Planet GSW-1601 Manual de usuario

10/100/1000Mbps

Gigabit Ethernet Switch

GSW-2401/GSW-1601

User's Manual

Trademarks

Content subjects to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp.

All other trademarks belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will

work properly in all environments and applications, and makes

no warranty and representation, either implied or expressed,

with respect to the quality, performance, merchantability, or

fitness for a particular purpose.

PLANET has made every effort to ensure that this User's

Manual is accurate; PLANET disclaims liability for any

inaccuracies or omissions that may have occurred.

Information in this User's Manual is subject to change without

notice and does not represent a commitment on the part of

PLANET. PLANET assumes no responsibility for any

inaccuracies that may be contained in this User's Manual.

PLANET makes no commitment to update or keep current the

information in this User's Manual, and reserves the right to

make improvements to this User's Manual and/or to the

products described in this User's Manual, at any time without

notice.

If you find information in this manual that is incorrect, misleading,

or incomplete, we would appreciate your comments and

suggestions.

FCC Warning

This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the Instruction manual,

may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be

required to correct the interference at its own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this

product may cause radio interference, in which case the user

may be required to take adequate measures.

Revision

PLANET Gigabit Ethernet Switch User's Manual

FOR MODELS: GSW-2401/GSW1601

Rev: 1.0(May.2005)

Part No.: 2010-A50140-000

1. INTRODUCTION

1.1 Package Contents

Check the contents of your package for following parts:

。 Gigabit Ethernet Switch x 1

。 User's manual x 1

。 Power cord x 1

。 Rack ear x 2

。 Screws x 6

。 Rubber feet x 4

If any of these are missing or damaged, please contact your dealer

immediately, if possible, retain the carton including the original

packing material, and use them against to repack the product in case

there is a need to return it to us for repair.

1.2 How to Use This Manual

This Gigabit Ethernet Switch User Manual is structured as

follows:

Chapter 2 Installation

The chapter explains the feature, functionality and the physical

installation of the Switch.

Chapter 3 Switch operation

The chapter explains the Gigabit Ethernet Switch transmit operation.

Chapter 4 Troubleshooting

The chapter explains the troubleshooting of the Gigabit Ethernet

Switch.

Appendix A

This chapter contains cable information of the Gigabit Ethernet

Switch.

1.3 Product Features

。 Complies with IEEE802.3, 10Base-T, IEEE802.3u

100Base-TX, IEEE802.3ab 1000Base-T

。 16/24-Port 10/100/1000Mbps Gigabit Ethernet ports

。 Features Store-and-Forward mode with wire-speed filtering

and forwarding rates

。 Hardware based 10/100Mbps, half/full duplex and 1000Mbps

full duplex mode, flow control and auto-negotiation

。 IEEE802.3x flow control for full duplex operation and

Backpressure for half duplex operation

。 Integrated address look-up engine, support 8K absolute MAC

addresses

。 Provide 272/400KB buffer memory

。 9K Jumbo packet support

。 Automatic address learning and address aging

。 Supports Auto MDI/MDI-X function

。 Support CSMA/CD protocol

。 100~240VAC, 3.0A, 50~60Hz universal Power input

。 FCC, CE class A compliant

1.4 Product Specifications

Model GSW-2401 GSW-1601

Hardware Specification

Network Ports 24 10/100/1000Base-T

RJ-45 MDI/MDI-X ports

16 10/100/1000Base-T

RJ-45 MDI/MDI-X ports

Dimensions (W x H x D) 440 x 44 x 120 mm

Weight (KG) 1.75 KG 1.6 KG

Power Requirement 100~240 VAC, 3.0A, 50-60 Hz

Switch Specification

Switch Architecture Store-and-forward

Address Table 8K entries, auto learning/ageing

Shared Data Buffer 400KB 272KB

Flow Control IEEE 802.3x full duplex operating and flow control

Packet Control Runt & CRC filtering, Broadcast storm control

Switch Fabric 48Gbps 16Gbps

Switch Throughput 35.7Mbps 23.8Mbps

Standard Conformance

Network Standards IEEE 802.3 (Ethernet), IEEE 802.3u (Fast Ethernet)

IEEE 802.3ab and IEEE802.3x (flow control)

Operation Temperature 0~50ºC

10% to 90% (Non-condensing)

Humidity -40~70ºC

Regulation Compliance FCC, CE

2. INSTALLATION

This section describes the functionalities of the Gigabit Ethernet

Switch’s components and guides how to install it on the desktop.

Basic knowledge of networking is assumed. Please read this chapter

completely before continuing.

2.1 Product Description

The PLANET GSW-2401/GSW-1601 is 10/100/1000Mbps Gigabit

Ethernet switch with 24/16 ports respectively, and non-blocking

wire-speed performance. With a 48/32Gbps internal switching fabric,

the GSW-2401/GSW-1601 can handle extremely large amounts of

data in a secure topology linking to a backbone or high capacity

servers. The GSW-2401/GSW-1601 has 8K MAC Address table and

provides 400KB/272KB buffer memory. The GSW-2401/

GSW-1601offers wire-speed packets transfer performance without

risk of packet loss. The high data throughput of

GSW-2401/GSW-1601 makes it ideal for most Gigabit environments,

especially while network upgrades to a Gigabit environment.

