Owner’s Manual

Please read before using this equipment.

6-In-One Light and

Learn Remote

2Contents



Contents

Features .................................................................. 3

A Quick Look at the Keys ..................................... 4

Preparation ............................................................. 7

Installing Batteries ............................................... 7

Device Types ....................................................... 9

Setting Up Your Remote ...................................... 9

Programming Favorite Channel Scan ............... 10

Resetting Scan ............................................... 11

Programming Macros ........................................ 12

Programming the Power Key ............................ 12

Resetting the Power Key .............................. 13

Reassigning Devices ......................................... 13

Resetting Reassigned Device Keys .............. 14

Programming Learning ...................................... 14

Learning Functions ....................................... 14

Deleting a Learned Function ......................... 15

Operation .............................................................. 15

Using the Remote .............................................. 15

Using the Light .................................................. 16

Using Channel Scan .......................................... 16

Using Favorite Channel Scan ............................ 17

Using Macros .................................................... 17

Using the Power Key ......................................... 17

Changing Volume Lock ..................................... 17

Volume Unlock on a Cable Convertor

or SAT/DSS Receiver .................................... 18

Volume Unlock on a VCR ............................. 18

Volume Unlock on a DVD ............................. 18

Volume Unlock on a CD Player ..................... 18

Volume Unlock on an Auxiliary Device ......... 19

Resetting Volume Lock to the

Original Settings ............................................ 19

Using the Sleep Timer ....................................... 19

Setting the Sleep Timer ................................. 19

Locking/Unlocking the Sleep Timer ............... 20

Using Home Theater ......................................... 20

Function Groups ........................................... 21

Device Groups .............................................. 21

RadioShack and RadioShack.com are

trademarks used by RadioShack Corporation.

Features

Enabling Home Theater ................................ 21

Using Home Theater ..................................... 22

Using Manual Code Search .............................. 23

Checking Your Code ..................................... 23

Troubleshooting ................................................... 24

Care ................................................................... 24

Manufacturers’ Codes ......................................... 25

Amplifier Codes ............................................. 25

Cable Codes ................................................. 26

CD Player Codes .......................................... 28

Home Automation Codes .............................. 31

Laser Disc Codes .......................................... 31

Miscellaneous Audio Codes .......................... 31

Video Codes .................................................. 32

Receiver Codes ............................................ 32

Satellite Codes .............................................. 34

Television Codes ........................................... 35

VCR Codes ................................................... 41

Television-VCR Combo Codes ..................... 45

DVD Player Codes ........................................ 47

Specifications ...................................................... 48



Features

Your Radio Shack 6-In-One Light and Learn Remote

allows you to control your TV, VCR, cable/SAT/DSS

converter, DVD player, CD player, and an auxiliary de-

vice with one easy-to-use remote control.

Its features include:

Home Theater Key — lets you access the function

keys of various home theater devices

Smart Keys — store and recall additional remote con-

trol functions

Sleep Timer — lets you program your TV or cable/

satellite system to turn off automatically

Extensive Searchable Code Library — contains re-

mote control codes for most available brands, includ-

ing discontinued devices

4A Quick Look at the Keys

Channel Scan — lets you “channel surf” all available

channels

Favorite Channel Scan — lets you “surf” up to 10 of

your favorite channels

Programmable Power Key — controls master on/off

of home entertainment devices with a single key press

Programmable Macro Keys — allow instant tuning to

favorite channels

Mode Reassignment — lets you add control of an-

other TV, VCR, DVD player or other auxiliary device in

place of an existing device.

Powerful Infrared Beam — lets you operate your

home entertainment devices from a greater distance

than with many of the original remote controls

Non-Volatile Memory — retains stored device codes

and any programmed settings when batteries are low

or must be replaced



A Quick Look at the

Keys

Your Radio Shack 6-In-One Remote controls the

most-used functions on your TV, VCR, cable/SAT/

DSS converter, DVD player, CD player, and auxiliary

device.

After you set up the remote control, its command keys

will work like the keys on your original remote controls.

For example, depending on the device you select (TV,

VCR, CBL/SAT, DVD, CD, or AUX) POWER operates

just like the POWER ON/OFF key on the remote con-

trol for your original TV, VCR, cable/SAT/DSS, DVD

player, CD player, or auxiliary device.

A Quick Look at the Keys

The following table lists all keys and how they func-

tion.

Key Function

PUse to program the remote control.

Use to turn the backlight on or off. When

on, any key press activates the back-

light. It stays on for up to 5 seconds after

the last key press.

TV,

VCR,

CBL/SAT,

and DVD

Use to set up the remote control to

replace the devices’ original remote

controls. In normal operation, use to

remotely select a desired device to con-

trol.

