Philips GC8030/28 Manual de usuario

Intellicare

GC8030, GC7030

ENGLISH 6

NORSK 15

SVENSKA 24

 33

TÜRKÇE 43

GC8030, GC7030

Introduction

Thank you for buying the Intellicare, the new intelligent steam-ironing

system from Philips.

The iron offers non-stop ironing and also has a detachable water tank

that can be refilled at any moment.

The iron has a constant high steam output, which is a unique feature

for steam-ironing systems with unlimited autonomy.This gives you a

constant and fast ironing result.

General description

AShot-of-Steam button (GC8030 only)

BTemperature dial

CSteam activator

DTemperature pilot light

ESupply hose

FSoleplate

GIron stand

HPower on/off switch with pilot light

I'Water tank refill' indicator light

JSteam tank pilot light

KMains cord

LSteam tank

MCalc-Clean rinsing cap & plug

NCord storage facility for mains cord & supply hose

OFilling opening

PDetachable water tank

QWater tank release lever

RTransport handgrip

SCup

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗Check if the voltage indicated on the bottom of the steam tank

corresponds to the local mains voltage before you connect the

appliance.

◗Only connect the appliance to an earthed wall socket.

◗Do not use the appliance if the plug, the cord, the hose or the

appliance itself is damaged.

◗Regularly check if the mains cord and the supply hose are still

undamaged and safe.

◗If the mains cord is damaged, it must be replaced by Philips, a

service centre authorised by Philips or similarly qualified persons

in order to avoid a hazard.

ENGLISH6

◗Never leave the iron unattended when it is connected to the

mains.

◗Never immerse the iron or the steam tank in water.

◗Infirm persons should not be allowed to use the appliance

without supervision. Keep the appliance out of the reach of

children.

◗The iron stand and the soleplate of the iron can become

extremely hot and may cause burns if touched. If you want to

move the steam tank, do not touch the stand.

◗Always place the iron on the stand or on its heel. Do not put the

hot iron on the supply hose or the mains cord. Make sure that

mains cord and the supply hose do not come into contact with

the hot soleplate.

◗Do not put perfume, vinegar, starch, descaling agents, ironing aids

or other chemicals in the water tank.

◗Always place the appliance on a stable, level and horizontal

surface.

◗When you have finished ironing and even when you leave the iron

for a short while, unplug the iron and put it on the iron stand.

◗If steam escapes from the steam tank when the appliance is

heating up, switch the appliance off and tighten the Calc-Clean

rinsing plug. If steam continues to escape when the appliance is

heating up, switch the appliance off and contact a service centre

authorised by Philips.

◗Rinse the steam tank once a month or after every 10 times of use

to prevent damage to your iron.

◗Never remove the Calc-Clean rinsing cap and unscrew the Calc-

Clean rinsing plug when the steam tank is hot.

Before first use

BThe iron may give off some smoke when you use it for the first time.This

is normal and will stop after a short while.

BWhite particles may come out of the soleplate when you use the iron for

the first time.This is normal; the particles are harmless and will stop

coming out of the iron after a short while.

BWhen you switch the appliance on, the steam tank may produce a

pumping sound.This is normal; the sound tells you that water is being

pumped into the steam tank.

1Remove any sticker or protective foil from the soleplate and

clean the soleplate with a soft cloth.

C2Place the steam tank on a stable and level surface, i.e. on the

ironing board or on a table.

ENGLISH 7

Preparing for use

Filling the detachable water tank

If the tap water in your area is very hard, we advise you to mix the tap

water with an equal amount of demineralised water.

Do not put perfume, vinegar, starch, descaling agents, ironing aids, other

chemicals or 100 percent distilled water in the water tank.

C1Remove the detachable water tank from the steam tank.

2Fill the water tank with water up to the MAX indication.

3Slide the water tank back into the steam tank.

◗The water tank can be refilled at any time during use.

◗This appliance has a built-in water level sensor.When the

minimum level in the detachable water tank has been reached, the

'water tank refill' indicator light goes on.

Steam ironing will not be possible!

BNote:When you use the appliance for the first time or after Calc Clean,

a lot of water will be pumped from the detachable water tank into the

steam tank. Refill the water tank, if necessary.

Setting the temperature

1Check the garment label for the required ironing temperature

-1Synthetic fabrics ( e.g. acryl, viscose, polyamide) and silk

-2Wool

-3Cotton

- MAX Linen

C2Set the temperature dial to the required ironing temperature

by turning it to the appropriate temperature indication.

3Insert the plug into an earthed wall socket and set the on/off

switch to 'on'.

◗The steam tank and the iron will now start heating up.

The iron takes approx. 1 minute to heat up to 2and the steam tank

takes approx. 2.5 minutes to heat up.

C◗As soon as the steam tank has reached its maximum pressure

level and is ready for steam ironing, the steam tank pilot light goes

out.

ENGLISH8

Tips

- If the article consists of various kind of fibres, always select the

temperature required by the most delicate fibre, i.e. the lowest

temperature. If, for example, the fabric consists of 60% polyester and

40% cotton, it should be ironed at the temperature indicated for

polyester (2).

- If you do not know what kind of fabric(s) the article is made of,

determine the right ironing temperature by ironing a part that will

not be visible when you wear or use the article.

- Silk, woolen and synthetic materials: iron the reverse side of the

fabric to prevent shiny patches.

- Fabrics that tend to acquire shiny patches should be ironed in one

direction only (along with the nap) while applying very little pressure.

- Start ironing the articles that require the lowest ironing temperature,

i.e. those made of synthetic materials.

◗To make the iron cool down faster, simply apply steam or iron a

piece of cloth.

Using the appliance

Steam ironing

The supply hose may become hot during a long ironing session.

BThe system may occasionally produce a pumping sound during steam

ironing.This is normal and tells you that water is being pumped into the

steam tank.

1Make sure there is enough water in the water tank.

◗Steam ironing is only possible at higher ironing temperatures

(higher than 2).

C2Press the steam activator to start steam ironing.

◗During steam ironing, the 'steam tank heating up' pilot light goes

on from time to time to indicate that the steam tank is heating up

to maintain the right temperature and pressure.

◗The opening and closing of the steam valve in the steam tank will

cause a clicking sound.This is perfectly normal.

ENGLISH 9

Ironing without steam

1Start ironing without pressing the steam activator.

After ironing

C1Put the iron on the stand.

C2Switch the appliance off.

3Remove the mains plug from the wall socket and let the iron

cool down.

Features

Vertical steaming

Never direct the steam at people.

C◗You can steam iron hanging curtains and clothes (jackets, suits,

coats) by holding the iron in vertical position and pressing the

steam activator.

Shot of steam (GC8030 only)

A powerful shot of steam helps to remove stubborn creases.

1Set the temperature dial to a position between 3and

MAX.

C2Press both the steam activator and the shot of steam button.

ENGLISH10
