privileged EXEC mode

Configuration

Examples

switch(config)# clear mac address-table dynamic vlan 1

2.9 mac address-table aging-time

Set the aging time of the address table.

mac address-table aging-time <10630>

Command Reference MACAddress Table Commands

Command

Mode

Privileged EXEC mode

Configuration

Examples

switch(config)# mac address-table aging-time 300

2.10 mac address-table static A:B:C:D:E:F vlan

Add static addresses to the MAC address table.

mac address-table static A:B:C:D:E:F vlan <1-4094> interfaces IF_PORTS

Command

Mode

Privileged EXEC mode

Configuration

Examples

switch(config)# mac address-table static 0:1:2:3:4:5 vlan 1 interfaces gi5

2.11 no mac address-table static A:B:C:D:E:F vlan

Delete static addresses from the MAC address table.

no mac address-table static A:B:C:D:E:F vlan <1-4094>

Command

Mode

Privileged EXEC mode

Configuration

Examples

switch(config)# no mac address-table static 0:1:2:3:4:5 vlan 1 interfaces gi5

Command Reference Jumbo Frame Commands

3 Jumbo Frame Commands

3.1 jumbo-frame

Use "jumbo-frame" com-mand to modify maximum frame size. The only way to show this

configuration is by using "show running-config" command.

jumbo-frame <1518- 9216>

Command

Mode

Privileged EXEC mode

Configuration

Examples

This example shows how to modify maximum frame size to 9216 bytes.

switch(config)# jumbo-frame 9216

3.2 no jumbo-frame

Use no form to disable jumbo-frame.table.

no jumbo-frame

Command

Mode

Privileged EXEC mode

Configuration

Examples

switch(config)# no jumbo-frame

4 Flow Control Commands

4.1 [no] back-pressure

Use " back-pressure " command to change port back pressure configuration. Use no form to restore

back-pressure to default (off) configuration.

[no] back-pressure

Command

Mode

Privileged EXEC mode

Configuration

Examples

This example shows how to modify port duplex configuration.

switch(config)# interface gi1

switch(config-if)# back-pressure

switch(config-if)# no back-pressure

4.2 flowcontrol

Use " flow-control " command to change port flow control configuration. Use off form to restore flow

control to default (off) configuration.
