54Mbps Wireless PoE Access Point

Key Feature

Data Sheet

The WAP-4033PE supports both IEEE 802.11b and IEEE 802.11g

standards. You can use it for connecting to an existing WLAN, or to build

up a new wireless LAN. Except essential AP mode, the WAP-4033PE

provides Repeater, Bridge, WDS, and Client modes to accommodate all

kinds of network topology. High data rate (up to 54Mbps) performing

allows faster communication between LAN and WLAN. The WAP-4033PE is

also integrated with the 802.3af PoE capability. It can directly draw power

from a PoE switch via CAT5 cable, thus provides greater flexibility for

installation. Maximize network efficiency via using the WAP-4033PE while

minimizing your network investment and maintenance costs.

The WAP-4033PE supports WEP, WPA, WPA2 and MAC address filter

function to consolidate the wireless network security. Meanwhile, you can

prevent unauthorized stations from accessing your wireless network. With

the user-friendly management interface and versatile features, the PLANET

WAP-4033PE is the best choice to integrate your wireless and wired

network seamlessly.

WAP-4033PE

• Compliant with the IEEE 802.11g/802.11b (DSSS) 2.4GHz specification

• Supports PoE port (IEEE 802.3af compliant)

• High data rate up to 54Mbps network speed, auto rate fallback

• Seamlessly integrates wireless and wired networks

• Supports WEP/WPA/WPA2 encryption

• Supports AP / AP Client / Bridge / Repeater and WDS (Wireless

Distributed System) mode

• Supports MAC Address Filter

• Supports Transmit Power Control

• Provides a reverse-polarity SMA connector for external antenna

connection

• Built-in DHCP server

• Web-based configuration

PLANET reserves the right to change specifications without prior notice. All brand names and trademarks are property or

10-06 C-WAP4033PE-1

PLANET Technology Corporation

11F, No. 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan R.O.C.

Tel: 886-2-2219-9518  Fax: 886-2-2219-9528

Email: [email protected] www.planet.com.tw

VoIP Gateway: vip.planet.com.tw

54Mbps Wireless PoE Access Point

WAP-4033PE

54Mbps Wireless PoE Access Point

Product

Specification

Applications

Ordering Information

Model

Standard

Transfer Rate

Modulation

Radio Technology

Antenna

Operating Modes

Transmit Power

LAN Interface

Cabling

LED Indicators

Power

Temperature

Humidity

Dimension

Weight

Emission

WAP-4033PE

Wireless: IEEE 802.11b, 802.11g

Wired: IEEE 802.3, 802.3u

PoE: IEEE 802.3af

802.11g: 54/48/36/24/18/12/9/6Mbps

802.11b: 11/5.5/2/1Mbps

OFDM@54Mbps, CCK@11/5.5Mbps, DQPSK@2Mbps and DBPSK@1Mbps

Direct Sequence Spread Spectrum (DSSS)

Detachable dipole antenna

Access Point

Station - Ad-Hoc

Station - Infrastructure

Bridge - Point to Point

Bridge - Point to Multi-Point

Bridge - WDS

Universal Repeater

18dBm (Maximum)

1-port RJ-45, Auto-MDI/MDI-X

Category 5/5e or above, 4-pair

3; PWR, WLAN, LAN

12V DC, 500mA or PoE

0 ~ 55 Degree C (Operating)

10 ~ 90%, non-condensing (Operating)

154 x 88 x 32 (mm)

180g

FCC class B, CE-mark

Cost-effective PoE Wireless LAN

The WAP-4033PE supports various operating

modes to accommodate different network

topologies: Wireless Clients Access, WISP, LAN

to LAN, or LAN to Multi-LAN. With the 802.3af

PoE capability, there is no need to get an AC

power socket for each AP. The WAP-4033PE

can directly obtain power from all types of

PLANET PoE switches via CAT5 cable, making

the installation more flexible and easy.

Data Sheet

WAP-4033PE

RAIUS Server

WL-U356M

WAP-4033PE Switch

WL-3563

WL-3560

Centrino

Power

over

Ethernet
