Owner’s Manual

Please read before using this equipment.

6-in-One Smart Audio/

Video Remote Control

15-1994.fm Page 1 Tuesday, February 29, 2000 2:04 PM

Need help? Call

1-888-284-8735

INTRODUCTION

Your RadioShack 6-in-One Smart Audio/Video (A/V)

Remote Control is both preprogrammed with the

most commonly used commands and equipped with

“smart technology” that lets you customize your re-

mote to suit your home entertainment needs.

Your 6-in-One can replace up to six infrared remote

controls. Use it to control your TV, VCR, cable con-

verter, satellite receiver, CD or DVD player, tuner,

phonograph, video accessory, digital audio tape,

cassette, or laser disc player from up to about 26 feet

(8 meters) away. It also has these features:

Four Smart Keys — can learn up to 24 features from

your original remotes (one for each key in up to six

device modes), so you can use the 6-in-One to per-

form functions that were not part of its original pro-

gramming.

Lighted Keypad — lets you easily see the remote’s

buttons in a dark room. With this feature on, pressing

any button lights the entire keypad.

Favorite Channel Scan — lets you program your re-

mote to automatically scan through 10 of your favor-

ite channels on a TV, VCR, or cable converter.

Sleep Timer — lets you set a device with or without

a built-in sleep timer to operate for 15-minute inter-

vals (up to 60 minutes), then automatically turn off.

This manual includes a list of many manufacturers’

4-digit codes for your devices. (If your brand is not

listed, see “Searching for a Code” on Page 48.) After

you enter the codes for your original remotes, the 6-

in-One Smart A/V Remote is ready to operate the

original remotes’ most used functions.

Plug ’n Power and RadioShack are registered trademarks

used by Tandy Corporation.

RadioShack.com is a trademark used by Tandy Corporation

15-1994.fm Page 2 Tuesday, February 29, 2000 2:04 PM

Need help? Call

1-888-284-8735

CONTENTS

A Look At Your Remote ............................................... 4

Preparation ................................................................... 6

Installing Batteries ................................................... 6

Device Types ........................................................... 7

Setting Up Your Remote Control ............................. 7

To Operate Your TV/VCR Combination ........... 8

Operation .................................................................... 10

Using the Light ....................................................... 10

Converting Device Keys ........................................ 10

Using Punch-Through ............................................ 11

Turning Punch-Through Off ........................... 11

Using the Smart Keys ............................................ 12

Clearing Smart Keys ..................................... 13

Using Favorite Channel Scan ................................ 14

Clearing Favorite Channel Scan ................... 15

Using the Sleep Function ...................................... 15

Manufacturer Codes .................................................. 17

Amplifiers ............................................................... 17

Cable Converters ................................................... 18

CD Players ............................................................ 21

DVD Players .......................................................... 24

Home Automation .................................................. 25

Laser Disc Players ................................................. 25

Miscellaneous Audio .............................................. 26

Satellite Receivers ................................................. 26

Televisions ............................................................. 27

Tuners/Receivers .................................................. 34

TV/VCR Combinations .......................................... 37

VCRs ..................................................................... 39

Video Accessories ................................................. 46

Troubleshooting ......................................................... 47

Searching for a Code ............................................. 48

Determining the 4-Digit Code ........................ 49

Care and Maintenance ............................................... 50

Specifications ............................................................ 51

15-1994.fm Page 3 Tuesday, February 29, 2000 2:04 PM

Need help? Call

1-888-284-8735

A LOOK AT YOUR REMOTE

Your RadioShack 6-in-One Smart A/V Remote Con-

trol was designed with the functions used most often

to operate your TV, VCR, cable converter, CD or

DVD player, satellite receiver, and audio equipment.

Key Function

PUsed in setting up your devices.

Used to activate light mode.

POWER,

MENU, GUIDE,

SELECT,

MUTE, LAST,

VOL +, VOL–,

DISPLAY, CH

+, CH –, digit

keys, TV/

VIDEO, ENTER

Operate the same as the correspond-

ing keys on your original remote con-

trol.

AUX 1, AUX 2,

VCR, TV, CD,

CBL/SAT

Used when you set up the remote

control to replace your original remote

controls. Also used during normal

operation to let you select the device

you want to control.

All Lights On

(POWER),

PLUG ’N

POWER,

All Off

(MUTE),

Brt

(VOL+),

Dim

(VOL–),

(CH+),

Off

(CH–)

Allows you to control lamps and appli-

ances with your 6-in-One A/V Remote

Control. To get the full benefit from

this feature, you must purchase addi-

tional equipment, available at your

local RadioShack store.

