Prorack K421 Manual de usuario

Page 1 of 4

K421 ASSEMBLY AND FITTING

INSTRUCTIONS

Kit Contains

1 x Instructions

4 x Feet Assemblies

4 x Coach Bolts

4 x M6 x 12 mm Capscrews

8 x M5 x 12 mm Capscrews

Remo e parts from box & check

Contact your Prorack dealer if any parts are missing or damaged

Items you will require that are not included:

1 x Tape measure

1 x Step Ladder for higher ehicles

Important Note:

Whispbar Through Bar pictured in these instructions, also applicable for Whispbar Flush Bar

Whispbar Through Bar pictured in these instructions, also applicable for Whispbar Flush Bar Whispbar Through Bar pictured in these instructions, also applicable for Whispbar Flush Bar

Whispbar Through Bar pictured in these instructions, also applicable for Whispbar Flush Bar

When Fitted and loaded

correctly

7575

kgkg

Maximum

Whispbar

Load

ating

1. Fitting Feet Assemb ies to Legs

•

emove crossbar and this kit parts from the

packaging.

•Follow step 1-3 of crossbar assembly instructions.

•emove clamp block by pressing it backwards.

•emove both pins from each leg.

(use

spanner/screwdriver located inside one of the left

hand covers to assist)

Press Here Remo e both pins

1.1

1.2

4 x Clamps + Bumpon Tape

4 x Red Plastic Knobs

K421 ASSEMBLY AND FITTING INSTRUCTIONS

Page 2 of 4

1.6

•

epeat 1.1-1.3 for all four legs

•Store these parts in a safe place. They

are not required for this fitting kit.

•

While holding crossbar, detach foot from leg.

Detach

Parts remo ed from

each leg

•Turn the crossbar upside down and use

the M6 x 12 mm capscrews to secure the

feet assembly using the Hex Screwdriver

supplied with the crossbar.

•epeat on all for legs

•Select four feet assemblies and match

the left and right assemblies to the left

and right roof rack legs.

•Use the M5 x 12 mm self tapping screws

to secure feet assemblies to leg.

1.5

1.4

1.3

K421 ASSEMBLY AND FITTING INSTRUCTIONS

Page 3 of 4

•

Slide clamp through opening in the leg

(see step 2.1).

•Ensure that the two pins of the clamp

engage correctly with the holes in the roof

rail.

•Thread the coach bolt through the clamp

and the leg.

•Tighten the red plastic knob. Do Not Over

Do Not Over Do Not Over

Do Not Over

Tighten

TightenTighten

Tighten.

•Ensure the red plastic knob is in the position

above and refit covers.

•epeat for all four legs.

2.2

2.3

2.1

•

Locate two holes at each position along the roof

rail.

•

Place crossbars approximately above these

holes on roof rails.

2.4

Pins engaged

correctly

Opening for

clamp

2. Positioning Crossbars on Roof Rai

K421 ASSEMBLY AND FITTING INSTRUCTIONS

Page 4 of 4

Warning Notes:

•Use these instruction in conjunction with crossbar instructions

WARNING: Check the Tightness of Screws Regu ar y

•

Check crossbars feel tight.

2.5

•Completed roof rack.

2.6
