Philips Azur GC4340 Manual de usuario

Azur

GC4340, GC4330, GC4325, GC4320, GC4310

ENGLISH 4

УКРАЇНСЬКА 13

HRVATSKI 23

EESTI 33

LATVIEŠU 42

SLOVENŠČINA 51

БЪЛГАРСКИ 60

SRPSKI 70

GC4340, GC4330, GC4325, GC4320, GC4310

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗Check if the voltage indicated on the type plate corresponds to

the local mains voltage before you connect the appliance.

◗Only connect the appliance to an earthed wall socket.

◗Do not use the appliance if the plug, the cord or the appliance

itself shows visible damage, or if the appliance has been dropped

or is leaking.

◗Check the cord regularly for possible damage.

◗If the mains cord is damaged, it must be replaced by Philips, a

service centre authorised by Philips or similarly qualified persons

in order to avoid a hazard.

◗Never leave the appliance unattended when it is connected to the

mains.

◗Never immerse the iron and the stand, if provided, in water.

◗Keep the appliance out of the reach of children.

◗The soleplate of the iron can become extremely hot and may

cause burns if touched.

◗Do not allow the cord to come into contact with the soleplate

when it is hot.

◗When you have finished ironing, when you clean the appliance,

when you fill or empty the water tank and also when you leave

the iron even for a short while: set the steam control to position

0, put the iron on its heel and remove the mains plug from the

wall socket.

◗Always place and use the iron and the stand, if provided, on a

stable, level and horizontal surface.

◗Do not put perfume, vinegar, starch, descaling agents, ironing aids

or other chemicals in the water tank.

◗This appliance is intended for household use only.

Before first use

C1Remove the heat-resistant protective cover from the soleplate

(GC4340 only). Remove any sticker or protective foil from the

soleplate.

BThe iron may give off some smoke when you use it for the first time.This

will cease after a short while.

ENGLISH4

Preparing for use

Filling the water tank

Never immerse the iron in water.

1Make sure the appliance is unplugged.

C2Set the steam control to position 0 (= no steam).

3Open the cap of the filling opening.

4Tilt the iron backwards.

C5Fill the water tank with tap water up to the maximum level by

means of the filling cup.

Do not fill the tank beyond the MAX indication.

Do not put perfume, vinegar, starch, descaling agents, ironing aids or

other chemicals in the water tank.

◗If the tap water in your area is very hard, we advise you to mix it

with an equal portion of distilled water, or to use distilled water

only.

C6Close the cap of the filling opening ('click').

Setting the temperature

C1Type GC4340 only: remove the heat-resistant protective cover.

Do not leave the heat-resistant protective cover on the soleplate

during ironing.

2Put the iron on its heel.

ENGLISH 5

C3Set the required ironing temperature by turning the

temperature dial to the appropriate position.

Check the laundry care label for the required ironing temperature:

-1Synthetic fabrics (e.g. acrylic, nylon, polyamide, polyester)

-1Silk

-2Wool

-3Cotton, linen

If you do not know what kind or kinds of fabric an article is made of,

determine the right ironing temperature by ironing a part that will not

be visible when you wear or use the article.

Silk, woollen and synthetic materials: iron the reverse side of the fabric

to prevent shiny patches. Avoid using the spray function to prevent

stains.

Start ironing the articles that require the lowest ironing temperature,

such as those made of synthetic fibres.

4Put the mains plug in an earthed wall socket.

C5When the amber temperature light has gone out, wait a while

before you start ironing.

The temperature light will go on from time to time during ironing.

Using the appliance

Steam ironing

1Make sure that there is enough water in the water tank.

2Select the recommended ironing temperature (see chapter

'Preparing for use', section 'Setting the temperature').

C3Select the appropriate steam setting. Make sure that the steam

setting you select is suitable for the ironing temperature

selected:

- 1 - 3 for moderate steam (temperature settings 2to 3)

- 4 - 6 for strong steam (temperature settings 3to MAX)

BThe iron will start steaming as soon as the set temperature has been

reached.

