Philips SLV5400 Manual de usuario

Wireless TV Link

User Manual

SLV5400

G2525

2525

WIRELESS TV LINK RECEIVER

12131415

3 5 64

Contents

Page

Overview 4

Control and display elements 4

Your Wireless TV Link 5

Safety 5

Installation 6

Operation 7

Enjoy your Wireless TV Link 7

Use additional features 9

Troubleshooting 10

Information 12

Health and safety 12

Maintenance and service 12

Recycling and disposal 12

Warranty 13

Glossary 13

EN Overview

Control and display elements

A Transmitter

1 On/off switch

2 Power light:

> red: standby

> green: on

> blinking: remote control signalling

3 RECORD SOURCE button

4 Link source indication lights

5 TV1 SOURCE button

6 AUTO light

7 Integrated remote control blaster light

8 TV1 source indication display

9 Antenna

10 SCART ports:

> 1-SAT/STB

> 2-AUX

> 3-DVD (for RGB signals)

> 4-VCR/DVD recorder (for RGB signals)

11 Wireless channel selection switch

12 Power input connector (DC 12V)

13 AUDIO OUT connectors (red/white)

14 SCART port for TV1

15 Remote control blaster cord port

B Receiver

16 On/off switch

17 Power light

> red: standby

> green: on

> blinking: remote control signalling

18 Source selector buttons (+/-)

19 Integrated remote control blaster light

20 Antenna

21 Wireless channel selection switch

22 SCART port for TV2

23 Power input connector (DC 12V)

C Remote control

G Remote control blaster cord

24 Connector

25 Blaster light

Your Wireless TV Link

You can say good-bye to wires. With your Wireless TV

Link you can now wirelessly connect a second TV and

choose between four devices to watch on your second

TV.

Safety

• Read the instructions in this manual carefully before

you connect, install and use the product.

• Keep this manual for future reference.

• The product is for indoor use only.

• Do not use the product close to water.

• Do not expose the product to extreme heat.

• In case of technical difficulties, do not open the

product. Bring it to your Philips dealer.

• Do not cover the product.

• Connect the power adapters only to a

220-240 V AC/50 Hz power supply.

• The product can cause interference to other

equipment. Check if any equipment near the product

can be affected before you start using it.

EN Installation

Install the remote control blaster cord

1 Switch off the transmitter (A).

2 Connect the remote control blaster cord (G) to the

IR port.

3 Position the blaster light in front of the video source.

4 Switch on the transmitter (A).

5 Take the remote control of a video source with you.

6 Go to TV2.

7 Switch on TV2.

8 Switch on the receiver (B).

9 Select the correct SCART input on TV2.

10 Operate the video source with its remote control.

11 If necessary, repeat the steps 3 to 10 for the other

video sources.

For basic installation, see

the quick start guide that

came with your Wireless

TV Link.

STANDBY SELECT

SLV5400WIRELESS TV LINK TRANSMITTER

See the user manual of the video source

for the exact location of the IR sensor

on the front panel.

STANDBY SELECT

SLV5400WIRELESS TV LINK TRANSMITTER

WIRELESS TV LINK RECEIVER

Installation

Remove interference on TV2

1 Find the CHANNEL switch on the transmitter (A).

2 Set the CHANNEL switch to different number.

3 Find the CHANNEL switch on the receiver (B).

4 Set the CHANNEL switch to the same number as

on the transmitter.

Operation

Enjoy your Wireless TV Link

Watch a cable TV program on TV2

1 Switch on the transmitter (A).

2 Switch on the VCR or DVD recorder.

3 Take the remote control of the VCR or DVD

recorder with you.

4 Go to TV2.

5 Switch on TV2.

6 Switch on the receiver (B).

Channel

DC 12V

1 2 3 4

CHANNEL

For basic operation, see

the quick start guide that

came with your Wireless

TV Link.

Your VCR or DVD recorder needs to

be connected to the transmitter (A) of

the Wireless TV Link and connected to

the Cable-TV signal.

STANDBY SELECT

SLV5400WIRELESS TV LINK TRANSMITTER

WIRELESS TV LINK RECEIVER

EN Operation

7 Press +or -on the receiver (B) to select the VCR or

DVD recorder;

or: press 4on the remote control (C).

8 Select the channel on the VCR or DVD recorder

with its remote control.

Watch a video source on TV1

Either: automatic

Operate TV1 and the video source as usual.

Or: manual

1 Switch on the transmitter (A).

2 Switch on TV1.

3 Select the correct SCART input on TV1.

4 Select the video source with TV1 SOURCE;

or: press +or -on the remote control (C).

5 Switch on the video source.

6 Operate the video source with its remote control.

Turn off the auto standby mode when

you use the VCR or DVD recorder to

watch a cable tv program. Refer to the

user manual of the VCR or DVD

recorder.

If the VCR or DVD recorder records a

television program, you watch the

recorded channel.

STANDBY SELECT

SLV5400WIRELESS TV LINK TRANSMITTER

TV1 SOURCE

Operation

Use additional features

Use VCR/DVD recorder features

1 Select a video source with SELECT.

> The signal of the video source is connected to the

VCR/DVD recorder.

2 Select the correct SCART input on the VCR or

DVD recorder.

3 Push RECORD on the VCR or DVD recorder.

4 Push PLAY on the video source.

> The VCR or DVD recorder now records the image of

the video source.

Sound through your audio amplifier

1 Take an audio cable (red and white plugs).

2 Plug the connectors of one end into the AUDIO

OUT connectors on the transmitter (A).

3 Plug the connectors of the other end into the

AUDIO IN connectors of your amplifier.

The making of unauthorised copies of copy-protected

material, including computer programmes, files,

broadcasts and sound recordings, may be an

infringement of copyrights and constitute a criminal

offence. This equipment should not be used for such

purposes.

SELECT SAT/STB

CONNECT 4-VCR/DVD RECORDER

AUX DVD PLAYER

123

TV1

AUDIO

OUT

Audio

Amplifier

Be responsible

Respect copyrights

EN Troubleshooting

Problem Tip

No image or wrong

image on TV1 •

Make sure video sources are

connected to the transmitter (A).

• Make sure the transmitter (A) is

connected to TV1.

• Make sure SCART cables are

firmly inserted.

• Make sure the video source is

switched on.

• Make sure the correct SCART

input on TV1 is selected.

• Select the correct video source

with TV1 source. See page 8.

No image or wrong

image on TV2 • Make sure SCART cables are

firmly inserted.

• Make sure the receiver (B) is

connected to TV2.

• Make sure both receiver (B) and

transmitter (A) are switched on.

• Make sure the video source is

switched on.

• Make sure the correct SCART

input on TV2 is selected.

• Select the correct video source

with +/- on the receiver (B).

• If the video source gives proper

image on TV1:

Make sure the video source gives

video signal in CVBS mode. See

its user manual

• Change the wireless channel that

is used for communication. See

page 7.

• The receiver (B) is out of range

of the transmitter (A). The num-

ber of walls and ceilings in

between the receiver (B) and

transmitter (A) restrict the dis-

tance.
