USER MANUAL

On-Line UPS

PowerWalker VFI 6000RT LCD

PowerWalker VFI 6000P/RT LCD

PowerWalker VFI 10000RT LCD

PowerWalker VFI 10000P/RT LCD

Uninterruptible Power Supply System

Contents

1. Introduction......................................................................................... 1

2. Safety Warnings.................................................................................. 4

2.1 Installation ...................................................................................... 4

2.2 Operation........................................................................................ 5

2.3 Maintenance, servicing and faults ................................................... 6

2.4 Transport ........................................................................................ 7

2.5 Storage........................................................................................... 7

2.6 Standards ....................................................................................... 7

3. Installation........................................................................................... 9

3.1 Inspecting the Equipment................................................................ 9

3.2 Unpacking the carton ...................................................................... 9

3.3 UPS Rear Panel ........................................................................... 12

3.4 UPS Front Panel........................................................................... 13

3.5 Rack mount Setup ........................................................................ 14

3.6 Tower Setup.................................................................................. 18

3.7 Installation of UPS with AC inputs ................................................. 19

4. Power cables connection & Startup................................................. 21

4.1 Access to terminal block................................................................ 22

4.2 Common input sources connection ............................................... 22

4.3 Separate input sources connection ............................................... 23

4.4 Frequency converter connection ................................................... 24

4.5 UPS Initial Startup......................................................................... 24

4.6 Parallel Installation and Operation................................................. 25

5. Operation........................................................................................... 31

5.1 Display Panel................................................................................ 31

5.2 Operating mode............................................................................ 33

5.3 Turning on and Turning off UPS .................................................... 36

5.4 LCD operation .............................................................................. 38

6. UPS Maintenance.............................................................................. 47

6.1 UPS and Battery Care .................................................................. 47

6.2 Transporting the UPS.................................................................... 47

6.3 Storing the UPS and Batteries....................................................... 48

6.4 Testing Batteries ........................................................................... 48

6.5 Recycling the Used Battery or UPS............................................... 49

7. Specifications ................................................................................... 50

7.1 Electrical specification................................................................... 50

7.2 Dimension and Weight.................................................................. 51

7.3 Operating Environment ................................................................. 51

8. Troubleshooting................................................................................ 52

8.1 Typical Alarms and Conditions ...................................................... 52

9. Communication................................................................................. 57

9.1 RS-232 and USB Communication Ports ........................................ 57

9.2 Network Management Card (Optional) .......................................... 59

9.3 UPS Management Software.......................................................... 59

9.4 REPO Function............................................................................. 60

1. Introduction

This Online R/T Series is an uninterruptible power supply

incorporating double-conversion technology. It provides perfect

protection specifically for computer equipment, communication

systems to computerized instruments. It protects your sensitive

electronic equipment from basic power problems such as power

failures, power sags, power surges, brownout, and line noise.

Power outages can occur when you least expect them and power

quality can be erratic. These power problems have the potential to

corrupt critical data, destroy unsaved work sessions, and damage

hardware

－

causing hours of lost productivity and expensive

repairs.

With the Online R/T UPS, you can safely eliminate the effects of

power disturbances and guard the integrity of your equipment. The

UPS can handle array--network devices flexibility that makes it the

best choice for protect your LANs, servers, workstations, and other

electrical equipment.

Online R/T UPS as Rack installation:

Figure 1-1: Online R/T 6K UPS

Figure 1-2: Online R/T 10K UPS

Online R/T UPS as Tower installation.

Figure 1-3: Online R/T 6K UPS Figure 1-4: Online R/T 10K UPS

Providing outstanding performance and reliability, the UPS’s unique

benefits include:

Online UPS design with pure sine wave output.

True online double-conversion technology with high power

density, utility frequency independence, and generator

compatibility.

Intelligent Battery Management technology that uses advanced

battery management to increase battery service life, optimize

recharge time.

Selectable High Efficiency mode of operation.

Start-on-battery capability for powering up the UPS even if

utility power is not available.

Standard communication options: one RS-232 communication

port, one USB communication port.

Optional connectivity cards with enhanced communication

capabilities.

Extended runtime with up to four Extended Battery Modules

(EBMs) per UPS.

Optional installation method

－

Rack & Tower.

Remote shutdown control through the Remote Emergent

Power-off (REPO) port.

Maintenances are simplified by allowing the safe replacement

of batteries without powering down the UPS.

Parallel with another Online R/T UPS, max amount is 2.

Optional Rack Slider.

PDU is standard configuration with maintenance bypass

switch.

2. Safety Warnings

IMPORTANT SAFETY INSTRUCTIONS FOR EACH STEP SAVE

THESE INSTRRUCTIONS.

2.1 Installation

Condensation may occur if the UPS is moved directly from a

cold to a warm environment. The UPS must be absolutely dry

before being installed. Please allow an acclimatization time of

at least two hours.

Do not install the UPS near water or in damp environment.

Do not install the UPS where it would be exposed to direct

sunlight or near heat.

Do not block ventilation openings in the UPS’s housing.

Place cables in such a way that no one can step on or trip over

them.

UPS has provided earthed terminal, in the final installed system

configuration, equipotent earth bonding to the external UPS

battery cabinets.

An integral single emergency switching device which prevents

further supply to the load by the UPS in any operation mode

should be provided in the building wiring installation.

An appropriate disconnect device as short-circuit backup

protection should be provided in the building wiring installation.