ENGLISH6

LINEN

SILK

NYLON

WOOL

COTTON

MIN

MAX

Ironing without steam

C1Set the steam control to position 0 (= no steam).

2Select the recommended ironing temperature (see chapter

'Preparing for use', section 'Setting the temperature').

Features

Delicate fabric protector (GC4325 only)

The delicate fabric protector protects delicate fabrics from heat

damage and shiny patches.

With the delicate fabric protector you can iron delicate fabrics (silk,

wool and nylon) at temperature settings 3to MAX in combination

with all steam functions available on the iron.

The delicate fabric protector reduces the soleplate temperature

instantly, thus allowing you to iron delicate fabrics safely.

If you do not know what kind or kinds of fabric an article is made of,

determine the right ironing temperature by ironing a part that will not

be visible when you wear or use the article.

C1Put the iron on the delicate fabric protector ('click').

Spray function

You can use the spray function to remove stubborn creases at any

temperature.

1Make sure that there is enough water in the water tank.

C2Press the spray button several times to moisten the article to

be ironed.

Concentrated shot of steam from the special Steam Tip

A powerful shot of concentrated steam helps remove stubborn

creases.The forward-directed concentrated shot of steam enhances

the distribution of steam into every part of your garment.

The shot-of-steam function can only be used at temperature settings

between 2and MAX.

ENGLISH 7

C1Press and release the shot-of-steam button.

Vertical shot of steam

C1The shot-of-steam function can also be used when you hold

the iron in vertical position.

This is useful for removing creases from hanging clothes, curtains etc.

Never direct the steam at people.

Drip stop

This iron is equipped with a drip-stop function: the iron automatically

stops producing steam when the temperature is too low, to prevent

water from dripping out of the soleplate.When this happens you may

hear a sound.

Automatic anti-calc system

C1The built-in anti-calc system reduces the build-up of scale and

guarantees a longer life for the iron.

Electronic safety shut-off function (GC4325/4320 only)

C◗The electronic safety shut-off function automatically switches off

the iron if it has not been moved for a while.

◗The red auto-off light starts blinking to indicate that the iron has

been switched off by the safety shut-off function.

To let the iron heat up again:

- Pick up the iron or move it slightly.

- The red auto-off light goes out. If the temperature of the soleplate

has dropped below the set ironing temperature, the amber

temperature light goes on.

ENGLISH8

- If the temperature light goes on after you have moved the iron, wait

for it to go out before you start ironing.

- If the temperature light does not go on after you move the iron, the

soleplate still has the right temperature and the iron is ready for use.

Alert light and electronic safety shut-off function (GC4340

and GC4330)

The iron is equipped with a blue alert light.

C◗The blue alert light burns as long as the iron is plugged in.

◗The blue alert light starts blinking to indicate that the iron has

been switched off by the safety shut-off function.

To let the iron heat up again:

- Pick up the iron or move it slightly.

- The blue alert light stops blinking. If the temperature of the soleplate

has dropped below the set ironing temperature, the amber

temperature light goes on.

- If the temperature light goes on after you have moved the iron, wait

for it to go out before you start ironing.

- If the temperature light does not go on after you move the iron, the

soleplate still has the right temperature and the iron is ready for use.

Cleaning and maintenance

After ironing

1Remove the mains plug from the wall socket and let the iron

cool down.

2Wipe flakes and any other deposits off the soleplate with a

damp cloth and a non-abrasive (liquid) cleaning agent.

To keep the soleplate smooth, you should avoid hard contact with

metal objects. Never use a scouring pad, vinegar or other chemicals to

clean the soleplate.

3Clean the upper part of the iron with a damp cloth.

4Regularly rinse the water tank with water. Empty the water

tank after cleaning.