POWER,

VOL +,

VOL –,

CH +,

CH –,

LAST,

MUTE,

ENTER,

Digit Keys,

Transport Keys,

+100,

and

TV/VCR (A/B)

Use the same as the corresponding

keys on the original remote controls.

POWER can also be programmed for

ALL POWER on/off of selected devices

(see “Programming the Power Key” on

Page 12).

MENU,

GUIDE,

INFO,

and EXIT

Use to view interactive menus for TV,

VCR, CBL/SAT, and DVD.

MUSIC,

MOVIES,

SPORTS,

and NEWS

Use to program instant tuning of up to

three channels per category (see “Pro-

gramming Macros” on Page 12).

1S, 2S, 3S, 4S Use to learn or add functions that are

unique to your home entertainment sys-

tem.

SCAN (FAV) Use to scan all or only favorite channels

(see “Using Channel Scan” on Page 16

and “Using Favorite Channel Scan” on

Page 17).

SLEEP In the TV and CBL/SAT devices,

enables a device’s Sleep Timer (See

“Using the Sleep Timer” on Page 19).

6A Quick Look at the Keys

The following tables explain how selected keys func-

tion in different modes. For example, CH+ acts as a

Channel-Up key in TV, VCR, and CBL/SAT modes.

However, in DVD mode, CH+ acts as a Skip Forward

key.

THEATER Use to access function keys without

changing device remotes (See “Using

Home Theater” on Page 20).

Key TV VCR CBL/

SAT

GUIDE Guide Program Guide

MENU Menu Menu Menu

INFO Display Display Information

CH+ Channel Up Channel Up Channel Up

CH– Channel

Down Channel

Down

LAST Last Channel Last Channel Last

Channel

TV/VCR TV/VCR TV/VCR A/B

REW Punch

through to

VCR

Rewind Rewind

VCR/ Page

Down*

PLAY Punch

through to

VCR

Play Play VCR

FF Punch

through to

VCR

Fast Forward Fast For-

ward VCR/

Page Up*

REC Punch

through to

VCR

Record Record VCR

STOP Punch

through to

VCR

Stop Stop VCR

PAUSE Punch

through to

VCR

Pause Pause VCR

Key Function

Preparation

*On some cable/satellite remote controls, REW and FF

do not punch through to VCR transport control. In-

stead, these keys act as Page Up and Page Down, re-

spectively.



Preparation

After installing the batteries (not included), you can im-

mediately use the remote (with its factory-pro-

grammed settings) to control an RCA TV, VCR, and

DIRECTV system (or SAT/DSS receiver), as well as a

Pioneer DVD player, CD player, and auxiliary device.

To control other brands, you must perform some sim-

ple programming to overwrite the default parameters.

For best results, read and perform all remaining in-

structions. Also, keep these instructions for future ref-

erence.

INSTALLING BATTERIES

Your remote requires four AAA batteries (not supplied)

for power. For the best performance and longest life,

we recommend RadioShack alkaline batteries.

Key DVD AUX CD

GUIDE Setup Menu Guide Guide

MENU DVD Menu Program Program

INFO Display Display Display

CH+ Skip Forward Preset + Preset +

CH– Skip Reverse Preset – Preset –

LAST Return Random Random

TV/VCR TV/DVD Input A/B

REW Rewind Rewind Rewind

PLAY Play Play Play

FF Fast Forward Fast Forward Fast Forward

REC Record Record Record

STOP Stop Stop Stop

PAUSE Pause Pause Pause

8Preparation

Cautions:

• Use only fresh batteries of the required size and

recommended type.

• Do not use rechargeable batteries.

• Do not mix old and new batteries or different

types of batteries (standard or alkaline).

• Always remove old or weak batteries. Batteries

can leak chemicals that can destroy electronic

parts.

Note: Do not press any of the remote control’s keys

while installing batteries.

Follow these steps to install batteries.

1. Press the battery compartment cover’s tab and lift

off the cover.

2. Place the batteries in the compartment as indi-

cated by the polarity symbols (+ and –) marked

inside.

3. Replace the cover.

When batteries become low, the remote control stops

operating to protect stored settings. Replacing the bat-

teries with new ones restores full functionality and

does not require you to reprogram your remote con-

trol.

Warning: Dispose of old batteries promptly and prop-

erly. Do not burn or bury them.

Caution: If you do not plan to use the remote for a

month or longer, remove the batteries. Batteries can

leak chemicals that can destroy electronic parts.

Note: Do not place objects on top of the remote con-

trol after you have installed the batteries. This can de-

press keys for an extended period of time and reduce

the battery life.

