Planet XGSW-28040 Manual de usuario

24-Port 10/100/1000Mbps with 4 Shared SFP

+ 4-Port 10G SFP+ Managed Switch

XGSW-28040

Quick Installation Guide

Table of Contents

1. Package Content......................................................................................... 3

2. Requirements ............................................................................................. 4

3. Terminal Setup ........................................................................................... 5

4. Logon to the Console .................................................................................. 6

5. CongureIPAddress .................................................................................. 7

6. Start Web Management............................................................................... 9

Customer Support...........................................................................................12

1. Package Content

Thank you for purchasing PLANET 24-Port 10/100/1000Mbps with 4 Shared SFP

+ 4-Port 10G SFP+ Managed Switch, XGSW-28040. Terms of “Managed Switch”

means the Switches mentioned titled in the cover page of this Quick installation

guide.

Open the box of the Managed Switch and carefully unpack it. The box should

containthefollowingitems:

TheXGSWManagedSwitchx1l

User’s Manual CD x 1l

QuickInstallationGuidex1l

RS232 Cable x 1l

RubberFeetx4l

TwoRack-mountingBracketswithAttachmentScrewsx1l

PowerCordx1l

SFPDustCapsx8l

If any item is found missing or damaged, please contact your local reseller for

replacement.

2. Requirements

Workstations of subscribers running Windows XP/2003/Vista/7/2008, MAC OS9l

orlater,Linux,UNIXorotherplatformcompatiblewithTCP/IPprotocols.

WorkstationinstalledwithEthernetNIC(NetworkInterfaceCard)l

Serial Port connectl(Terminal)

AbovePCwithCOMPort(DB9)

Ethernet Port connectl

 Networkcables-Usestandardnetwork(UTP)cableswithRJ-45connectors.

 AbovePCinstalledwithWEBBrowserandJAVAruntimeenvironmentPlug-in

Note

It is recommended to use Internet Explore 7.0 or above to access

XGSWManagedSwitch.

3. Terminal Setup

To congure the system, connect a serial cable to a COM port on a PC or

notebookcomputerand to serial(console)portof theXGSWManagedSwitch. The

console port of the Managed Switch is DCE already, so that you can connect the

consoleportdirectlythroughPCwithouttheneedofNullModem.

PC / Workstation

with

Terminal emulation software

Serial Port

RS-232

Serial Port

115200,8,n,1

XGSW Managed Switch

A terminal program is required to make the software connection to the XGSW

Managed Switch. Windows’ Hyper Terminal program may be a good choice. The

HyperTerminalcanbeaccessedfromtheStart menu.

1. Click START,thenPrograms,AccessoriesandthenHyper Terminal.

2.When the following screen appears, make sure that the COM port should be

conguredas:

Baud:115200

Databits:8

Parity:None

Stopbits:1

FlowControl:None

4. Logon to the Console

Once the terminal has connected to the device, power on the XGSW Managed

Switch,theterminalwilldisplaythatitisrunningtestingprocedures.

Then, the following message asks the login username and password. The factory

default username and password as following and the login screen in Figure 4-1

appears.

Username:admin

Password:admin

Figure 4-1 XGSW Managed Switch Console Login screen

Note

1.For security reason, please change and memorize the

newpasswordafterthisfirstsetup.

2.Only accept command in lowercase letter under console

interface.

5.CongureIPAddress

TheXGSWManagedSwitchisshippedwithdefaultIPaddressasfollowing.

IPAddress:192.168.0.100

SubnetMask:255.255.255.0

Tocheckthe currentIPaddress or modifyanew IP addressfortheSwitch, please

usetheproceduresasfollow:

Show the current IP address

1. On “Switch/>”prompt,enter“show ip”.

2.Thescreendisplaysthe currentIPaddress,SubnetMask andGateway.Asshow

inFigure5-1.

Figure 5-1 Show IP Information screen

 Congure IP address

3. On “Switch/>” prompt, enter the following command and press <Enter>. As

showinFigure5-2.

Switch/> ip setup 192.168.1.100 255.255.255.0 192.168.1.1

ThepreviouscommandwouldapplythefollowsettingsfortheSwitch.

IP Address: 192.168.1.100

Subnet Mask: 255.255.255.0

Gateway: 192.168.1.1

Figure 5-2 Set IP Address screen

4.RepeatStep1tocheckiftheIPaddressischanged.

If the IP is successfully congured, the Managed Switch will apply the new IP

address setting immediately. You can access the Web interface of XGSW Managed

SwitchthroughthenewIPaddress.

Note

If you do not familiar with console command or the related param-

eter,enter“help”anytimeinconsoletogetthehelpdescription.

6. Start Web Management

ThefollowingshowshowtostartuptheWeb ManagementoftheXGSWManaged

Switch. Note the Managed Switch is congured through an Ethernet connection,

please make sure the manager PC must be set on the same IP subnet address.

For example, the default IP address of the XGSW Managed Switch is

192.168.0.100, then the manager PC should be set at 192.168.0.x (where x

is a number between 1 and 254, except 100), and the default subnet mask is

255.255.255.0.

PC / Workstation

with

IE Browser

RJ-45/UTP-Cable

IP Address:

192.168.0.x

IP Address:

192.168.0.100

XGSW Managed Switch

Figure 6-1 IP Management Diagram

1.Use Internet Explorer 7.0 or above Web browser, enter IP address

http://192.168.0.100 (the factory-default IP address or that you have just

changedinconsole)toaccesstheWebinterface.

2.When the following dialog box appears, please enter the default username and

password “admin” (or the password you have changed via console). The login

screeninFigure6-2appears.

DefaultUsername:admin

DefaultPassword:admin

Figure 6-2 Login screen

3.Afterenteringthepassword,themainscreenappearsasFigure6-3.

Figure 6-3 Web Main Screen of XGSW Managed Switch