Calc-clean function

You can use the calc-clean function to remove scale and impurities.

◗Use the calc-clean function once every two weeks. If the water in

your area is very hard (i.e. when flakes come out of the soleplate

ENGLISH 9

during ironing), the calc-clean function should be used more

frequently.

1Make sure the appliance is unplugged.

2Set the steam control to position 0.

3Fill the water tank to the maximum level.

Do not put vinegar or other descaling agents in the water tank.

C4Select the maximum ironing temperature.

5Put the plug in an earthed wall socket.

6Unplug the iron when the amber temperature light has gone

out.

C7Hold the iron over the sink, press and hold the calc-clean

button and gently shake the iron to and fro.

Steam and boiling water will come out of the soleplate. Impurities and

flakes (if any) will be flushed out.

8Release the calc-clean button as soon as all the water in the

tank has been used up.

Repeat the calc-clean process if the iron still contains a lot of impurities.

After the calc-clean process

- Put the plug in the wall socket and let the iron heat up to allow the

soleplate to dry.

- Unplug the iron when it has reached the set ironing temperature.

- Move the hot iron gently over a piece of used cloth to remove any

water stains that may have formed on the soleplate.

- Let the iron cool down before you store it.

Storage

1Unplug the iron and set the steam control to position 0.

C2Empty the water tank.

ENGLISH10

LINEN

SILK

NYLON

WOOL

COTTON

MIN

MAX

Otros manuales para Azur GC4340

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Hierro de Philips

Philips

Philips GC9140 Manual de usuario

Philips

Philips GC4800 series Manual de usuario

Philips

Philips GC6320 Manual de usuario

Philips

Philips GC4430 Manual de usuario

Philips

Philips GC2980 Manual de usuario

Philips

Philips RI2560 Manual de usuario

Philips

Philips GC7630 Manual de usuario

Philips

Philips GC8560/02 Manual de usuario

Philips

Philips GC8700 series Manual de usuario

Philips

Philips GC6420 Manual de usuario

Philips

Philips GC4525/10 Manual de usuario

Philips

Philips HI 915 Manual de usuario

Philips

Philips GC8460 Manual de usuario

Philips

Philips HI5900 series Manual de usuario

Philips

Philips PerfectCare Elite Plus GC9680/80 Manual de usuario

Philips

Philips GC7330 Manual de usuario

Philips

Philips GC8700 series Manual de usuario

Philips

Philips EasyCare GC8340 Manual de usuario

Philips

Philips GC1903/21 Manual de usuario

Philips

Philips GC8420/02 Manual de usuario

Philips

Philips GC4500 series Manual de usuario

Philips

Philips GC4800 series Manual de usuario

Philips

Philips 3000 series Manual de usuario

Philips

Philips Mistral GC2105 Manual de usuario

Manuales populares de Hierro de otras marcas

Clatronic

Clatronic DB 3703 Manual de usuario

TEFAL

TEFAL FV4093Z0 Manual de usuario

Gorenje

Gorenje SIH 2200 BS Manual de usuario

Bosch

Bosch 2 Series Manual de usuario

Riffel

Riffel Catena KB-819 Manual de usuario

Texi

Texi Hestia Manual de usuario

Maxwell

Maxwell MW-3010 Manual de usuario

TREVIDEA

TREVIDEA Girmi ST60 Manual de usuario

Primula

Primula Vapormat Manual de usuario

Magio

Magio MG-541 Manual de usuario

Scarlett

Scarlett SC-1334S Manual de usuario

Bosch

Bosch Sensixx B22L Manual de usuario

Vitek

Vitek VT-1247 VT Manual de usuario

Cleanmaxx

Cleanmaxx 3397 Manual de usuario

dyras

dyras ESI-2400AC Manual de usuario

GE 169061 Manual de usuario

Gorenje

Gorenje SIH 2200 GC Manual de usuario

AEG

AEG DBS 5591 Manual de usuario
