Rointe Kyros Manual
Class II
KYROS
INSTRUCTION MANUAL
TOWEL RAILS
Mounting, installation, starting and operation
2
KYROS
Thank you very much for choosing Rointe.
Before using the low consumption KYROS digital electric towel rail,
we recommend you read this instruction manual thoroughly.
IMPORTANT:
This manual should be left with the product after installation.
Thank you.
3
CONTENTS
1. KYROS Towel Rail Information ........................................................................................ 4
1.1. Control Panel.............................................................................................................. 4
1.2. Switching On and Off (stand-by)............................................................................... 6
1.3. Adjust the Day/Time .................................................................................................. 6
1.4. Temperature Selection............................................................................................... 7
1.5. Locking the Keypad... ................................................................................................ 8
1.6. Main Menu ..................................................................................................................9
1.6.1 Setting sub-menu .............................................................................................9
1.6.2 Energy sub-menu ........................................................................................... 11
1.6.3 Balance sub-menu ..........................................................................................13
1.6.4 Program sub-menu......................................................................................... 13
1.7. OPEN WINDOWS function....................................................................................... 21
2. Mounting ........................................................................................................................ 22
3. Connecting .................................................................................................................... 23
3.1. Technical Characteristics........................................................................................ 24
3.2. Specific Regulations for Bathrooms....................................................................... 25
4. Maintenance & Cleaning................................................................................................. 25
4.1. Safety Precautions.................................................................................................. 25
5. Guarantee ...................................................................................................................... 25
4
KYROS
1. KYROS Towel Rail Information
1.1. Control Panel
1.1.1. Keypad
1.1.2. Display Panel
NO. INDICATION
1Programming
2Days Of The Week
3Time Of Day
4Temperature Selected
5Control Panel Locked / Unlocked indicator
6MANUAL / AUTOMATIC / PILOT WIRE
function indicator
7COMFORT / ECO / ANTI-FROST
mode indicator
8Heating Element On indicator
9Consumption indicator
10 OPEN WINDOWS function indicator
1
2
3
4
10 9
87
6
5
ICON INDICATION
On / Off - Accept
Decrease Temperature - Move left
Increase Temperature - Move right
Access/Back to Menu - Move up
Manual/Automatic - Move down
5
ICON INDICATION
OPEN WINDOWS function - active mode, no detection
OPEN WINDOWS function - active mode, detected
Energy Consumption indicator - green / yellow / red
Heating Element on
COMFORT mode on
ECO mode on
ANTI-FROST mode on
AUTOMATIC function on
MANUAL function on
PILOT WIRE function on
AUTOMATIC function on when USER mode activated
MANUAL function on when USER mode activated
PILOT WIRE function on when USER mode activated
Control Panel locked through Keypad
Control Panel locked through Remote Control
Not available in UK. Only upon demand.
Not available in UK. Only upon demand.
6
KYROS
1.2. Switching On and Off (stand-by)
To switch the product ON, please press the button once.
The image to the right will appear on the display panel when the product
is switched on.
After 5 seconds the temperature, time and days of the week will be
displayed on the display panel.
To switch the product OFF, please press the button again once.
The product will go into stand-by mode with the word ‘STAND-BY’
displayed on the display panel.
After 5 seconds the Rointe logo will appear.
1.3. Adjust the Day and Time
To set the day and time, please press the button on the keypad panel
to access the Main Menu.
Select the `Settings´ menu icon using the or buttons on the
keypad.
To move left press the button and to move right press the button.
Once the icon is highlighted on the display panel, press to access.
7
Now use the and buttons again to select the clock option and
press to access.
Use the buttons and to set the hour, then press to confirm.
Then use the and buttons to set the minutes and press to
confirm. Finally, use the and buttons to set the day (1 = Monday,
2 = Tuesday etc.) and confirm by pressing the button.
1.4. Temperature Selection
To change the temperature, please press the or the button. To
decrease the temperature press the button and to increase the
temperature press the button.
When the room temperature is lower than the set temperature on the display
panel, the product will come on with the symbol appearing in the top
right of the display panel.
8
KYROS
1.5. Locking the Keypad
You can lock the keypad from the product or from your remote control* (optional).
TO LOCK USING THE KEYPAD:
To lock the keypad manually, please hold and press the button AND the
button TOGETHER for 3 seconds.
The symbol will appear on the display panel and the keys will not respond.
To unlock the keypad manually, please hold and press the button AND
the button TOGETHER for 3 seconds.
*To lock the keypad using your remote control, please see the corresponding
instruction manual for your remote control separately.
Please note that if you lock your product using your remote control then you
can only unlock using your remote control. If your product is locked using
your remote control and you press the control panel on your product then
the following image will appear on the display panel.
9
1.6. Main Menu
The Main Menu of your product is accessed by pressing the menu
button.
You can navigate through the different options available on the menu by
pressing the and buttons to move left and right respectively and
to scroll through all 4 options.
The selected sub-menu will be highlighted with a frame, as shown in the
image to the right on the `Settings´ section of the display panel.
The below icons displayed on the screen take you to the following sub-
menus:
Settings Energy Balance Program
1.6.1. Main Menu: Settings sub-menu
The `Settings´ sub-menu configures the technical parameters of your
product. To access, select the icon displayed in the Main Menu screen
and press to confirm.
Use the and buttons to move across the different options on the
sub-menu to choose your parameter and press .
The below icons displayed on the screen take you to the following
parameters:
Clear
Memory
Display Panel
brightness Clear Memory Language Time
10
KYROS
• Adjust brightness of the Display Panel
This allows you to change the brightness of the display panel in both the
STAND-BY and ON modes separately. To change the brightness ensure
the icon is highlighted and press the button to access. Then with
the buttons and you can switch between the two modes.
With the buttons and you can increase or decrease the brightness
as you wish.
The cursor indicates the intensity of the light. Once you have set the required
brightness press the button to save and exit.
• Clear the Memory Clear
Memory
This allows you to clear any information saved in your product.
To clear the memory ensure the Clear
Memory icon is highlighted in the `Settings´
sub-menu and press the button to confirm.
The display panel will show when completed and the language will change
to default.
• Change the Language
To set your chosen language, ensure the icon is highlighted in the
`Settings´ sub-menu and press the button to access.
Use the and buttons to move up or down respectively until your
chosen language is highlighted and confirm by pressing the button.
LANGUAGE
ENGLISH
FRANÇAIS
ESPAÑOL
PORTUGUÊS
