USER MANUAL

REV.01-09/22 English version

EclSoft LinearIP

IP65, 250W Tunable White and colourful linear

LED soft light with pixels and lighting effects

Thank you for choosing PROLIGHTS

Please note that every PROLIGHTS product has been designed in Italy to meet quality and performance requirements

for professionals and designed and manufactured for the use and application as shown in this document.

Any other use, if not expressly indicated, could compromise the good condition/operation of the product and/or be

a source of danger.

This product is meant for professional use. Therefore, commercial use of this equipment is subject to the respectively

applicable national accident prevention rules and regulations.

Features, specications and appearance are subject to change without notice. Music & Lights S.r.l. and all afliated

companies disclaim liability for any injury, damage, direct or indirect loss, consequential or economic loss or any other

loss occasioned by the use of, inability to use or reliance on the information contained in this document.

Product user manual can be downloaded from the website www.prolights.it , or can be inquired to the ofcial

PROLIGHTS distributors of your territory (https://www.prolights.it/sales_network.html).

Scanning the below QR Code, you will access the download area of the product page, where you can nd a broad

set of always updated technical documentation: specications, user manual, technical drawings, photometrics,

personalities, xture rmware updates.

The PROLIGHTS Logo, PROLIGHTS names and all other trademark in this document pertaining to PROLIGHTS services

or PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its afliates, and subsidiaries.

04026 - Minturno (LT) ITALY.

Visit the download area

of the product page

PROLIGHTS - EclSoft LinearIP 01

INDEX

SAFETY INFORMATION 02

1 - PACKAGING 05

PACKAGE CONTENT..................................................................................................... 05

OPTIONAL ACCESSORIES............................................................................................. 05

2 - TECHNICAL DRAWING 05

3 - INSTALLATION 06

MOUNTING.................................................................................................................... 06

4 - CONNECTION TO THE MAINS SUPPLY 08

5 - START UP 08

CONNECT AND DISCONNECT POWER FROM THE PRODUCT.................................. 08

6 - PRODUCT OVERVIEW 09

7 - DMX CONNECTION 10

CONNECTION OF THE CONTROL SIGNAL: DMX LINE .............................................. 10

INSTRUCTIONS FOR A RELIABLE DMX CONNECTION ............................................... 10

CONNECTION DAISY CHAIN........................................................................................ 10

CONNECTION OF THE DMX LINE................................................................................ 10

CONSTRUCTION OF THE DMX TERMINATION ........................................................... 11

DMX ADDRESSING ........................................................................................................ 11

ETHERNET CONNECTION ............................................................................................ 11

ETHERNET OPERATION ................................................................................................ 11

ETHERNET TO DMX OPERATIONS ............................................................................... 12

OPERATION AS A WIRELESS TRANSMITTER................................................................ 12

IN TO WDMX ................................................................................................................. 12

OPERATION AS A WIRELESS RECEIVER........................................................................ 13

WDMX TO DMX (RX)...................................................................................................... 13

8 - CONTROL PANEL 14

DISPLAY AND BUTTONS LAYOUT................................................................................. 14

9 - MENU STRUCTURE 15

10 - SHORTCUT 20

11 - RDM FUNCTIONS 21

12 - DMX CHARTS 25

13 - ACCESSORIES INSTALLATION 78

CENTER MOUNT BRACKET (CODE ESLIPBRK - OPTIONAL) ....................................... 78

BALL HEAD JOINT (CODE EPTWCBHEAD - OPTIONAL) ............................................. 79

FOOT PLATE (CODE ESLIPFY - OPTIONAL).................................................................. 80

FRONT INTENSIFIED/ HIGH / MEDIUM / LOW DIFFUSION (CODE ESLIPFILTERINT /

HD / MD / LD - OPTIONAL) ........................................................................................... 81

EGG CRATE (CODE ESLIPEC60 - OPTIONAL).............................................................. 82

14 - TEST OF IP65 RATING 83

15 - MAINTENANCE 84

MAINTENANCE AND CLEANING THE PRODUCT........................................................ 84

VISUAL CHECK OF PRODUCT HOUSING ..................................................................... 84

TROUBLESHOOTING..................................................................................................... 85

PROLIGHTS - EclSoft LinearIP02

SAFETY INFORMATION

WARNING!

• Please read carefully the instruction reported in this section before installing, powering,

operating or servicing the product and observe the indications also for its future handling.

This unit is not for household and residential use, only professional applications.

