Rancilio Classe 7E Manual de usuario

/ 7E TALL

Electronic control and automatic

dosing for practical preparation

with consistent results.

Rancilio has designed Classe 7 TALL

for all coee-based beverages that

require large cups/glasses.

The work surface is set at a lower

level than on the standard model,

allowing glasses up to 14.5 cm in

height to be used.

The TALL model can also be used to

dispense Italian espresso, thanks

to the removable plate that allows

cups to be placed the correct

distance from the group.

Classe 7 has an ergonomic lighting

system in the work area to make

the barista’s job easier plus

chrome group covers and all the

distinctive stylish accessories

from the Rancilio range.

The machine has a hot water

dispenser with programmable

time-controlled dosing.

Classe 7 is designed to combine functionality, ergonomics and a contemporary look.

Classe 7 is an essential, versatile machine made from tough materials, such as aluminium and steel, so it is very

sturdy and reliable. Available in a 2 groups compact version, or with 2 and 3 groups and also in a Tall version.

Technical Features

STANDARD FEATURES: 1 ﬁlter holder for 2 cups per group, 1 ﬁlter holder for 1 cup,

2 steam wands, 1 hot water dispenser with programmable time-controlled dosing,

coee tamper, measuring scoop and cleaning discs, levelling feet.

ACCESSORIES: automatic or manual DP water softener, MD dosing grinder,

interchangeable side panels.

Standard features, accessories

stainless steel and grey painted aluminium panels.

Materials

Technical Data

Classe 7E / 7E TALL

independent heat exchangers

electric heating

incorporated volumetric pump

boiler pressure gauge

automatic water level control

reduction to 2/3 of maximum power

electronic boiler temperature/pressure control

TALL version - H max cups/glasses: 5.7 in

standard and COMPACT version

LED lights in the work area (not available on the 2 groups COMPACT)

2 GROUPS COMPACT

2 GROUPS

23.2×19.5×20.5 in (590×495×520 mm)

29.5×19.5×20.5 in (750×495×520 mm)

dimensions (W×D×H)

boiler

boiler power

weight

voltage

120 V / 220-240 V / 380-415 V (3N)

5 l (1.1 galUK)

11 l (2.4 galUK)

3,200 W (120 V) - 3,000 W

3,200 W (120 V) - 4,300 W

121.2 lb (55 kg)

136.7 lb (62 kg)

frequency

50/60 Hz

3 GROUPS

39.0×19.5×20.5 in (990×495×520 mm)

dimensions (W×D×H) boiler

boiler power

weight

voltage

220-240 V / 380-415 V (3N)

16 l (3.5 galUK)

6,000 W

163.1 lb (74 kg)

Classe 7E - 3 groups - front view

Classe 7E TALL - 3 groups - front view

Classe 7E - 3 groups - rear view

Classe 7E - 3 groups - side view

Standard

On demand

www.ranciliogroup.com

Rapid setting

Smart power management Advanced diagnostics

Ergonomic ﬁlter holder Ergonomic work surface

ERGO-FILTER

HOLDER

Voltage stabilizer Ergonomic lighting (*) Ergonomic control panel

Gas heating (*)

Electric cup warmer

Pod and capsule adaptor

Ergonomic steam control Manual steam wand (*)

(*) not available for 2 groups COMPACT version
