Reolink RLC-842A Guía de inicio rápido
Operational
Apply to: RLC-842A, RLC-542WA
Instruction
EN/DE/FR/IT/ES
1 2
What's in the Box 2
Camera Introduction 3
Connection Diagram 7
Set up the Camera 8
Mount the Camera 9
Troubleshooting 12
Specication 13
NoticationofCompliance 14
What's in the Box
Quick Start Guide
Camera Antenna * Waterproof Lid Power Adapter *
4.5M Power *
Extension Cable
Pack of Screws
Mounting Hole
Template
1M
Ethernet Cable
Surveillance Sign
Mounting Wrench
EN
Content
NOTE:
*Thepoweradapter,antennasand4.5mpowerextensioncableonly
comewithWiFicamera.
*Quantityofaccessoriesvarieswiththecameramodelyoupurchase.
3 4
Camera Introduction
Antenna
Lens
lnfrared Lights
Built-in Mic
Mount
SD Card Slot
Waterproof Lid
Power Port(Optional)
Reset Button
Network Cable
*Pressforabout10secondstorestorethe
devicetofactorysettings.
WiFi Camera
5 6
PoE Camera
Lens
lnfrared Lights
Built-in Mic
Mount
SD Card Slot
Waterproof Lid
Power Port(Optional)
Reset Button
Network Cable
*Pressforabout10secondstorestorethe
devicetofactorysettings.
7 8
Connection Diagram
Beforeinitialsetup,followthestepsbelowtoconnectyourcamera.
1.ConnectthecameratoaLANportonyourrouterwithanEthernet
cable.
2.Usethepoweradaptertopoweronthecamera.
NOTE: The connection diagram takes the WiFi Camera as an example
andalsoapplytothePoEcamera.ForPoECamera,pleasepowerthe
camerawithaPoESwitch/Injector/ReolinkPoENVRoraDC12Vpower
adapter.(notincludedinthepackage)
Camera
Network Cable
Router
Power Cable
PowerAdapter
Set up the Camera
• On Smartphone
Scan to download
theReolinkApp.
DownloadandlaunchtheReolinkApporClientsoftware,andfollowthe
onscreeninstructionstonishinitialsetup.
NOTE:
•WhensettinguptheWiFicamera,youneedtofollowtheonscreen
instructionstonishtheWiFicongurationrst.
•IfyouareconnectingthePoEcameratoaReolinkPoENVR,pleaseset
upthecameraviatheNVRinterface.
English English
9 10
Mount the Camera
•Donotfacethecameratowardsanylightsources.
•Donotpointthecameratowardsaglasswindow.Or,itmayresultin
poorimagequalitybecauseofthewindowglarebyinfraredLEDs,
ambientlightsorstatuslights.
• Do not place the camera in a shaded area and point it towards a
well-litarea.Or,itmayresultinpoorimagequality.Toensurebestimage
quality,thelightingconditionforboththecameraandthecaptureobject
shallbethesame.
•Toensurebetterimagequality,it’srecommendedtocleanthedome
coverwithasoftclothfromtimetotime.
•Makesurethepowerportsarenotdirectlyexposedtowateror
moistureandnotblockedbydirtorotherelements.
•WithIPwaterproofratings,thecameracanworkproperlyunder
conditionslikerainandsnow.However,itdoesn'tmeanthecameracan
workunderwater.
• Do not install the camera at places where rain and snow can hit the lens
directly.
•Thecameramayworkinextremecoldconditionsaslowas-25°C.
Becausewhenitispoweredon,thecamerawillproduceheat.Youmay
poweronthecameraindoorsforafewminutesbeforeinstallingit
outdoors.
Installation Tips
Install the Camera
Put the mounting template on
the ceiling and drill holes at the
indicatedlocations.
Screwthedomecoverowith
themountingwrench.
Screwthecameratotheceiling.
1
2
3
11 12
Loosenthetwoscrewsonboth
sidesofthecameraandadjust
thecameraviewingangle.
Tighten the screws and screw the
coverbacktothecamera.
4
5
Troubleshooting
•Makesureyourcameraispoweredonproperly.ThePoEcamerashould
bepoweredbyaPoEswitch/injector,aReolinkNVRora12Vpower
adapter.
