Quick Start Guide

[]

FIBRE CHANNEL SWITCH INSTALLATION P

QUICK START GUIDE

SANbox®5202

for Windows®Operating Systems

Quick Start Guide

Installation Instructions

Congratulations on your purchase of the SANbox® 5202 Fibre Channel switch. This Quick Start

Guide describes the simple steps to install and activate your new switch using a Windows®

workstation.

NOTE: Do not connect and apply power to the switch until instructed in Step 5.

For advanced options and instructions (including Solaris®, Linux®, and Mac OS X® installations),

refer to the SANbox 5200 Series Fibre Channel Switch Installation Guide on the CD provided with

the switch.

Step 1. Verify the Package Contents

The SANbox 5202 Fibre Channel Switch is shipped with the following items:

1 SANbox 5202 Fibre Channel Switch

2 AC Power cords

4 Rubber feet

1CD

NOTE: Small Form-factor Pluggable (SFP) transceivers, XPAK switch stacking cables, and the

rail kit, if you ordered them, are packaged separately. XPAK switch stacking cables connect

SANbox 5202 switches together through the 10-Gbps ports. The switch must have a 20-port

license to enable the 10-Gbps ports.

Step 2. Mount the Switch

You can mount the SANbox 5202 switch on a flat surface or in a rack.

❑For a surface mount, attach the rubber feet to the locations on the bottom of the switch.

❑For a rack mount, install the SANbox 5202 rail kit in a standard 19" rack as described in the

SANbox 3000/5000 Fibre Channel Switch Rack Mounting Guide that is packaged with the

rail kit.

Step 3. Stack Switches

If your switch is licensed for 20 ports, you can connect up to four switches together through the

10-Gbps ports using XPAK switch stacking cables. Stacking provides performance and fail-over

while preserving ports for devices.

• For a 2-switch stack, use two 3-inch cables.

• For a 3-switch stack, use two 3-inch cables and one 9-inch cable.

• For a 4-switch stack, use three 3-inch cables and three 9-inch cables.

❑Remove the 10-Gbps port covers according to the instructions provided with the cables.

Connect 2, 3, or 4 switches into 2-, 3- or 4-switch stacks.

Step 4. Install SFPs

An SFP transceiver is required for each switch port that will be connected to a device, device loop,

or another switch.

Recommended SFPs: Finisar® FTRJ-8519-P1BNL, JDS Uniphase® JSP-21S0AA1,

Picolight® PL-XPL-VC-S23-11.

❑If SFP transceivers were included in your shipment, install them now. To install an SFP

transceiver, insert the transceiver into the switch port and gently press until it snaps in

place. The transceiver will fit only one way. If the transceiver does not install under gentle

pressure, flip it over and try again.

LAL AL AL ALA

LALALA LALA

LA LA

0123456 7 8 9 10 11 13 14 15

LAL AL AL ALA

LALALA LALA

LA LA

0123456 7 8 9 10 11 13 14 15

LAL AL AL ALA

LALALA LALA

LA LA

0123456 7 8 9 10 11 13 14 15

LAL AL AL ALA

LALALA LALA

LA LA

0123456 7 8 9 10 11 13 14 15

LAL AL AL ALALALALALALALA

LALALA

0123456 7 8 9 10 11 13 14 15

LAL AL AL ALA

LALALA LALA

LA LA

0123456 7 8 9 10 11 13 14 15

LAL AL AL ALA

LALALA LALA

LA LA

0123456 7 8 9 10 11 13 14 15

LAL AL AL ALA

LALALA LALA

LA LA

0123456 7 8 9 10 11 13 14 15

LAL AL AL ALA

LALALA LALA

LA LA

0123456 7 8 9 10 11 13 14 15

2-Switch Stack 3-Switch Stack

4-Switch Stack

Step 5. Apply Power to the Switch

❑Attach the AC power cords to the switch

and wall outlet or power strip. Verify that

the Input Power LED is illuminated.

❑The switch runs its self tests and begins

normal operation – this may take a few

minutes. Verify that the Heartbeat LED is

blinking (once per second) and the

System Fault LED is NOT illuminated.

Step 6. Verify Workstation Requirements

❑Verify that your workstation can support the SANsurfer Switch Manager™ application with

the following minimum requirements:

• Windows XP/2000/2003

• 256 MB memory

• 150 MB disk space

• 500 MHz processor

• Video card with 256 colors

• CD ROM drive, RJ-45 Ethernet port

• Internet Browser: Microsoft® Internet Explorer®, Netscape Navigator®, or Mozilla™

Step 7. Install the SANsurfer Switch Manager Application

The SANsurfer Switch Manager application includes the Configuration Wizard. This wizard

auto-detects and configures the switch based on selected options and recommended settings. To

install the SANsurfer Switch Manager application on a Windows workstation/server, perform the

following steps:

❑Insert the supplied CD into the CD ROM drive of the Windows workstation/server.

❑In the upper left corner of the product introduction screen, click Management Software.

❑Locate your platform in the table and click Install.

❑If the product introduction screen does not open, open the CD with Windows Explorer and

run the installation program with the following path:

data\files\Management_Software\Windows\Windows_5.00.xx.xx.exe

INPUT

POWER LED

HEARTBEAT

LED

SYSTEM

FAULT LED

ration. All other trademarks are the property of their respective companies. Information supplied by QLogic is believed to be accurate and

reliable. QLogic Corporation assumes no responsibility for any errors in this brochure. QLogic Corporation reserves the right, without notice,

to make changes in product design or specifications.

Step 8. Obtain Network Configuration

❑Obtain the IP address and subnet mask from your network administrator.

Step 9. Run the Configuration Wizard

❑Double-click the SANsurfer Switch Manager shortcut, or select SANsurfer Switch Manager

from Start menu, depending on how you installed SANsurfer Switch Manager.

❑Connect the switch and the workstation using an Ethernet crossover cable, switch, or hub.

❑The Configuration Wizard tool will auto-detect and configure the switch based on selected

options and recommended settings. Follow the instructions to set network parameters and

the password.

NOTE: If you are using an Ethernet switch and the auto-connect process fails due to a time out,

try a direct connection from your workstation to the switch using an Ethernet cross-over cable.

Step 10.Connect Devices and Switches

❑Connect fibre optic cables between the installed SFP transceivers and their corresponding

devices. Each port auto-negotiates the proper port type with the connected device or switch.

Congratulations!

You have successfully installed your QLogic SANbox 5202

Switch!

For technical support, visit our web site at support.qlogic.com, email us at support@qlogic.com,

or call us at 952-932-4040. For more detailed installation instructions, see the SANbox 5200 Series

Fibre Channel Switch Installation Guide, located on the product CD or on the QLogic web site.

QLogic Corporation 26650 Aliso Viejo Parkway Aliso Viejo, CA 92656

949.389.6000 www.qlogic.com

50347-01 B

*50347-01B*