Connection to mains supply

• The Connection to the mains supply must be carried out by a qualied electrical

installer.

• Use only AC supplies 100-240V 50-60 Hz, the xture must be electrically connected

to ground (earth).

• Select the cable cross section in according with the maximum current draw of the

product and the possible number of products connected at the same power line.

• The AC mains power distribution circuit must be equipped with magnetic+residual

current circuit breaker protection.

• Do not connect it to a dimmer system; doing so may damage the product.

Protection and Warning against electrical shock

• Do not remove any cover from the product, always disconnect the product from AC

power before servicing.

• Ensure that the xture is electrically connected to ground (earth). And use only a

source of AC power that complies with local building and electrical codes and has

both overload and ground-fault (earth-fault) protection.

• Before using the xture, check that all power distribution equipment and cables are

in perfect condition and rated for the current requirements of all connected devices.

• Isolate the xture from power immediately if the power plug or any seal, cover, cable, or

other components are damaged, defective, deformed or showing signs of overheating.

• Do not reapply power until repairs have been completed.

• Refer any service operation not described in this manual to PROLIGHTS Service team

or an authorized PROLIGHTS service center.

Installation

• Make sure that all visible parts of the product are in good visible condition before its

use or installation.

• Make sure the point of anchorage is stable before positioning the projector.

• When suspending the xture above ground level, secure it against failure of primary

attachments by attaching a safety cable that is approved as a safety attachment for

the weight of the xture to the attachment point on the main frame of the product. ln

case the safety cable, enter in action, it needs to be replaced with a new one.

• Install the product only in well ventilated places.

• For non temporary installations, ensure that the xture is securely fastened to a load-

bearing surface with suitable corrosionresistant hardware.

• For a temporary installation with clamps, ensure that the quarter-turn fastener and/or

screws are turned fully, and secured with a suitable safety cable.

0.5 m Minimum distance of illuminated objects

• The projector needs to be positioned so that the objects hit by the beam of light are

at least 0,5 meters (1,64 ft) from the lens of the projector.

T 45°C

Max operating ambient temperature (Ta)

• Do not operate the xture if the ambient temperature (Ta) exceeds 45 °C (113 °F).

PROLIGHTS - EclSoft LinearIP 03

-20°

aMinimum operating ambient temperature (Ta)

• Do not operate the xture if the ambient temperature (Ta) is below -20 °C (-4 °F).

Protection from burns and re

• The exterior of the xture becomes hot during use. Avoid contact by persons and

materials.

• Ensure that there is free and unobstructed airow around the xture.

• Keep ammable materials well away from the xture.

• Do not expose the front glass to sunlight or any other strong light source from any an-

gle. Lenses can focus the sun’s rays inside the xture, creating a potential re hazard.

• Do not attempt to bypass thermostatic switches or fuses.

IP65

Outdoor (temporary) use

• This product is rated with an IP (Ingress protection) for temporary outdoor use when

used and serviced according to the instruction contained in this document.

• Never use the xture in places subject to vibrations or bumps.

• Make certain that no inammable liquids, water or metal objects enter the xture.

• Excessive dust, smoke uid, and particle build up degrades performance, causes

overheating and will damage the xture.

• Damages caused by inadequate cleaning or maintenance are not covered by the

product warranty.

70°

Temperature of the external surface

• The surface of the xture can reach up to 70 °C (158 °F) during operation. Avoid

contact with people and materials.

Maintenance

• Warning! Disconnect the xture from AC mains power and allow to cool for at least

10 minutes before handling.

• Only technicians who are authorized by PROLIGHTS or Authorised service partners

are permitted to open the xture.

• Users may carry out external cleaning, following the warnings and instructions pro-

vided, but any service operation not described in this manual must be referred to a

qualied service technician.

• Important! Excessive dust, smoke uid, and particle build up degrades performance,

causes overheating and will damage the xture. Damages caused by inadequate

cleaning or maintenance is not covered by the product warranty.

Photobiological safety

• This device emits potentially dangerous optical radiation and is identied in the cat-

egory of Risk Group 1 according to EN 62471.

Do not stare at the operating light source

• Do not look directly at the LED source during operation. It can be harmful to the eyes

and skin.

• During Installation, operation and maintenance, be prepared for the xture to light

and move suddenly when connected to power.

Disposal

• This product is supplied in compliance with European Directive 2012/19/EU – Waste

Electrical and Electronic Equipment. (WEEE). To preserve the environment please

dispose/ recycle this product at the end of its life according to the local regulation.

