Poly Blackwire 3200 Series Manual de usuario

Blackwire 3200 Series

Corded headset with inline call

control

User Guide

Contents

Overview 3

Setup 4

Load software 4

Fit 5

Adjust the headband 5

Position the boom 5

Adjust the boom 5

Use the inline controller 6

Make/take/end calls 6

Volume 6

Mute 6

Troubleshooting 7

Headset 7

Support 8

Icons Inline control LEDs Function

Call button Flashes green Incoming call

Solid green On a call

Volume up button Increases the listening volume

Volume down

button

Decreases the listening volume

Mute button Solid red Headset is muted

Overview

Power on your headset by connecting to your computer or mobile device.

You can connect your headset in 2 ways:

1Via USB-A/USB-C connector

NOTE Headset call control functionality may vary in mobile devices.

2Via 3.5 mm connector*

NOTE Headset call control functionality is not available.

* 3.5 mm connector available on Blackwire 3215/3225 only.

Customize your device behavior through advanced settings and options with Poly Lens

Desktop App. Some softphones require the installation of Poly software to enable device

call control (answer/end and mute) functionality. Download: poly.com/lens.

NOTE Device settings are also available in Plantronics Hub Desktop App.

Update your Poly device

Keep your firmware and software up-to-date to improve performance and add new

features to your Poly device.

Update your device using your computer with Poly Lens Desktop App. Download at

poly.com/lens.

While updating:

• Do not use your Poly device until the update is complete.

• Do not start a second update from a second device.

• Do not stream media.

• Do not answer or place a call.

Setup

Load software

Lengthen or shorten the band until it fits comfortably. The cushions should sit comfortably

over the center of your ears.

This headset can be worn on the left or right side.

Rotate the boom to align with your mouth.

CAUTION To avoid breaking the boom, only rotate it up and over 180°.

Gently bend the boom in or out so it is approximately two finger widths from the corner of

your mouth.

Fit

Adjust the headband

Position the boom

Adjust the boom

Headset call control is a software feature and dependent on a compatible softphone. If you

have not installed Poly Lens Desktop App (poly.com/lens) or do not have a compatible

softphone, press the headset call button first and then make/take/end the call using the

softphone application.

Answer or end a call

Tap the Call button or use your softphone.

Make a call

Dial using your softphone application.

Redial

If not on an active call, double key press the call button to redial the last call.

Hold

Press and hold the call button for 2 seconds to put a call on hold.

Listening volume

Press the Volume up (+) or Volume down (-) button.

Adjust headset microphone volume (softphone)

Place a test softphone call and adjust softphone volume and PC sound volume accordingly.

During a call, briefly press the mute button to mute the microphone on the inline

controller. To unmute press the button again.

Use the inline controller

Make/take/end calls

Volume

Mute

I cannot hear caller. • Listening volume is too low. Press the volume up button on

the headset. and/or ensure that the volume setting on your

computer is set accurately.

• The analog headset is not set as the default audio device. Use

the audio settings in your sound control panel/preferences to

select your headset as the default audio device.

Callers cannot hear me. • Headset is muted. Slide the mute button up to unmute the

microphone.

• Headset microphone boom aligned incorrectly. Align the

headset boom with your mouth.

• The analog headset is not set as the default Voice device. Use

the audio settings in your sound control panel/preferences to

change the input device.

The sound in the headset is

distorted.

I can hear an echo in the headset.

• Lower the listen volume on your softphone until the

distortion disappears.

• Adjust volume on headset.

The other headset I was using to

listen to music does not work any

more.

• The analog headset will set itself as the default audio device

in Windows. Use the audio settings in your sound control

panel/preferences to change the audio device.

My phone is not nding my

headset during a call or while

listening to music.

• When on a call or listening to music, make sure that audio is

routing to the desired headset by going to your settings and

ensuring it is defaulted.

Troubleshooting

Headset

Support

NEED MORE HELP?

poly.com/support

Plantronics, Inc. Plantronics B.V.

345 Encinal Street

Santa Cruz, CA 95060

United States

Scorpius 171

2132 LR Hoofddorp

Netherlands

are trademarks of Plantronics, Inc. All other trademarks are the property of their

respective owners. Manufactured by Plantronics, Inc.

211088-06 06.21