SLEEP Controls the Sleep Timer in TV,

CABLE, SAT, and AUX 1 or AUX 2

modes for devices that have this fea-

ture. If your device does not have a

sleep timer, SLEEP activates the

remote’s built-in sleep timer.

15-1994.fm Page 4 Tuesday, February 29, 2000 2:04 PM

Need help? Call

1-888-284-8735

Notes:

• Whenever you use REC on the remote control,

you must press it twice. This safety feature

helps you avoid accidentally recording over

tapes.

• If you use the 6-in-One to replace extremely

complex remote controls, the 6-in-One might not

be able to duplicate some of the original remote

control’s functions, but you can program one of

the Smart Keys to operate those functions. See

“Using the Smart Keys” on Page 12.

REW, PLAY,

FFWD, REC,

STOP, PAUSE

Control VCR functions and are used

to select options and navigate in your

TV or cable converter.

1s, 2s, 3s, 4s Smart keys used for learning from

your original remote control.

FAV/SCAN Can be programmed to scan through

your 10 favorite channels or left un-

programmed to scan all channels.

PIP, SWAP,

MOVE Picture-in-Picture keys operate the

same as corresponding keys on your

original remote control.

SURR,

CENTER, ,

, and

Control your Surround Sound system

and other similar devices.

Key Function

15-1994.fm Page 5 Tuesday, February 29, 2000 2:04 PM

Need help? Call

1-888-284-8735

PREPARATION

INSTALLING BATTERIES

Your RadioShack 6-in-One Smart A/V Remote Con-

trol requires four AAA batteries (not supplied), avail-

able at your local RadioShack store.

Cautions:

• Use only fresh batteries of the required size and

recommended type.

• Do not mix old and new batteries, different types

of batteries (standard, alkaline, or recharge-

able), or rechargeable batteries of different

capacities.

1. Press the battery compartment cover’s tab and

lift off the cover.

2. Place the batteries in the compartment as indi-

cated by the polarity symbols (+ and –) marked

inside.

3. Replace the cover.

If you installed the batteries correctly and the red in-

dicator does not light when you press POWER, re-

place the batteries.

Note: You do not need to reprogram your remote

control after removing the batteries, because no

stored information is lost during battery replacement.

Cautions:

• Dispose of old batteries promptly and properly.

Do not burn or bury them.

• Always remove old or weak batteries. Batteries

can leak chemicals that can destroy electronic

parts.

15-1994.fm Page 6 Tuesday, February 29, 2000 2:04 PM

Need help? Call

1-888-284-8735

DEVICE TYPES

You can use the remote control's device keys to con-

trol these types of devices:

•TV — TVs

•VCR — VCRs and TV/VCR combinations, digital

video disc players, laser disc players, cassette

decks, digital audio tape players

•CBL/SAT — cable converters, satellite systems,

video accessories

•CD — CD players

•AUX 1 or AUX 2 — miscellaneous audio devices

(such as graphic equalizers and digital audio

service terminals)

•PLUG ’N POWER — home automation

Note: To enjoy the full benefit of the Plug ’n Power

feature, you must purchase additional equipment,

available at your local RadioShack store.

SETTING UP YOUR REMOTE

CONTROL

1. Refer to “Manufacturer Codes” on Page 17 and

write down the codes for your devices on the 6-

in-One’s label.

Note: Some manufacturers have several codes

listed. Try each until you find the right one. See

“Searching for a Code” on Page 48 if you cannot

find the correct code.

2. Turn on your TV.

3. Press the device key for the type of remote you

are replacing (TV, VCR, CBL/SAT, CD, AUX 1 or

15-1994.fm Page 7 Tuesday, February 29, 2000 2:04 PM

Need help? Call

1-888-284-8735

AUX 2, or PLUG ’N POWER), then hold down P

until the red light blinks twice.

4. Enter the 4-digit code.

For example, to replace a Panasonic TV’s

remote control (set-up code 0051), press TV,

hold down Puntil the red light blinks twice, then

enter 0 0 5 1.

When the red light blinks twice, the remote con-

trol has accepted the code.

Note: If you enter an invalid code, the red light

makes one long blink.

5. Point the 6-in-One at your device and press

POWER. Your TV should turn off.

If the remote does not operate your device, try the

other codes you wrote down in Step 1.

To Operate Your TV/VCR Combination

1. Refer to “TV/VCR Combinations” on Page 37

and write down the codes for your TV/VCR com-

bination on the supplied label.

Notes:

• Some manufacturers have several codes

listed. Try each until you find the right one.