PROLIGHTS - EclSoft LinearIP04

The products to which this manual refers comply with:

• 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD);

• 2014/30/EU - Electromagnetic Compatibility (EMC);

• 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS);

• 2014/53/EU - Radio Equipment Directive (RED).

The products to which this manual refers comply with:

• UL 1573 + CSA C22.2 No. 166 - Stage and Studio Luminaires and Connector Strips.

• UL 1012 + CSA C22.2 No. 107.1 - Standard for power units other than class 2.

FCC Compliance:

• This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may

cause undesired operation.

Other approvals

• The product meets the safety requirements of the certification procedures of the

market in which it is placed and sold.

PROLIGHTS - EclSoft LinearIP 05

1 - PACKAGING

PACKAGE CONTENT

• 1x ECLSOFTLINEARIP.

• 1x 1,5 meters power cable (BARE END - SEETRONIC IP65 power connector).

• User Manual.

• 2x OS27: quick-Lock omega bracket, M10 hole.

• 1x ESLIPFILTERMD: front medium diffusion lter for ECLSOFTLINEARIP.

OPTIONAL ACCESSORIES

• FCLECLSOFTLIP: ight case for 5 pcs of ECLSOFTLINEARIP.

• ESLIPEC60: egg crate for ECLSOFTLINEARIP.

• ESLIPFILTERINT: front intensied diffusion lter for ECLSOFTLINEARIP.

• ESLIPFILTERHD: front high diffusion lter (less output) for ECLSOFTLINEARIP.

• ESLIPFILTERLD: front low diffusion lter (more output) for ECLSOFTLINEARIP.

• ESLIPFY: foot plate kit with tilt for the ECLSOFTLINEARIP (2 pcs).

• EPTWCBHEAD: ball head joint for center mount bracket EPTWCBRK series.

• ESLIPBRK: center mount bracket for ECLSOFTLINEARIP.

• ESLIPSG50: 50° SnapGrid, for ECLSOFTLINEARIP by DoP choice.

• RSR0630A/B: steel security cable for hanging bodies, inox steel shackle, L=60 cm, silver/black.

• C6002: slim aluminium clamp, 200 kg loading, 48-51 mm tubes, M10 bolt.

• IPTESTBOX: portable vacuum and pressure tester for ProLights IP xtures.

• WSBBR512G5: blackBox R-512 G5 receiver 512Ch, 2.45GHz & 5.8GHz, DMX/RDM optional.

• WSBBF1G6: BlackBox F-1 G6 transrec, 512ch, 2.45GHz, DMX&RDM,Bluetooth,G3,G4,G4S, G5, CRMX.

• WSBBF1G5: blackBox F-1 G5 transmitter, 2,45GHz & 5.2/5,8 GHz, DMX/RDM, 512Ch.

• TOUR53415L03: dmx cable HC5340. CANC5MXX XLR 5p->CANC5FXX XLR (f) 5p, L.3m.

• 958225L03: 3x2.5mm TH07 Cable, 16A 3p PwCon MXW, 16A 3p PwCon FXW, L. 3m.

• 9513FXWL03: ass. 3x2.5mm TH07 cable, 16A 3p 230V CEE plug, MENAC3FXW socket, L.3 m.

• 9533FXWL03: ass. 3x2.5mm TH07 cable, SHUKO plug, MENAC3FXW socket, L.3m.

• WSBBR512G6: blackBox R-512 G6 receiver 512Ch, 2.45GHz,DMX&RDM,Bluetooth,G3,G4,G4S,G

5,CRMX.

• UPBOX1UP5: rmware uploader kit, USB IN, 5pin XLR DMX OUT, USB OUT.

119 mm

[4.7in]

1000 mm

[39.4in]

85 mm

[3.3in]

Fig. 01

Weight: 7.1 kg - 15.65 lbs

2 - TECHNICAL DRAWING

PROLIGHTS - EclSoft LinearIP06

Fig. 02

3 - INSTALLATION

MOUNTING

Check that the supporting structure can safely bear the weight of all installed xtures, clamps, cables,

auxiliary equipment, etc. and complies with locally applicable regulations.

When suspending the xture above ground level, secure it against failure of primary attachments by

attaching a safety wire that is approved as a safety attachment for the weight of the xture to an anchor

point on the product main frame.

Do not use removable parts or weak anchors for secondary attachment.

Warning! When clamping the xture to a truss or other structure at any angle, use clamps of half-cou-

pler type. Do not use any type of clamp that does not completely encircle the structure when fastened.

