Issue 9.3 March 2021

40-290/291 User Manual

PXI Programmable Resistor Module

Page (II) PROGRAMMABLE RESISTOR MODULES 40-290/291

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

PROGRAMMABLE RESISTOR MODULES 40-290/291

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) PROGRAMMABLE RESISTOR MODULES 40-290/291

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

PROGRAMMABLE RESISTOR MODULES 40-290/291

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI Modules ............4.1

Module Architecture 40-290-021 .........................................4.2

Module Architecture 40-290-121 .........................................4.3

Module Architecture 40-291-021 .........................................4.4

Module Architecture 40-291-121 .........................................4.5

Programming The Module ....................................................4.6

Section 5

Connector Information................................................................5.1

40-290 ...................................................................................5.1

40-291 ...................................................................................5.2

Section 6

Trouble Shooting.........................................................................6.1

Section 7

Maintenance Information............................................................7.1

Calibration .............................................................................7.2

Relay Lookup Table 40-290-021 ..........................................7.6

Relay Lookup Table 40-290-121 ..........................................7.7

Relay Lookup Table 40-291-021 ..........................................7.8

Relay Lookup Table 40-291-121 ..........................................7.9

CONTENTS

Page (VI) PROGRAMMABLE RESISTOR MODULES 40-290/291

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

PROGRAMMABLE RESISTOR MODULES 40-290/291

pickering

Page (VII)

2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

This product is not specically designed for use in hazardous environments, for example in explosive

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the host chassis are populated with blanking plates to prevent access to user I/O

signals that may be present. Blanking panels are available to order from Pickering in a variety of

slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

Not to be used in safety critical circuits, refer to the Pickering Interfaces’ terms & conditions of sale.

This module must not be used for the switching of Mains Circuits. For the switching of voltages up

to the module’s full specication, Secondary Circuit power supplies and the Device Under Test must

be fully isolated from the Mains Circuit and the safety earth.

The host chassis must be correctly installed and be connected to mains or factory safety ground,

please refer to your chassis installation manual.

Diagram Showing Separation Between The Mains Circuit and Secondary Circuit / DUT

For the purposes of this document, a Mains Circuit is an installation classied as Overvoltage

Category II up to 300V. Separation between the Secondary Circuit and Mains Circuit is achieved

by a transformer in which the primary windings are separated from the secondary windings by

reinforced insulation, double insulation, or a screen connected to the protective conductor terminal.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in

anti-static bags.

PXI Switching

Module

Device

Under Test

Power

Supply

Power

Supply

Host Chassis

Secondary Circuit

Mains

Circuit

Mains

Circuit

Mains/Factory

Safety Ground

Page (VIII) PROGRAMMABLE RESISTOR MODULES 40-290/291

pickering

Page (VIII) 2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579

pickering

CAUTION - PRODUCT DOCUMENTATION SYMBOL

Suitably qualied & trained users should ensure that the accompanying documentation is fully read

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page 1.1

PROGRAMMABLE RESISTOR MODULES 40-290/291

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI Programmable Resistor Module 40-290/291

ISSUE 9.1 MAR 2021

yDual 16-Bit or Quad 8-Bit Resolution Resistor Module

yProgrammable From 0 Ω to 32767.5 Ω in 0.5 Ω Steps

yBuilt-In Non-Volatile Parametric Memory For

Calibration Data

yOption To Include 16 SPDT Reed Relays

yUses High Reliability Pickering Reed Relays For

Maximum Performance

yOver 1000 Value Changes Per Second

ySpecial Versions Built To Order

yVISA, IVI & Kernel Drivers Supplied for Windows

ySupported by PXI or LXI Chassis

y3 Year Warranty

The 40-290 Programmable Resistor Module comprises a dual

16-bit resistor chain together with 16 optional SPDT Reed

Relays (see diagram below). The 40-291 is conﬁgured as a quad

8-bit programmable resistor chain also with the option of 16

SPDT relays. Connections are made via a front panel 68-pin

male connector.

Programmable resistors may be connected together either

in series or in parallel to form many types of conﬁguration.

For example potentiometers (2 resistors in series) and more

accurate resistors (connecting in parallel). Each programmable

resistor has a position for a user inserted offset value.

The 40-290 and 40-291 use Ruthenium Reed Relays for

maximum switching accuracy and operating life.

To give maximum accuracy each resistor chain has on-board

E2PROM, this allows accurate calibration data to be recorded for

each resistor in the chain.

If versions are required with different resistor ranges than those

shown, please contact the Sales Ofﬁce for assistance.

Programmable Resistor Module Conﬁgured In Dual 16-Bit Resistor Mode With 16 x SPDT Reed Relays

Resistor

Chain 1

Relays may be connected

to the resistors using

internal wire jumpers

Resistor

Chain 2

16 x SPDT

Reed Relays

R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 R12 R13 R14 R15 R16R off

SW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8

SW9 SW10 SW11 SW12 SW13 SW14 SW15 SW16

16 Bit 8 Bit

16 Bit

8 Bit

Programmable Resistor Module Overview

Individual

Resistor

Chains

Example

Series

Connection

40-290 40-291

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unidad de control de Pickering

Pickering

Pickering Pxi 41-660 Manual de usuario

Pickering

Pickering 40-520 Manual de usuario

Pickering

Pickering 4 785C Series Manual de usuario

Pickering

Pickering 40-297A Manual de usuario

Pickering

Pickering 40-540 Manual de usuario

Pickering

Pickering PXI 40-710 Manual de usuario

Pickering

Pickering 40-618A Manual de usuario

Pickering

Pickering PXI 40-787 Manual de usuario

Pickering

Pickering PXI 40-145 Manual de usuario

Pickering

Pickering PXI BRIC 40-595A Manual de usuario

Pickering

Pickering 4x-585A Manual de usuario

Pickering

Pickering PXI 40-597 Manual de usuario

Pickering

Pickering 40-252 Manual de usuario

Pickering

Pickering 40-522 Manual de usuario

Pickering

Pickering PXI BRIC 40-569 Manual de usuario

Pickering

Pickering 45-541 Manual de usuario

Pickering

Pickering PXI BRIC 40-562A Manual de usuario

Pickering

Pickering PXI BRIC 40-560A Manual de usuario

Pickering

Pickering 40-587B Manual de usuario

Pickering

Pickering 40-785C Manual de usuario

Pickering

Pickering 40-592A Manual de usuario

Pickering

Pickering SYSTEM 10 Manual de usuario

Pickering

Pickering SYSTEM 10 Manual de usuario

Pickering

Pickering 40-500 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