•IfthecameraisconnectedtoaPoEdeviceaslistedabove,connectitto
anotherPoEportandcheckagain.
•TryagainwithanotherEthernetcable.
Ifyourcameraisnotpoweringon,pleasetrythefollowingsolutions:
Camera is not Powering on
For PoE Camera
For WiFi Camera
•Plugthecameraintoadierentoutletandseeifitworks.
•Poweronthecamerawithanotherworking12V1ADCadapterandsee
ifitworks.
Ifthesewon’twork,contactReolinkSupport.
NOTE:TheinstallationmethodstakethePoEcameraasanexampleand
alsoapplytotheWiFicamera.
13 14
Ifthepicturefromthecameraisnotclear,pleasetrythefollowing
solutions:
•Checkthecameradomecoverfordirt,dustorspiderwebs,pleaseclean
thedomecoverwithasoft,cleancloth.
•Pointthecameratoawell-litarea,thelightingconditionwillaectthe
picturequalityalot.
•Upgradethermwareofyourcameratothelatestversion.
•Restorethecameratofactorysettingsandcheckoutagain.
Picture is not Clear
Dimension:Φ133x100mm
Weight:685g
OperatingTemperature:-10°C~+55°C(14°F~131°F)
Notication of Compliance
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubject
tothefollowingtwoconditions:(1)thisdevicemaynotcauseharmful
interference,and(2)thisdevicemustacceptanyinterferencereceived,
includinginterferencethatmaycauseundesiredoperation.Changesor
modicationsnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser’sauthoritytooperatetheequipment.
FCC Compliance Statement
NOTE:ThefollowingnotesareonlyforWiFicamera.Thisequipment
hasbeentestedandfoundtocomplywiththelimitsforaClassBdigital
device,pursuanttoPart15oftheFCCRules.Theselimitsaredesigned
toprovidereasonableprotectionagainstharmfulinterferenceina
residentialinstallation.Thisequipmentgenerates,usesandcanradiate
radiofrequencyenergyand,ifnotinstalledandusedinaccordance
withtheinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethatinterferencewill
notoccurinaparticularinstallation.Ifthisequipmentdoescauseharmful
interferencetoradioortelevision,reception,whichcanbedetermined
byturningtheequipmentoandon,theuserisencouragedtotryto
Specication
InfraredNightVision:Upto30meters
Day/NightMode:Autoswitchover
AngleofView:Horizontal:90°~31°,Vertical:67°~24°
Hardware Features
General
OperatingHumidity:10%~90%
15 16
correcttheinterferencebyoneormoreofthefollowingmeasures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentandreceiver.
•Connecttheequipmentintoanoutletonacircuitdierentfromthatto
whichthereceiverisconnected.
•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
FCCRFwarningstatement:
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
Thedevicecanbeusedinportableexposureconditionwithoutrestriction.
ReolinkdeclaresthattheWiFicameraisincompliancewiththeessential
requirementsandotherrelevantprovisionsofDirective2014/53/EU,the
PoEcameraisincompliancewithDirective2014/30/EU.
Simplied EU Declaration of Conformity
Thisproductcomeswitha2-yearlimitedwarrantythatisvalidonlyif
purchasedfromReolinkOcialStoreoraReolinkauthorizedreseller.
.
Limited Warranty
NOTE: Wehopethatyouenjoythenewpurchase.Butifyouarenot
satisedwiththeproductandplantoreturn,westronglysuggestthat
youresetthecameratofactorydefaultsettingsbeforereturning.
UseoftheproductissubjecttoyouragreementtotheTermsofService
andPrivacyPolicy Keepoutofreachofchildren.
Terms and Privacy
ByusingtheProductSoftwarethatisembeddedontheReolinkproduct,
youagreetothetermsofthisEndUserLicenseAgreement(“EULA”)
betweenyouandReolink.
End User License Agreement
This marking indicates that this product should not be disposed with
otherhouseholdwastes.throughouttheEU.Topreventpossibleharmto
theenvironmentorhumanhealthfromuncontrolledwastedisposal,
recycleitresponsiblytopromotethesustainablereuseofmaterial
resources.Toreturnyouruseddevice,pleaseusethereturnand
collectionsystemsorcontacttheretailerwheretheproductwas
Correct Disposal of This Product
purchased.Theycantakethisproductforenvironmentallysaferecycling.