C6002

clamp

RSR0630A/B

Steel security cable

OS27

Quick-lock

C6002

clamp

OS27

Quick-lock

107 mm

4,21 in

107 mm

4,21 in

PROLIGHTS - EclSoft LinearIP 07

Fig. 03

C6002

clamp

C6002

clamp

C6002

clamp

RSR0630A/B

Steel security cable

OS27

Quick-lock

OS27

Quick-lock

OS27

Quick-lock

RSR0630A/B

Steel security cable

PROLIGHTS - EclSoft LinearIP08

5 - START UP

CONNECT AND DISCONNECT POWER FROM THE PRODUCT

To apply and disconnect power to the product:

• Check that the product is installed and secured as indicated in the Safety Informations, and that

personal safety will not be put at risk when the xture lights up.

• Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz).

• The product is then ready for its operations and can be controlled through the available input sig-

nals on board.

• To disconnect power from the product, disconnect the Mains from the socket.

4 - CONNECTION TO THE MAINS SUPPLY

WARNING: For protection from electric shock, the xture must be earthed!

The product is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz

AC power source from 100-240 Volts.

If you need to install a power plug on the power cable to allow connection to power outlets, install a

grounding-type (earthed) plug, following the plug manufacturer’s instructions. If you have any doubts

about proper installation, consult a qualied electrician.

The max power consumption is 250W.

Core (EU) Core (US) Connection Plug terminal marking

Brown Black Live L

Blue White Neutral N

Yellow+green Green Earth

Tabla de contenidos

Otros manuales de Equipo de DJ de ProLights

ProLights

ProLights SOLAR27Q Manual de usuario

ProLights

ProLights EclProfile CT+ Manual de usuario

ProLights

ProLights AIR5FAN Manual de usuario

ProLights

ProLights 6 BEAM Manual de usuario

ProLights

ProLights MOSAICOXL Manual de usuario

ProLights

ProLights ECLFRJPTU-DY Manual de usuario

ProLights

ProLights Z7SPOT Manual de usuario

ProLights

ProLights ARENACOB4FC Manual de usuario

ProLights

ProLights ARCPOD27Q Manual de usuario

ProLights

ProLights STARBALL Manual de usuario

ProLights

ProLights VERSAPAR PARLED ZOOM Manual de usuario

ProLights

ProLights VORTEX VXBUBBLE Manual de usuario

ProLights

ProLights QUADMOON Manual de usuario

ProLights

ProLights TRIBE AQUA Manual de usuario

ProLights

ProLights ARCLED1107UV Manual de usuario

ProLights

ProLights PHYRO600SNOW Manual de usuario

ProLights

ProLights ECLIPSEHDTWC Manual de usuario

ProLights

ProLights VX1300SNOW Manual de usuario

ProLights

ProLights LUMIPAR12UAW Manual de usuario

ProLights

ProLights LUMIPAR6Q Manual de usuario

ProLights

ProLights Tribe LUMIPIX12UQ Manual de usuario

ProLights

ProLights CROMOSPOT500 Manual de usuario

ProLights

ProLights ECLIPSE FRESNEL TU Manual de usuario

ProLights

ProLights EMERALD Manual de usuario

Manuales populares de Equipo de DJ de otras marcas

ALPHA LITE

ALPHA LITE ALPHA 1500 Manual del propietario

Chauvet

Chauvet OVATION E-930VW Manual de usuario

Zumtobel

Zumtobel APHRODITE Home Manual de usuario

Snow Masters

Snow Masters Zig Oscillator Manual de usuario

EuroLite

EuroLite 50530554 Manual de usuario

Beamz

Beamz BUV243 Manual de usuario

thomann

thomann Stairville DJ Lase 40-G MK-III Manual de usuario

Eagletone

Eagletone 6 Eyes Flower Manual de usuario

EuroLite

EuroLite FLD-1508 Manual de usuario

Technical Pro

Technical Pro LG8xSEA Manual de usuario

JB Systems

JB Systems Lounge Laser DMX Manual de usuario

Lightmaxx

Lightmaxx Vega Halo 90 Manual de usuario

Elation

Elation FUZE WASH Z350 Manual de usuario

Maverick

Maverick MK3 WASH Manual de usuario

Infinity

Infinity TF-260C7 Fresnel Manual de usuario

Chauvet

Chauvet EVE E-50Z Manual de usuario

Eliminator Lighting

Eliminator Lighting E 138 Manual de usuario

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manual de usuario
