Pyle PLCMDVR 8 Manual de usuario

USER MANUAL

PLCMDVR 8

Backup Camera Parking Assist System

Dual Cameras and Monitor with Image & Video Recording

A B C D E F

HHH

1. Turn on DVR

Start car engine to tun on DVR power

2. Turn oﬀ DVR

Shut oﬀ car engine to turn oﬀ DVR power.

Note: Short prsee buon, DVR will turn to sleep mode only.

Main Menu

OSD

As above picture showed, green color icon is the icon selected.

Buons

UP: Cursor le

DN: Cursor right

OK: Enter/execute the menu selected

MENU: No funcon.

DVR Power ON/OFF

Driving record funcon

Driving record image SOS image

: Short press“ ” to enter sleep mode.

2. Funcon descripon

Stop recording: When there is no SD card or SD card does not insert correctly, it will stop

recording.

Normal recording: In loop mode, whenever the recording me reaches user-set loop recording

me, a new ﬁle will be saved. When SD card capacity is full, current recorded normal video ﬁle

will cover the ﬁrst saved one.

SOS recording: Once G-sensor detected value exceeds a given threshold value, it will turn to

SOS recording and current video will be saved as SOS ﬁle. In loop recording, SOS ﬁle is saved as

three video ﬁles(previous video, current video and next video when entering SOS state), which

will not be overwrien. When SOS recording ﬁnished, it will return to normal recording.

Auto power oﬀ aer car stopped: When the car is stopping and DVR under normal recording

mode, G-sensor will detect and if G-sensor detected value not exceed threshold value(This

value is not same as event trigger value and cannot be set by user) within 5 minutes, the unit

will power oﬀ automacally.

Sound recording on

Sound recording oﬀ

System beep on

System beep oﬀ

1. Icons

3. Buons

: Short press “ ” to enter sleep mode.

OK: Enter/Exit SOS recording

MENU: Exit recording and back to main menu

Motion detection image

Moon Detecon

Open motion detection function when car is stopping. When recording image changes,

it will turn to normal recording; when image is static again, it will continue recording and

be back to motion detection state once it reaches motion detection recording time in

setting menu.

1. Icons

10S means when recording image changes and stac again, it will connue recording

10seconds and then stop.

2. Buon Funcon

: Short press“ ” to enter sleep mode.

UP: No funcon

DN: No funcon

OK: No funcon

MENU: Exit recording and back to main menu

Camera image

14MP 12MP (4000 x 3000)

8MP (3264 x 2448) 5MP (2560 x 1920)

3MP (2048 x 1536) 2MP (1920 x 1080)

1.2MP (1280 x 960) VGA (640 x 480)

Cemara Funcon

Buon funcon

UP: Zoom in

DN: Zoom out

OK: Shoot a photo and save a picture of JPG format to SD card.

M: Exit picture size seng interface or camera funcon.

: Short press“ ” to enter sleep mode.

File Browser

1 .The number shows the quanty of documents contained in the four project folders 'REC

Files', 'SOS Files', 'MD' and 'Photos Files'.

2 .Shows memory usage of current SD card.

In this mode you can shoot photos of the following sizes:

1. Delete ﬁles

Select the ﬁles that you want to delete, long press 'UP' buon, then click 'OK', the ﬁles selected

in project folder will be deleted.

Note: The deleted ﬁles in the four folders can not be recovered.

2. Buon funcon

UP(Short press): Cursor le

UP(Long press): Delete ﬁle message.

DN: Cursor right

OK: Enter the project folder selected

MENU: Exit File Browser and back to main menu.

: Short press“ ” to enter sleep mode.

REC Files

Image File Playback

Select the image ﬁle that you want to replay, then click 'OK'.

When the selected ﬁle play completes, it will connue to play subsequent ﬁles.

Delete Image Files

Buons

UP: Select previous ﬁle

DN: Select next ﬁle

OK: Pause/Resume play

MENU: Exit play

SOS Files

The operaon and buon funcon is same as 'REC Files'.

Moon Detecon

The operaon and buon funcon is same as 'REC Files'

Select the image ﬁles that you want to delete, long press 'UP' buon, then click 'OK', the image

ﬁles selected will be deleted.

Note: Deleted image ﬁles can not be recovered.

: Short press“ ” to enter sleep mode.

Photos Files

1. Delete photos

Select the photo ﬁle that you want to delete, long press 'UP' buon, then click 'OK', the ﬁle

selected will be deleted.

Note: Deleted ﬁles can not be recovered.

2. Buon funcon

UP(Short press): Select the previous ﬁle

UP(Long press): Delete ﬁle message.

DN: Select next ﬁle

OK: Open selected ﬁle.

MENU: Exit and return to previous menu.

: Short press“ ” to enter sleep mode.

Recording Mode

1. Video Quality

1296SHD: 2304x1296；

1080FHD: 1920x1080；

720HD: 1280x720；

2. Buon funcon

: Short press to enter sleep mode.

UP: Select previous item

DN: Select next item

OK: Enter seng or conﬁrm the change of sengs.

MENU: Exit or discard the change of seng.

Note: If no special instrucons, the buon funcon operaon for all sengs are same as above.

Sengs

Photo Size

Photo size can be set as 14MP, 12MP, 8MP, 5MP, 3MP, 2MP, 1.2MP, VGA

Loop Recording

Loop recording me can be set to 1 minute/ 2 minutes/ 3 minutes for each ﬁle. Default seng is 1

minute.

ON: Record video with sound(default seng)

OFF: Record video without sound.

Sound Record

Set MD sensivity as HIGH/MIDDLE/LOW.

Oﬀ/High/Medium/Low sensivity for diﬀerent environment. Default seng is MIDDLE

MD Sensivity

G-Sensor

ON: Turn on buon sound.

OFF: Turn oﬀ buon sound.

Buon Sound

Volume seng on Mute or 5%~100%.

Volume Seng

Backlight Time

ON: Turn on backlight all the me(Default seng).

30s: Turn oﬀ backlight aer no operaon for 30s.

1 min: Turn oﬀ backlight aer no operaon for 1 minute.

5 min: Turn oﬀ backlight aer no operaon for 5 minutes

Light Frequency

50Hz: Remove light frequency interference of 50Hz

60Hz: Remove light frequency interference of 60Hz

Note: This funcon is to remove the interference of indoor ﬂuorescent light 50Hz or 60Hz to

system CMOS image.