All RJ-45 copper interfaces support 10/100/1000Mbps

Auto-Negotiation for optimal speed detection through RJ-45 Category

6, 5 or 5e cables. Support is standard for Auto-MDI/MDI-X that can

detect the type of connection to any Ethernet device without requiring

special straight or crossover cables.

The Flow Control function allows your Gigabit switch supported

routers and servers to directly connect to this switch for fast, reliable

data transfer.

2.1.1 Product Overview

The PLANET GSW-2401 and GSW-1601 are Gigabit Ethernet

switches with 24/16 RJ-45 10/100/1000 Mbps ports for high-speed

network connectivity. The switches can also automatically identify and

determine the correct transmission speed and half/full duplex mode of

the attached devices with its 24/16 ports. The Gigabit port with jumbo

frame feature supported, can handle extremely large amounts of data

transmission in a secure topology linking to a backbone or high-power

servers.

This product also supports store-and-forward forwarding scheme to

ensure low latency and high data integrity, eliminates unnecessary

traffic and relieves congestion on critical network paths. With an

intelligent address recognition algorithm, the switches could recognize

up to 8K different MAC address and enables filtering and forwarding at

full wire speed.

2.1.2 Switch Front Panel

Figure 2-1 & 2-2 shows a front panel of GSW-2401/GSW-1601

Figure 2-1 GSW-2401 front panel

2.1.3 LED Indicators

Figure 2-2 GSW-1601 front panel

LED Color Function

PWR Green Lights to indicate that powered on.the Switch is

GSW-2401

LNK/ACT

1000

100

24-Port 10/100/1000

Gigabit Ethernet Switch

GSW-1601

LNK/ACT

1000

100

1000

LNK/ACT

16-Port Gigabit Ethernet Switch

LNK/ACT Green Lights to indicate the link through that port is

successfully established.

Blinks to indicate that the switch is actively sending or

receiving data over that port.

1000 Green

Lights to indicate that the port is operating at

1000Mbps.

100 Green

Lights to indicate that the port is operating at 100Mbps.

2.1.4 Switch Rear Panel

Figure 2-3 & 2-4 shows a rear panel of GSW-2401/GSW-1601.

100 ~ 240V AC

50/60 Hz

Figure 2-3 GSW-2401 front panel

100 ~ 240V AC

50/60 Hz

Figure 2-4 GSW-1601 front panel

Power Notice:

1. The device is a power-required device, it means, it will not work

till it is powered. If your networks should active all the time, please

consider using UPS (Uninterrupted Power Supply) for your device.

It will prevent you from network data loss or network downtime.

2. In some area, installing a surge suppression device may also

help to protect your switch from being damaged by unregulated

surge or current to the Switch or the power adapter.

2.2 Installing the Switch

This part describes how to install your Gigabit Ethernet Switch and

make connections to it. Please read the following topics and perform

the procedures in the order being presented.

Note: This switch does not need software configuration.

2.2.1 Desktop Installation

To install the switch on desktop, simply follow the next steps:

Step1: Attach the rubber feet to the recessed areas on the bottom of

the switch.

Step2: Place the switch on desktop near an AC power source.

Step3: Keep enough ventilation space between the switch and the

surrounding objects.

Note: When choosing a location, please keep in mind the

environmental restrictions discussed in Chapter 1, Section 1.4

Product Specification.

Step4: Connect your switch to network devices.

A. Connect one end of a standard network cable to the

10/100/1000 RJ-45 ports on the Back of the switch.

B. Connect the other end of the cable to the network devices such

as printer servers, workstations or routers…etc.

Note: Connection to the switch requires UTP Category 5 network

cabling with RJ-45 tips. For more information, please see the Cabling

Specification in Appendix A.

Step5: Supply power to the switch.

A. Connect one end of the power cable to the switch.

B. Connect the power plug of the power cable to a standard wall

outlet.

When the switch receives power, the Power LED should remain solid

Green.

Otros manuales para GSW-1601

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Planet

Planet

Planet FSD-504HP Manual de usuario

Planet

Planet Switch Manual de usuario

Planet

Planet IGS-5225 Series Manual de usuario

Planet

Planet WH-2400M Manual de usuario

Planet

Planet XGS3-24042 Manual de usuario

Planet

Planet FSD-808HP Manual de usuario

Planet

Planet GS-5220-8P2T2S Manual de usuario

Planet

Planet NOVASwitch GSW-1200S Manual de usuario

Planet

Planet POE-1200G Manual de usuario

Planet

Planet GSD-800S Manual de usuario

Planet

Planet TSN-6325-8T4S4X Manual de usuario

Planet

Planet SGS-6341-24T4X Manual de usuario

Planet

Planet IFGS-1022HPT Manual de usuario

Planet

Planet KVM-800 Manual de usuario

Planet

Planet FSD-1008HP Manual de usuario

Planet

Planet GSW-1402S Manual de usuario

Planet

Planet FNSW-2402 Manual de usuario

Planet

Planet IPM-8221 Manual de usuario

Planet

Planet NOVA100 Series Manual de usuario

Planet

Planet FSD-604HP Manual de usuario

Planet

Planet FNSW-4800 Manual de usuario

Planet

Planet GS-6320 Series Manual de usuario

Planet

Planet KVM-210 Series Manual de usuario

Planet

Planet GSD-Series Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
