PROAIM CINEMA Series Manual de usuario

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Flymate Versale Camera Dolly with Universal

Track Ends (DL-FLMT-01)

Assembly Manua l

Central Support with Baby feet

Long Feet

100 mm

Bowl Base 150mm

Bowl Base

End Truss

Baby feet

Camera Plaorm

Mitchell Base

75mm

Conversion Ring

 Insert both the track rails (Not included) into

the end truss & ghten knobs properly.

Note: For reference, We have used an 8 rail

track (Not included) for the assembly purpose.

You must place the central support in the middle

for a longer track, as shown in the photo.

 Now aach long feet to the end truss and

ghten the knobs to secure them.

Flymate Versale Camera Dolly Setup

 Now, place the camera plaorm with a

150mm bowl aached to it onto the rail track.

The handle part of the camera plaorm

should be inside the rail track, as shown. Make

sure all wheels are aligned correctly on the

rails, so the camera plaorm runs smoothly.

 Mount the 100mm bowl onto the camera

plaorm and ghten it appropriately with the

help of a screw driver, as shown.

Mount Camera Plaorm with Bowl on the Track

Note: Assembly steps for 75mm/100mm/150mm Bowl are the same.

 For hi-hat mounng, aach the Hi-hat adap-

tors to the camera plaorm, then insert the

bolt to secure them.

 Aach the long feet to the Hi-hat adaptors

and ghten the knob to secure them togeth-

er, as shown in the image.

 Similarly, you can aach Mitchell base to the

camera plaorm, and secure it by ghtening

the bolt with the help of the Allen key.

 Similarly, you can aach the baby feet to the

Hi-hat adaptors and secure them by ghten-

ing the knob.

 Lastly, mount your camera setup onto the

uid head (Not included) and secure it

properly.

YOUR FLYMATE VERSATILE CAMERA DOLLY WITH UNIVERSAL TRACK ENDS

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
