RoyalTek GPS SPEED CAMERA WARNING DEVICE RCD-1000 Manual de usuario

English 1

RCD-1000

GPS Speed Camera Warning Device

Quick Guide

Congratulations on your purchase of the GPS Camera warning device.

The Detector is equipped with the latest generation SiRF Star III digital

processor specially designed for fast and accurate fix on GPS signals. The

RCD-1000 will help you to drive safely, when the database has been

downloaded, the device will compare your position using its built-in GPS

antenna with the position of every known danger locations and give you an

audible and visual warning as you approach them.

With the latest in GPS technology, RCD-1000 device also can become a GPS

Receiver to deliver GPS information.

Before starting using the device please refer to the following for content

checking.

Contents packaged with your GPS Device purchase:

1. GPS Camera Warning Detector

2. USB cable

3. Car Charger

4. External antenna (optional)

5. Dashboard Pad

English 2

Button, Mini USB, Volume Control & External Antenna Port

(1) The POI record Button: Press for more than 2 seconds to record current

position.

A short beep sound will inform you that the POI has been successfully store

User can manage the POI information via the supplied software.

Note: The POI Record Button function will be enabled after GPS

is fixed and the Camera database is pre-uploaded into memory

successfully.

(2) The Speed limit setting Button: Press for more than 2 seconds to record

current speed of your vehicle. A short beep sound will inform you that current

speed limit has been successfully done. If you exceed the speed limit, the

device will beep until your speed fall below the limit. To cancel the setting,

press the button for more than 2 seconds again.

(3) Volume control: Rotate forward and backward to adjust the volume.

POI Button

Mini USB Port

External Antenna Port

Volume Control

Speed Limit button

English 3

LED Display & Audio Alarm

Front View

21 3

English 4

Event LED Display Audio Alarm

1 System Initialize Green+ Red (No 1+No 2+No3),

Sweeping

1 beep

2 GPS Search Green (No.1) Blinking

3 GPS is fixed Green (No.1) Glowing 2 beeps after

GPS Fixed

4 Memory full /Erase Red (No 2) Glowing/Blinking X

Not exceed

speed

Glowing 3 beeps

Approach

Certified

Camera Zone

and pre-alert

(distance less

than 500 meter)

Over speed Red (No

2+No3) Blinking 1 time

per second

Continuous

1 beeps for 3

seconds

continuously

Not exceed

speed

Glowing 3 beeps6 Approach

Certified

Camera Zone

and pre-alert

(distance less

than 300 meter)

Over speed Red (No 1+No

2+No3) Blinking 1 time

per second

Continuous

3 beeps per

second

continuously

Not exceed

speed

Glowing 3 beeps

7 Approach User

defined POI and

pre-alert

(distance less

than 500 meter)

Over speed

Amber (No

2+No3) Blinking 1 time

per second

Continuous

1 beeps for 3

seconds

continuously

Not exceed

speed

Glowing 3 beeps

8 Approach User

defined POI and

pre-alert

(distance less

than 300 meter)

Over speed

Amber (No

1+No 2+No3) Blinking 1 time

per second

Continuous

1 beeps for 3

seconds

continuously

9 User Defined POI Function

activated

Green (No 1+No 2+No3),

Flashing once

1 beep

10 User Defined POI full Amber (No.2), Glowing X

11 Speed Limit function enable Red (No.3), Glowing 1 beep per

second

12 Speed Limit function disable X 3 beeps

13 Over Speed only (W/O Camera

or POI Zone)

Amber (No.3), Blinking 1 beep for

3seconds

continuously

English 5

Connect to PC or Notebook for “Speed Camera Detector Utility”

 User can upload the Camera database and manage the POI using the

supplied “Speed Camera Detector Utility”.

 User also can download the GPS log file to PC/Notebook supplied

software.

 Refer to the supplied software application user manual to install the

software utility.

Connect to PC or Notebook for Update Camera Database

 User can update the Camera Database using the supplied software.

 Refer to the supplied software application user manual to install the

software utility.

Tips

1. Use the supplied dashboard pad, remove the backing from the base, fix it

on the dashboard as close to the windscreen as possible in clear view of

the driver’s line of the sight and place your Detector onto the pad

2. Cars that are equipped with heat dissipation films for the windshield and

windows will degrade the GPS performance.

3. For the most accurate position fix results and quickest acquisition time,

please make sure that your device is not in motion but stationary and in

open spaces.

FEDERAL COMMUNICATIONS COMMISSION

INTERFERENCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

CAUTION:

Any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

"This device complies with Part 15 of the FCC Rules.Operation is subject to the following two

conditions:

(1) this device may not cause harmful interference and(2) this device must accept any

interference received, including interference that may cause undesired operation ."