See “Searching for a Code” on Page 48 if you

cannot find the correct code.

• Some TV/VCR combinations require a sec-

ond code to control volume. If you cannot

control volume, use one of the codes listed

for your brand in “TV/VCR Combinations.”

2. Turn on your TV/VCR combination and insert a

tape.

15-1994.fm Page 8 Tuesday, February 29, 2000 2:04 PM

Need help? Call

1-888-284-8735

3. Press VCR then hold down Puntil the red light

blinks twice.

4. Enter the 4-digit code.

For example, to replace a Panasonic TV/VCR

combination’s remote control (set-up code

1162), press VCR, hold down Puntil the red light

blinks twice, then press 1 1 6 2.

When the red light blinks twice, the remote con-

trol has accepted the code.

Note: If the code you entered is invalid, the red

light makes one long blink.

5. Point the 6-in-One at your TV/VCR combination

and press POWER or PLAY. Your TV/VCR com-

bination should turn off or start to play.

If the remote does not operate your TV/VCR combi-

nation, try the other codes you wrote down in Step 1.

Note: Some TV/VCR combinations require a second

code to control volume. If you cannot control the vol-

ume, use the TV code listed in “TV/VCR Combina-

tions” on Page 37.

15-1994.fm Page 9 Tuesday, February 29, 2000 2:04 PM

Need help? Call

1-888-284-8735

OPERATION

1. Press the device key for the device you want to

control.

2. Point the remote control toward the device you

want to control, then press the desired com-

mand keys.

3. Repeat Steps 1 and 2 for all other devices you

want to operate.

Note: The command keys on the remote con-

trol work the same as the keys on the original

remote control; however, the labeling might dif-

fer slightly.

4. To turn off the last device you selected, press

POWER. To turn off other devices, press the

device key for the device you want to turn off,

then press POWER.

USING THE LIGHT

The backlight lets you see the keys on your 6-in-One

in the dark. Press to turn on the light. The keypad

lights for about 5 seconds. Then, every time you

press a key, the 6-in-One lights up and stays lit for

about 5 seconds. To turn off the light, press

again.

CONVERTING DEVICE KEYS

You can use your 6-in-One Remote to operate a sec-

ond TV or VCR (or other components) for a total of

up to six devices. To do this, you must first convert

an unused device key (AUX1, AUX2, VCR, TV, CD,

CBL/SAT) to operate each additional device. For ex-

ample, to convert AUX1 to operate a second TV:

1. Hold down Puntil the red light blinks twice.

15-1994.fm Page 10 Tuesday, February 29, 2000 2:04 PM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Mando a distancia de Radio Shack

Radio Shack

Radio Shack 15-1990 Manual de usuario

Radio Shack

Radio Shack Kameleon Manual de usuario

Radio Shack

Radio Shack Wireless Security Keychain Remote Manual de usuario

Radio Shack

Radio Shack Kameleon Manual de usuario

Radio Shack

Radio Shack 7-in-1 Remote Control with Lighted Keypad Manual de usuario

Radio Shack

Radio Shack 15-1995 Manual de usuario

Radio Shack

Radio Shack 15-2147 - Universal Remote Manual de usuario

Radio Shack

Radio Shack TOUCHSCREEN REMOTE Manual de usuario

Radio Shack

Radio Shack 4 Manual de usuario

Radio Shack

Radio Shack 15-310 Manual de usuario

Radio Shack

Radio Shack 7-in-One Home Theater Manual de usuario

Radio Shack

Radio Shack 15-2146 - Voice Prompt Universal Remote Manual de usuario

Radio Shack

Radio Shack Keychain Manual de usuario

Radio Shack

Radio Shack 15-1925 Manual de usuario

Radio Shack

Radio Shack 150-2114 Manual de usuario

Radio Shack

Radio Shack Kameleon 4-in-1 Manual de usuario

Radio Shack

Radio Shack 2-in-1 Remote Control Manual de usuario

Radio Shack

Radio Shack Keychain-Remote Control System Manual de usuario

Radio Shack

Radio Shack Light and Learn Remote Manual de usuario

Radio Shack

Radio Shack 15-303 Manual de usuario

Radio Shack

Radio Shack 15-309 Manual de usuario

Radio Shack

Radio Shack Univer 15-2138 Manual de usuario

Radio Shack

Radio Shack 8-IN-ONE REMOTE Manual de usuario

Radio Shack

Radio Shack 63-1166 Manual de usuario

Manuales populares de Mando a distancia de otras marcas

Panasonic

Panasonic EUR7622KB0 Manual de usuario

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación
