Pyle PLCM3550WIR Manual de usuario
PLCM3550WIR
POWER
V1 / V2
MENU
R
PLCM3550WIR
DC
Came ra Inpu t
Wirel ess Video Tra nsmit ter
R
Backup Camera & Rearview Monitor Parking Assist System
the license plate). The receiver is built in the display monitor. This receives the signal from the camera connected to the
transmitter.
a. Stick the monitor to window shield using the suction cup.
b. Use the cigarette plug to get power.
PLCM3550WIR
DC
Cam era Inp ut
Wirele ss Vi deo Transm itt er
R
Cigarette plug
DC
Taillight
DC
+12v
-12v
Camera
Video Transmitter
Monitor
POWER
V1 / V2
MENU
R
PLCM3550W IR
1, Long press for power ON/OFF; Short press for Video1/Video2 switch.
2, Positive Adjustment
3, Menu
4, Negative Adjustment
POW ER
V1 / V2
MEN U
R
PLC M355 0WI R
5, DC power input
6, Optional AV input
Discover other cameras & driver safety on our website.
