Prorack K571 Guía de instalación

FittingKit

K571

Fitting Instruction for Accessory

x 4

x 1

x 2

x 4

Revision No:

1.0

FittingKit

K571

MAX kg

W/P

WHD

W/P

WHD

BMW

1 Series E82, 2dr Coupe 07-+

FittingKit

K571

First Time Installation

Remove parts from packaging and check

contents. Contact your Prorack dealer if parts

are missing or damaged.

These instructions show type A crossbar

fitted. They also apply to type B, C and D.

This kit fits type A, B, C and D.

Use keys to remove covers.

FittingKit

K571

Use hex screwdriver to reverse adjusting

screw 10 turns.

Press adjusting screw and pull crossbar legs

out. Refer to the crossbar instructions for

crossbar adjustment.

Ensure each end of the crossbar is adjusted

equally.

Attaches to factory-fitted mounting points

Please check the rear of this manual for

information relating specifically to your

vehicle.

Adjust crossbar in or out to suit vehicle.

Refer to the crossbar instructions for

crossbar adjustment.

FittingKit

K571

Tighten adjusting screw to 5 Nm.

Remove clamp block by pressing backwards.

Select plastic internal block (from fitting kit)

and insert into foot.

Repeat for all legs.

FittingKit

K571

Fitment

Open or remove fixed-point covers.

Select grubscrews and screw into the

vehicle's fixed points.

Do not over tighten.

Repeat for all four positions.

Refer to the underside of the pad for the part

number.

FittingKit

K571

It is important to put the pads in the correct

position on the vehicle.

Letters refer to the pad part numbers and

position.

Pad Part Number:

A = 11-04-233

B = 11-04-234

Ensure the fixed-point covers sit vertically in

the recess in the pads.

Place crossbars on pads ensuring the pads

fit into the holes underneath the foot and the

grubscrew pass through the hole in the foot.

Repeat for all four positions.

Tighten adjusting screw to 5 Nm.

FittingKit

K571

Tighten the red plastic knob. The side with

the nut showing should be facing up.

Ensure the red plastic knob is in the position

shown when fully tightened.

Repeat for all legs.

Check crossbar is securely attached to the

vehicle.

Use keys to fit and lock covers

FittingKit

K571

CAUTION:

Recheck all fasteners immediately after a load is

applied to the crossbars.

Regularly check screws are tight.

FittingKit

K571

Maintenance

Clean the car roof and surfaces of the

product that will be in contact with the car

roof.

Follow the fitting instructions for fitting the

product to your vehicle. Make sure all steps

are carried out in order.

Set crossbars a minimum distance of 700mm

apart where no other distance is specified in

the fitting instructions. This is especially

important when carrying long loads.

Check unit is securely attached whenever

you refit it to the vehicle. If the unit feels

loose, refer to the fitting instructions and

readjust.

Some sunroofs and radio antennae cannot

be used when the product is fitted.

Do not modify this product.

Refer to the maximum permitted load

capacity specified in the fitting instructions.

Do not exceed the vehicle manufacturers

roof load rating if it is lower than the

maximum load capacity specified in the fitting

instructions.

Loads should not overhang the sides of the

product and be evenly distributed with the

lowest possible centre of gravity.

Long loads should be secured with non-

elastic straps to the front and rear of the

vehicle.

Objects with pointed ends (skis) should be

carried with the pointed ends to the rear of

the vehicle.

Remove all loose or removable objects from

the load prior to loading.

Make sure all loads are securely fastened

with non-elastic straps. Check regularly

during longer journeys.
