WAP-4036
802.11g Wireless Access Point
Overview
The WAP-4036 supports both IEEE 802.11b and IEEE 802.11g standard. You can use it
for connecting to an existing WLAN, or to build up a new wireless LAN. Except essential
AP mode, the WAP-4036 provides Repeater, WDS, AP+WDS, and Client modes to
accommodate all kinds of network topology. High data rate (up to 54Mbps) performing
allows faster communication between LAN and WLAN. Maximize network efficiency via
using the WAP-4036 while minimizing your network investment and maintenance cost.
The WAP-4036 supports WEP, WPA / WPA2 Personal encryptions and MAC address filter
function to consolidate the wireless network security. Meanwhile, you can prevent
unauthorized stations from accessing your wireless network. With the user-friendly
management interface and versatile features, the PLANET WAP-4036 is the best choice to
integrate your wireless and wired network seamlessly.
Ordering Infomation
WAP-4036 802.11g Wireless Access Point
Accessories
ANT-OM5 5dBi Desktop Antenna
©PLANET Technology Corporation. All rights reserved.
Keyword Search
Home > Product > Wireless LAN > 802.11g Wireless LAN
LAN Switches
Power over Ethernet
Media Conversion
Wireless LAN
802.11g Wireless LAN
Super G Wireless LAN
MIMO Wireless LAN
802.11n/g Wireless LAN
802.11a/g Wireless LAN
Outdoor Wireless LAN
802.11a/g MESH Wireless LAN
Wireless LAN Switch
Bluetooth
Wireless Antenna & Cable
Accessories
IP Surveillance
IP Telephony
Broadband Communication
Network Security
Network Peripheral
Support Resources
‧User's Manual
Related Products
‧WL-8317
‧WL-U356M
FAQ
Awards
User Name:
Password:
Login
WAP-4036
802.11g Wireless Access Point
Key Features
• Compliant with the IEEE 802.11g / 802.11b (DSSS) 2.4GHz specification
• High data rate up to 54Mbps network speed, auto rate fallback
• Seamlessly integrates wireless and wired networks
• Supports WEP / WPA / WPA2 Personal encryption
• Supports AP / Client / WDS / AP+WDS and Repeater mode
• Supports MAC Address Filter
• Provides a reverse-polarity SMA connector for external antenna connection
• Built-in DHCP server
• Web-based configuration
Ordering Infomation
WAP-4036 802.11g Wireless Access Point
Accessories
ANT-OM5 5dBi Desktop Antenna
©PLANET Technology Corporation. All rights reserved.
Keyword Search
Home > Product > Wireless LAN > 802.11g Wireless LAN
LAN Switches
Power over Ethernet
Media Conversion
Wireless LAN
802.11g Wireless LAN
Super G Wireless LAN
MIMO Wireless LAN
802.11n/g Wireless LAN
802.11a/g Wireless LAN
Outdoor Wireless LAN
802.11a/g MESH Wireless LAN
Wireless LAN Switch
Bluetooth
Wireless Antenna & Cable
Accessories
IP Surveillance
IP Telephony
Broadband Communication
Network Security
Network Peripheral
Support Resources
‧User's Manual
Related Products
‧WL-8317
‧WL-U356M
FAQ
Awards
User Name:
Password:
Login
WAP-4036
802.11g Wireless Access Point
Specification
Model WAP-4036
Product
Standard IEEE 802.11g / 802.11b (Wireless), IEEE 802.3 (Wired)
Transfer Rate 802.11g: 54 / 48 / 36 / 24 / 18 / 12 / 9 / 6Mbps
802.11b: 11 / 5.5 / 2 / 1Mbps
Modulation OFDM@54Mbps, CCK@11/5.5Mbps, DQPSK@2Mbps and
DBPSK@1Mbps
Radio Technology Direct Sequence Spread Spectrum (DSSS)
Antenna Detachable dipole antenna
Operating modes
Access Point
Client
Repeater
WDS
AP+WDS
Transmit Power 15dBm ± 2dBm
LAN Interface 1-Port RJ-45, Auto-MDI / MDI-X
Cabling Category 5 / 5e or above, 4-Pair
LED Indicators 6; PWR, SYS, LAN 100M, LAN LNK, LAN ACT, WLAN ACT
Power 9V DC, 700mA
Temperature Operating: 0 ~ 55 Degree C
Humidity Operating: 10 ~ 90%, non-condensing
Dimension (W x D x H) 186 x 119 x 29 (mm)
Weight 200g
Emission FCC class B, CE-mark
Ordering Infomation
WAP-4036 802.11g Wireless Access Point
Accessories
ANT-OM5 5dBi Desktop Antenna
©PLANET Technology Corporation. All rights reserved.
Keyword Search
Home > Product > Wireless LAN > 802.11g Wireless LAN
LAN Switches
Power over Ethernet
Media Conversion
Wireless LAN
802.11g Wireless LAN
Super G Wireless LAN
MIMO Wireless LAN
802.11n/g Wireless LAN
802.11a/g Wireless LAN
Outdoor Wireless LAN
802.11a/g MESH Wireless LAN
Wireless LAN Switch
Bluetooth
Wireless Antenna & Cable
Accessories
IP Surveillance
IP Telephony
Broadband Communication
Network Security
Network Peripheral
Support Resources
‧User's Manual
Related Products
‧WL-8317
‧WL-U356M
FAQ
Awards
User Name:
Password:
Login
WAP-4036
802.11g Wireless Access Point
Application
Enterprise or Campus Users
In an enterprise or campus area, some mobile users may need a continuous network
connection. By installing the WAP-4036, mobile users can always surf the internet with a
PLANET wireless card in their notebooks or PDAs. The roaming capacity allows users to
connect to the network for transparently roaming from one access point to another.
LAN to LAN or LAN to Multi-LAN
Wiring inside your own building perhaps is an easy job, however, it is hard if network
cabling needs to go through some public areas or difficult wiring environments. The WAP-
4036 can work in WDS or repeater mode to provide a robust solution for connecting two
or more buildings together.
Ordering Infomation
WAP-4036 802.11g Wireless Access Point
Accessories
ANT-OM5 5dBi Desktop Antenna
