Prestigio GeoVision 430 Manual de usuario

Prestigio GeoVision 430

GPS Navigational and Multimedia System

User Manual

Version 1.6

CAUTION:

zTo reduce the risk of electric shock, do not remove the cover

(or back). No user-serviceable parts inside. Refer servicing to

qualified service personnel. Unplug the product from the wall

outlet before servicing or when it is not used for a long period

of time.

zThe manufacturer should not hold responsibility for the

damage caused by any substitutions and modifications of the

product without authorization from the manufacturer or

authorized organization.

WARNING:

zThe unit is designed to provide user with route suggestions. It

does NOT reflect road closures, road conditions, traffic

congestion, weather conditions, or other factors that may

affect safety or timing while traveling.

zUse the unit only as a navigational aid. Do NOT attempt to use

the unit for any purpose requiring precise measurement of

direction, distance, location, or topography. This product

should NOT be used to determine ground proximity for aircraft

navigation.

The lightning flash with arrowhead symbol, within an equilateral triangle,

is intended to alert the user to the presence of un-insulated “dangerous

voltage” within the product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the appliance.

1. Getting Started

1.1 Safety Precautions

1.2 Package Content

2. Product Views

2.1 Front and Top Views

2.2 Left and Right Side Views

2.3 Rear View

3. System Connections

3.1 Connecting to External GPS Antenna

3.2 Connecting to Earphone

3.3 Connecting to PC

3.4 Inserting/Removing SD Memory Card

3.5 Connecting to AC Adaptor

3.6 Connecting to Car Adaptor

4. Navigation

5. Photo

5.1 Loading Files

5.2 Viewing Files

6. Setting

6.1 Language

6.2 Date & Time

6.3 Volume

6.4 Backlight

6.5 Screen

6.6 Power

7. Mounting Accessories

8. Troubleshooting

9. Appendix

9.1 Product Specifications

9.2 Technical Support and Warranty Information

9.3 Disclaimer

9.4 Trademark Acknowledements

Table of Contents

1. Getting Started

Thank you for purchasing Prestigio GPS Navigational and Multimedia System.

You have made an excellent choice and we hope you will enjoy all of its capabilities.

The product offers a fully functional personal navigation system together with

multimedia players such as MP4 player, MP3 player, and photo viewer. Please read

through the user manual carefully before using the product, and follow all of the

procedures in the manual to fully enjoy all features of the product.

1.1 Safety Precautions

Please observe all safety precautions before using Prestigio GPS

Navigational and Multimedia System. Please follow all procedures outlined

in this manual to correctly operate the device. Failure to comply with the

following potentially hazardous situations may result in injury or property

damage.

zDo NOT attempt to disassemble or alter any part of the device that is not

described in this guide.

zDo NOT block any ventilation openings.

zDo NOT place the device in contact with water or any other liquids. The device

is NOT designed to be liquid proof of any sort.

zIn the event of liquid entry into interior of device, immediately disconnect the

device from the computer. Continuing use of the device may result in fire or

electrical shock. Please consult your product distributor or the closest support

center.

zTo avoid risk of electrical shock, do not connect or disconnect the device with

wet hands.

zDo NOT place the device near a heat source or directly expose it to flame or

heat.

zDo NOT place the device in vicinity of equipments generating strong

electromagnetic fields. Exposure to strong magnetic fields may cause

malfunctions or data corruption and loss.

Getting Started

1.2 Package Content

Item Description Quantity

Prestigio GeoVision 430 1

User Manual 1

Driver DVD 1

GPS Antenna 1

AC Adaptor 1

Car Adaptor 1

Mounting cradle 1

USB Cable 1

Mounting Bracket 1

Touch Pen 1

Getting Started

2. Product Views

The images in this document are for user reference only. The actual product may

look slighly different from these images.

2.1 Front and Top Views

1. 4.3” LCD screen

2. Power Button

Press and hold the button to exit or activate standby mode.

2.2 Left and Right Side View

3. USB Port

Connect to PC for map updates.

4. SD Card Slot

Insert SD memory card for multimedia access.

5. DC 5V Input Jack

Connect to car adapter or AC adapter.

1 2

3 4 5 76

Product Views

6. Earphone Jack

Connect to earphone. On board speaker automatically mutes when

earphone is connected.

7. Volume Control

Adjust the volume of earphone or on board speaker.

2.3 Rear View

8. External GPS Antenna Jack

Connect to external GPS antenna.

9. Power Swtich

Switch power on/off.

Product Views

3. System Connections

WARNING:

Switch off and unplug the unit and any other external device

connected to the unit before attempting to connect the unit to any

external device. Failure to comply may result damages to both the

unit and the connected device.

3.1 Connecting to External GPS Antenna

1. The unit is designed with a GPS antenna

to connect to the device for better satellite

signal reception.

2. Simply insert the receptacle end into the

jack on device and place the antenna at an

open area.

3.2 Connecting to Earphones

1. Connect the included earphone to the

earphone jack at right side of the unit.

2. The on board speakers automatically

mutes when the earphone is

connected.

System Connections

WARNING:

Excessively loud volume may detriment hearing. Turn down the

volume before connecting to the earphone and then raise the

volume to appropriate level.

3.3 Connecting to PC

WARNING:

Please install ActiveSync software from the driver DVD before

connecting device to host computer.

The unit is designed with a USB port to be

connected to PC for map updating. Follow

the instructions below for details.

1. Install driver in the host PC.

2. Connect the unit to host PC via

supplied USB cable and turn on the

unit.

3. “Mobile Device” will appear in “My

Computer” for map updating.

System Connections

3.4 Inserting SD Memory Card

he unit is designed with a SC

memory slot for multimedia access.

Insert the SD memory card into the

unit and press until it locks in place as

shown below.

2. To remove SD memory card, gently

press it with fingernail. The card will

unlock and eject slightly. It is now safe

to remove the card.

3. Do NOT use force to remove SD

memory card for it may damage the

unit and the card itself.

3.5 Connecting to AC Adaptor

1. The unit is supplied with an AC

adaptor for powering and battery

charging.

2. Turn unit power off before

connecting/disconnecting.

3. Connect AC adaptor to the jack

marked DC 5V IN at right side of the

unit as shown at the left.

4. Plug the two-prong end of the power

cord into a grounded electrical outlet.

System Connections
