Philips FC8919 Manual de usuario
FC8919
2
3
2
30
1
3
4
5
6
7
8
9
10 11
20
18
21
19
27
26
28
29
31
32
33
34
17
16
25
15
13
14
23
22
24
12
1
4
6
18
30
42
54
66
78
90
102
114
126
138
150
6
Congratulations on your purchase and welcome to Philips! To fully benet
from the support that Philips offers, register your product at www.philips.
com/welcome.
1 Cover
2 Cover release tab
3 Motor protection lter
4 Dustbag holder
5 Dustbag
6 Hose connection opening
7 Dustbag-full indicator
8 Top handle
9 Suction power selection wheel
10 On/off button
11 Cord rewind button
12 Ergonomic ComfortControl handgrip
13 Tube release button
14 Accessory holder release levers
15 Accessory holder
16 Hose
17 Flexible hose connection
18 Hard-oor nozzle
19 Combination nozzle
20 Parking/storage ridge
21 Rocker switch for carpet/hard oor settings
22 Small nozzle
23 Brush attachment
24 Crevice tool
25 Telescopic tube
26 Filter grille
27 Washable HEPA 12 lter
28 Parking slot
29 Mains cord with plug
30 Handgrip
31 Swivel wheel
32 Storage slot
33 Type plate
34 Rear wheels
Read this user manual carefully before you use the appliance and save it for
future reference.
- Never suck up water or any other liquid. Never suck up ammable
substances and do not suck up ashes until they are cold.
- Check if the voltage indicated on the appliance corresponds to the
local mains voltage before you connect the appliance.
- Do not use the appliance if the plug, the mains cord or the appliance
itself is damaged.
- If the mains cord is damaged, you must have it replaced by Philips, a
service centre authorised by Philips or similarly qualied persons in
order to avoid a hazard.
- This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
- Children should be supervised to ensure that they do not play with the
appliance.
- Do not point the hose, the tube or any other accessory at the eyes
or ears nor put it in your mouth when it is connected to the vacuum
cleaner and the vacuum cleaner is switched on.
- When you use the vacuum cleaner to vacuum ashes, ne sand, lime,
cement dust and similar substances, the pores of the dustbag become
clogged. As a result, the dustbag-full indicator will indicate that the
dustbag is full. Replace the dustbag, even if it is not full yet (see chapter
‘Replacing the dustbag’).
- Never use the appliance without the motor protection lter. This could
damage the motor and shorten the life of the appliance.
- Only use Philips s-bag ® synthetic dustbags.
- Noise level: Lc = 80 dB [A]
This Philips appliance complies with all standards regarding electromagnetic
elds (EMF). If handled properly and according to the instructions in this
user manual, the appliance is safe to use based on scientic evidence
available today.
1 Take the appliance and its accessories out of the box.
2 Remove any sticker, protective foil or plastic from the appliance.
- The unique ComfortControl handgrip is ergonomically designed to
give you sufcient comfort during vacuum cleaning.
7
- To gain optimal benet from this handgrip, it is important that you do
not position your second hand on the tube. When you do so, you twist
and bend your back, which could result in back problems.
1 To connect the hose, push it rmly into the appliance (‘click’). Make
sure the recess in the hose connection opening ts exactly on the
projection on the housing of the appliance.
2 To disconnect the hose, press the buttons (1) and pull the hose out
of the appliance (2).
1 Attach the tube to the ComfortControl handgrip (‘click’).
8
2 To disconnect the tube from the ComfortControl handgrip, hold the
handgrip with one hand. With the other hand, press the tube release
button (1) on the telescopic tube and pull the tube off the handgrip
(2).
Note: This vacuum cleaner has been tted with holes at the end of the bend.
These holes may prevent objects from getting stuck or damaged when you use
your vacuum cleaner without the tube or accessories supplied.
3 Adjust the length of the telescopic tube in such a way that the
exible hose connection is at hip level.
4 Hold the tube at an angle of 45° to the oor.
1 To connect one of the nozzles to the tube, press the spring-loaded
lock button on the tube and insert the tube into the nozzle. Fit the
spring-loaded lock button into the opening in the nozzle (‘click’).
2 To disconnect the nozzle from the tube, press the spring-loaded lock
button on the tube and pull the tube out of the nozzle.
The combination nozzle can be used on either carpets or hard oors.
1 To clean hard oors, push the rocker switch on top of the nozzle
with your foot.
,The brush strip for cleaning hard oors comes out of the nozzle
housing.
45°
9
2 To clean carpets, push the rocker switch again.
,The brush strip disappears into the nozzle housing.
- The hard-oor nozzle is designed for gentle cleaning of hard oors.
1 To connect crevice tool (1) or small nozzle (2) to the tube, press the
spring-loaded lock button on the tube and insert the tube into the
crevice tool or small nozzle. Fit the spring-loaded lock button into
the opening in the crevice tool or small nozzle (‘click’).
Note: You can also attach the crevice tool and the small nozzle directly to the
ComfortControl handgrip.
2 To disconnect the crevice tool or small nozzle, press the spring-
loaded lock button on the tube and pull crevice tool or small nozzle
off the tube or ComfortControl handgrip.
1 To assemble the brush attachment, slide it onto the bottom of the
small nozzle (‘click’).
2 To disassemble the brush attachment, slide it off the bottom of the
small nozzle.
10