Preparation

DEVICE TYPES

You can use the remote control’s device keys to con-

trol the following types of devices:

TV — TV

VCR — VCR or PVR (Personal Video Recorder)

CBL/SAT — Cable converter or SAT/DSS receiver

DVD — DVD or LD Player

AUX — Amplifier, tuner or other audio device

CD – CD Player

SETTING UP YOUR REMOTE

To control devices other than the default brands (for

example, an RCA TV, VCR, and cable converter or

SAT/DSS receiver, a Pioneer DVD player, CD player,

and auxiliary device), perform the following steps. If

you use the default brand devices, skip this section.

1. Refer to “Manufacturers’ Codes” on Page 25 and

write down the code(s) for the brand of each

device you want to program on the supplied label.

Note: Some manufacturers may have several

codes listed. Try each until you find the right one.

If you cannot find the correct code, see “Using

Manual Code Search” on Page 23.

2. Turn on all your home entertainment devices.

3. On the remote control, press the desired device

key (TV, VCR, CBL/SAT, DVD, CD or AUX).

Note: For TV/VCR combinations, press VCR and

use the VCR code listed for your model under

“Television-VCR Combo Codes” on Page 45. If

your TV/VCR combination also lists a TV code,

you must program the TV separately by repeating

Steps 3–5 to add volume control. In Step 3, press

TV, then in step 4 enter the TV code.

10 Preparation

4. Hold down Puntil the remote’s red light blinks

twice, then enter the first 4-digit manufacturer’s

code for the desired device. When the red light

blinks twice, the remote control has accepted the

code.

For example, to set up the remote control of a

Panasonic TV (manufacturer’s code 0051), press

TV, hold down Puntil the red light blinks twice,

then press 0 0 5 1.

Note: If you entered the code incorrectly, the red

light emits one long blink.

5. Point the remote control at the desired device and

press POWER. The device should turn off.

If the remote control does not operate your

device, try the other codes listed in “Manufactur-

ers’ Codes” on Page 25 for your brand of device.

Otherwise, use the search method to find a work-

ing code (see “Using Manual Code Search” on

Page 23).

6. Repeat Steps 2–5 to program other devices.

Note: If the remote control does not operate all

device functions, try using another code in the list

that may be more compatible.

PROGRAMMING FAVORITE

CHANNEL SCAN

Once you have programmed channels into a favorite

channel table, you can scan up to ten favorite chan-

nels for a desired device.

Note: Once you have programmed SCAN/FAV for Fa-

vorite Channel Scan, you cannot use it for Channel

Scan unless you reset it (see “Resetting Scan”).

1. Select TV or CBL/SAT for the favorite channel

scan.

2. Hold down Puntil the red light blinks twice.

3. Press 9 9 6. The red light blinks twice.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Mando a distancia de Radio Shack

Radio Shack

Radio Shack 7-in-One IR Manual de usuario

Radio Shack

Radio Shack Keychain-Remote Control System Manual de usuario

Radio Shack

Radio Shack 63-1166 Manual de usuario

Radio Shack

Radio Shack 15-310 Manual de usuario

Radio Shack

Radio Shack Keychain Manual de usuario

Radio Shack

Radio Shack 15-1931 Manual de usuario

Radio Shack

Radio Shack 15-1990 Manual de usuario

Radio Shack

Radio Shack 15-309 Manual de usuario

Radio Shack

Radio Shack 6-in-1 Remote Control Manual de usuario

Radio Shack

Radio Shack TOUCHSCREEN REMOTE Manual de usuario

Radio Shack

Radio Shack 4 Manual de usuario

Radio Shack

Radio Shack Wireless Security Keychain Remote Manual de usuario

Radio Shack

Radio Shack 15-2146 - Voice Prompt Universal Remote Manual de usuario

Radio Shack

Radio Shack Audio/ Video Remote Control Manual de usuario

Radio Shack

Radio Shack 15-303 Manual de usuario

Radio Shack

Radio Shack Remote Control Manual de usuario

Radio Shack

Radio Shack 15-1915B Manual de usuario

Radio Shack

Radio Shack 7-in-1 Remote Control with Lighted Keypad Manual de usuario

Radio Shack

Radio Shack 15-2147 - Universal Remote Manual de usuario

Radio Shack

Radio Shack 2-in-1 Remote Control Manual de usuario

Radio Shack

Radio Shack Univer 15-2138 Manual de usuario

Radio Shack

Radio Shack 6-IN-ONE TOUCHSCREEN REMOTE Manual de usuario

Radio Shack

Radio Shack 7-in-One Home Theater Manual de usuario

Radio Shack

Radio Shack Kameleon 4-in-1 Manual de usuario

Manuales populares de Mando a distancia de otras marcas

Panasonic

Panasonic EUR7622KB0 Manual de usuario

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación
