DIGITAL I/O MODULE 20-410

pickering

Issue 4.1 July 2019

User Manual

GPIB Digital Input/Output Module

(Model No. 20-410)

pickeringtest.com pickering

SYSTEM 10/20

*Please contact Pickering for alternative

PXI/LXI/USB solutions

Page (II) DIGITAL I/O MODULE 20-410

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

DIGITAL I/O MODULE 20-410

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) DIGITAL I/O MODULE 20-410

pickering

Page (IV) GENERAL PURPOSE REED RELAY MODULE 10-110/115/120/125

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

DIGITAL I/O MODULE 20-410

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre-Operation Checks...........................................................3.1

Hardware Installation ............................................................3.1

Software Installation .............................................................3.3

Self-Test..................................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming the Module .....................................................4.1

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting.........................................................................6.1

Section 7

Maintenance Information............................................................7.1

PCB and Component Layout................................................7.2

CONTENTS

Please use the hyperlinked text to navigate to the page required

Page (VI) DIGITAL I/O MODULE 20-410

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

DIGITAL I/O MODULE 20-410

pickering

Page (VII)

GENERAL PURPOSE REED RELAY MODULE 10-110/115/120/125

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

This product is not specically designed for use in hazardous environments, for example in explosive

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the System 10/20 chassis are populated with blanking plates to prevent access

to user I/O signals that may be present. Blanking panels are available to order from Pickering in a

variety of slot widths. If the product is not used in this manner for example by using an extender card

then additional care must be taken to avoid contact with exposed signals.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in

anti-static bags.

CAUTION - PRODUCT DOCUMENTATION SYMBOL

Suitably qualied & trained users should ensure that the accompanying documentation is fully read

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

Page (VIII) DIGITAL I/O MODULE 20-410

pickering

THIS PAGE INTENTIONALLY BLANK

Page 1.1

DIGITAL I/O MODULE 20-410

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

GPIB Digital Input/Output Module 20-410

ISSUE 5.2 JUL 2019

• Up to 128-Bits of Digital Input and Output in

One Module

• TTL Compatible Digital Inputs

• Choice of TTL or Open-Collector Digital

Outputs

• Open-Collector Outputs Suitable For Driving

Relay Coils.

• Programmable by Bit Byte or Word

• Front Panel Status Indicators

• Built-in Self Test

20-410 Digital Input/Output Module

DIGITAL

OUTPUTS

DIGITAL

INPUTS

SYSTEM 20 BACKPLANE

Diagram for the 20-410-041 Digital Input/Output

Module With 64-Bits of I/O

The 20-410 Digital Input/Output Modules offer a choice of port

congurations up to a maximum of 128-bits. Modules can be

specied as all inputs, all outputs or a combination of both.

All inputs are compatible with TTL voltage levels and are suitable

for receiving signals from logic circuits or sensors with TTL level

outputs. Outputs can be specied as either TTL, suitable for driving

standard logic, or Open-Collector, for driving higher current loads

such as relay coils. The Open-Collector option can tolerate up to

50V and sink up to 500mA of current.

The module is programmed by writing and reading data at bit, byte

or word level, this simplies the interfacing operation. Applications

include; generating control signals, stimulus and sensing status

from digital devices.

Typical Applications

• Construction of special one-off circuits

• Programmable ampliers

• Programmable attenuators

• Programmable lters

• Special circuits to drive external relays

• Mounting special relay types

• Dummy multiplexer channels for calibration purposes

*Please contact Pickering for alternative

PXI/LXI/USB solutions

Page 1.2 DIGITAL I/O MODULE 20-410

pickering

SECTION 1 - TECHNICAL SPECIFICATION

Digital Input/Output Module – 20-410

pickeringtest.com

Speciﬁcations

Speciﬁcation - TTL Output Drivers

Maximum drive capability: 15 TTL inputs.

Current drive Sink: 10mA max

Current Source: 0.4mA max

Max Voltage: 7V

Total Operate/Release Time: 7ms

Safety & CE Compliance

All modules are fully CE compliant and meet applicable EU

directives: Low-voltage safety EN61010-1:2010, EMC Immunity

EN61326-1:2013, Emissions EN55011:2009+A1:2010.

Operating/Storage Conditions

Operating Conditions

Operating Temperature:

Humidity:

Altitude:

0°C to +55°C

Up to 95% non-condensing

5000m

Storage and Transport Conditions

Storage Temperature:

Humidity:

Altitude:

-20°C to +75°C

Up to 95% non-condensing

15000m

Speciﬁcation - Open Collector Transistor Drivers

Maximum Standoff Voltage: 50V

Power per O/P: 1.0W max

Power per byte: 1.6W max

Current Drive: 500mA max.

Total Operate/Release Time: 7ms

Speciﬁcation - Digital Inputs

Maximum Standoff Voltage: 7V

Input Current: Iih = 20mA, Iil = -0.4mA

Pull up resistor: 10kΩpulled up to 5V

Nominal True voltage: >2.0V

Nominal false voltage: <0.8V

Programming

The module uses a standard IEEE-488.2/RS-232 message based

interface and is programmed via the System 20 backplane. The I/O

ports are programmable by bit, byte or word.

Self Test

The module has a built in self-test that is executed at power on or

invoked by a software command. The test checks internal logic,

checks power supply levels and tests the output drivers. The result

of the test is indicated on the front panel LEDs.

Mechanical Characteristics

All modules conform to the 6U height (128mm) Eurocard standard

and are 160mm deep. Panel width for all versions is 2.4 Inches.

Connectors

• System 20 bus: 64-Pin DIN 41612 plug

• Digital input/output: 2 x 64-Pin DIN 41612 plugs on

front panel (20-410)

Note: Alternative connectors are available to order, please contact

the sales ofce for details.

Otros manuales para SYSTEM 10

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unidad de control de Pickering

Pickering

Pickering PXI BRIC 40-595A Manual de usuario

Pickering

Pickering PXI 60-104 Manual de usuario

Pickering

Pickering 40-280 Manual de usuario

Pickering

Pickering PXI 40-855 Manual de usuario

Pickering

Pickering 40-587B Manual de usuario

Pickering

Pickering PXI 30 A Manual de usuario

Pickering

Pickering 40-545 Manual de usuario

Pickering

Pickering 40-582A Manual de usuario

Pickering

Pickering PXI 40-795-001 Manual de usuario

Pickering

Pickering 40-559 Manual de usuario

Pickering

Pickering 40-870 Manual de usuario

Pickering

Pickering 40-582 Manual de usuario

Pickering

Pickering 40-670A Manual de usuario

Pickering

Pickering PXI 40-145 Manual de usuario

Pickering

Pickering 40-567A Manual de usuario

Pickering

Pickering PXi 41-720 Manual de usuario

Pickering

Pickering PXI BRIC 40-569 Manual de usuario

Pickering

Pickering 40-262 Manual de usuario

Pickering

Pickering 40-670A Manual de usuario

Pickering

Pickering PXI BRIC 40-569B Manual de usuario

Pickering

Pickering Pxi 41-182A Manual de usuario

Pickering

Pickering 40-561A Manual de usuario

Pickering

Pickering 40-884 Manual de usuario

Pickering

Pickering PXI 40-710 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