For three-phase equipment connection to an IT power system,

a four-pole device which disconnect all phase conductors and

CAUTION:

Before performing the procedures in this document, read and follow

the safety instructions and important regulatory information in your

Safety, Environmental, and Regulatory Information document.

the neutral conductor should be provided in the building wiring

installation.

This is permanently connected equipment , it must be installed

by qualified maintenance personnel.

For permanently connected equipment: make sure that a

readily accessible disconnect device is incorporated in the

building installation wiring.

To reduce the risk of fire, connect only to a circuit provided with

branch circuit overcurrent protection with an ampere rating in

accordance with the IEC/EN 60934 standard or your local

electrical code and have a contact air gap of at least 3 mm.

Uninterruptible power supply

output power 240V

6K 40 amp

2-pole circuit breaker

10K 63 amp

2-pole circuit breaker

You can connect four extended battery modules to the

uninterruptible power supply.

Earthing connection is essential before connecting to the

building wiring terminal.

2.2 Operation

Do not disconnect the earth conductor cable from the UPS or

the building wiring terminals in any time since this would cancel

the protective earthing of the UPS system and all connected

loads.

The UPS output terminal block may be electrically active even if

the UPS system is not connected to the building wiring

terminal.

In order to completely disconnect the UPS, firstly press the

OFF button, and then disconnect the mains lead.

Ensure that no liquid or other foreign objects can enter the

UPS.

The UPS can be operated by any individual without previous

experience.

2.3 Maintenance, servicing and faults

The UPS operates with hazardous voltages. Maintenance

should be carried out only by qualified maintenance personnel.

Caution - risk of electric shock. Even after the unit is

disconnected from the mains power supply (building wiring

terminal), components inside the UPS are still connected to the

battery which have potentially dangerous.

Before carrying out any kind of service and/or maintenance,

please disconnect the batteries. Verify that no current is

present and no hazardous voltage exist in the capacitor or BUS

capacitor terminals.

Batteries must be replaced only by qualified personnel.

Caution – the risk of electric shock. The battery circuit is not

isolated from the input voltage. Hazardous voltage may occur

between the battery terminals and the ground. Verify that no

voltage is present before servicing!

Batteries have a high short-circuit current and pose a risk of

shock. Take all precautionary measures specified as below and

any other measures necessary when working with batteries:

1) Remove all jewellery, wristwatches, rings and other metal

objects

2) Use only tools with insulated grips and handles.

3) When changing batteries, replace with the same quantity

and the same type of batteries.

4) Do not attempt to dispose of batteries by burning them. It

could cause explosion.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unión Postal Universal de PowerWalker

PowerWalker

PowerWalker VFI 1000RT LCD Manual de usuario

PowerWalker

PowerWalker VI 1200 Manual de usuario

PowerWalker

PowerWalker VFI 1000 R1U Manual de usuario

PowerWalker

PowerWalker VFI 1000 LCD Manual de usuario

PowerWalker

PowerWalker VFI 1000RM Manual de usuario

PowerWalker

PowerWalker VI CW Series Manual de usuario

PowerWalker

PowerWalker BP P96T Guía del administrador

PowerWalker

PowerWalker VFI 3000 LCD Guía de instalación

PowerWalker

PowerWalker VFI 10000CP 3/3 Manual de usuario

PowerWalker

PowerWalker VFI 10000P/RT LCD Manual de usuario

PowerWalker

PowerWalker VI 400 Manual de usuario

PowerWalker

PowerWalker VFD 400 IEC Manual de usuario

PowerWalker

PowerWalker VFI 2000RT Manual de usuario

PowerWalker

PowerWalker VI 650 GX Manual de usuario

PowerWalker

PowerWalker MBP 1-1 Manual de usuario

PowerWalker

PowerWalker VFI 1000T/E LCD Manual de usuario

PowerWalker

PowerWalker VFI CG PF1 Series Manual de usuario

PowerWalker

PowerWalker VFI RT HID Series Manual de usuario

PowerWalker

PowerWalker VFI 3000T LCD Manual de usuario

PowerWalker

PowerWalker VFI 6000 CT LCD Manual de usuario

PowerWalker

PowerWalker 1000VA Manual de usuario

PowerWalker

PowerWalker VI 1000 Manual de usuario

PowerWalker

PowerWalker VFI 2000 RMG/S PF1 Manual de usuario

PowerWalker

PowerWalker VFI ICT IoT Series Manual de usuario

Manuales populares de Unión Postal Universal de otras marcas

Pylontech

Pylontech Victron & Pylontech US5000 Manual de usuario

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manual de usuario

Mecer

Mecer ME-1000-WTU Manual de usuario

Mustek

Mustek PowerMust 530(B) Plus Manual de instalación y operación

Emerson

Emerson Liebert NXL series Manual de usuario

MAKELSAN

MAKELSAN BOXER SERIES Manual de usuario

Block

Block PC-0524-400-0 Manual de usuario

CyberPower

CyberPower CP585LCD Manual de usuario

Eaton

Eaton 3S Instrucciones de montaje

CyberPower

CyberPower Office Tower Series UPS 1000 Manual de usuario

CyberPower

CyberPower BM100 Manual de usuario

Best Power

Best Power 610 Manual de usuario

Best Power

Best Power Unity/I UT3K Manual de usuario

Mustek

Mustek PowerMust 400 Offline Manual de usuario

Xantrex

Xantrex Trace 512 UR-UPS Manual de usuario

Forza

Forza SL-1501UL Manual de usuario

LEGRAND

LEGRAND keor 310081 Manual de usuario

ABB

ABB Conceptpower DPA 500 Manual de usuario
