you want the camera to be angled down, use the supplied wedges between the
camera and the mounting plates as shown in the picture.
Mount the license plate on the license plate bracket.
for the camera’s power cable t
hrough the vehicle’s body to the
If in doubt, seek professional installation assistance.
Some vehicles may have a hole available to pass the wire through, such as where the
license plate light is mounted, or you can drill a hol s
e to where the power cable
is attached to the camera. Once you have chosen where the cable will enter the
vehicle’s body, remove the camera.
Before you drill a hole you MUST CHECK and se
e WHAT IS BEHIND WHERE YOU ARE
DRILLING. If there are any vehicle components, such as electrical parts or fuel
system components behind where you are drilling, you must take whatever
precaution is necessary not to damage them. Remove the license plate and
After you have drilled the
hole, insert the supplied grommet, then pass the camera
cables through the grommet into the vehicle. You must use the grommet to prevent
the metal edge of the hole from cutting the camera cable.
transmitter box inside the trunk. Connect the camera’s power cable and
the transmitter box power cable to the transmitter box.
Next you’ll need to find the vehicle’s reverse lights. Turn the vehicle’s ignition key to
the accessory position, engage the park
ing brake and put the car in reverse. Look at
the vehicle’s tail lights to see where the reverse lights are located, they are the white
To locate the reverse light’s 12V+ wire it will be nec ry to gain access to
the rear of the vehicle’s tail li
ght. For help locating the vehicle’s reverse light circuit
contact your vehicle’s manufacturer for vehicle specific wiring diagrams.
Once you have located the reverse light circuit you will have to route the transmitter
box power cable to that location. Y
ou must securely fasten the power cable to prevent
it from being caught on any vehicle component such as the trunk hinge.
the cable on the outside of the vehicle!
If you are able to use an e xisting ope ning, skip
