Philips PowerLife GC2510 Manual de usuario

ServiceManual

Philips Consumer Lifestyle

Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification

Steam Iron PowerLife

GC2510

08/03

PRODUCT INFORMATION

Features

- Colour: Blue

- Non-stick soleplate

- Pointed tip soleplate

- Steam output: 30 g/min

- Steam boost: 90 g/min

- 3 steam level control

- Spray feature

- Tank capacity: 300 ml

- Cord length: 2 m

- 360 degrees ball swivel

- Filling door

- Calc clean feature

Safety Information

- This product meets the requirements regarding

interference suppression on radio and TV.

- After the product has been repaired, it should function

properly and has to meet the safety requirements and

legal regulations as officially laid down at this moment.

TECHNICAL INFORMATION

Voltage : 110 V, 220 - 240 V

Frequency : 50 - 60 Hz

Power : 1300 W, 1830 - 2150 W

Dimension (F-box) : 303 (L) x 120 (W) x 152 (H) mm

Product weight : 1.2 kg

Water Advice

Suitable for tap water use. Advice to mix with equal portion

of distilled water or use only distilled water if the tap water is

very hard.

Non-stick Soleplate

3 layer coating silver soleplate. This soleplate glides smoothly,

is non-stick & easy to clean.

Pointed Tip

This feature allows soleplate to reach tricky area.

Steam Boost

The steam boost of 90 g/min helps to remove stubborn

wrinkles easily.

Calc Clean Function

This function ﬂush scale particles out of the iron, hence iron

enjoy longer life.

GC2510

2-5

DISASSEMBLY ADVICE

BACKPLATE 17

CORDSET 20

Remove screw A

Disassemble BACKPLATE 17

Remove screws B1, B2

Remove cord clamp

Disconnect 3x quick-connectors of CORDSET 20

Disassemble CORDSET 20

LAMP ASSY 6

DOSING ASSY 22

SUB INLAY CAP 27

SUB INLAY ASSY 16

INLAY 15

Disconnect 2x quick-connectors of LAMP ASSY 6

Disassemble LAMP ASSY 6

Remove DOSING ASSY 22

Remove screw C1

Remove SUB INLAY CAP 27

Remove screw C2

Disassemble SUB INLAY ASSY 16

Release rear catch of INLAY 15

Disassemble INLAY 15

SOS KNOB 13

SPRAY KNOB 14

PUMP ASSY (SOS) 11

PUMP ASSY (SPRAY) 10

TANK SEAL 9

THERMOSTAT DIAL PRINTED 19

Disassemble SOS KNOB 13

Disassemble SPRAY KNOB 14

Disassemble PUMP ASSY (SOS) 11

Disassemble PUMP ASSY (SPRAY) 10

Disassemble TANK SEAL 9

Disassemble THERMOSTAT DIAL PRINTED 19

WATER TANK ASSY 7

PILOT LAMP COVER 5

THERMOSTAT BUSH 4

COVER 3

RYTON RING 2

DOSING SOS SEAL 12

SOLEPLATE ASSY 1

Remove screws D1, D2

Disassemble WATER TANK ASSY 7

Disassemble PILOT LAMP COVER 5

Disassemble THERMOSTAT BUSH 4

Remove screws E1, E2, E3

Disassemble COVER 3

Disassemble RYTON RING 2

Disassemble DOSING SOS SEAL 12

Disassemble SOLEPLATE ASSY 1

GC2510

3-5

REPAIR INSTRUCTIONS

- Due to the high wattage of the iron, only the specified cord set must be used.

- Should damage be observed on the CORDSET 20, it must be replaced.

Continued usage is not allowed.

- After the product has been repaired, it should function properly and has to meet the safety requirements & legal regulations as

laid down & officially established at this moment.

- The following tests are common checks that are conducted on a repaired product before it is returned to the consumer.

1. Soleplate temperature

Check that soleplate temperature is within IEC requirement.

Measure the temperature of the soleplate after the iron has reached steady state i.e connected to the mains for at least 15 minutes.

The table below shows the temperature requirement.

Marking

Soleplate temperature (Deg C)

Material, for example

Test-

point

Minimum Maximum Nominal + Tolerance

•(1 dot) 70 120 95 ± 25 Acetate, elastane, polyamide, polyproylene

•• (2 dots) 100 160 130 ± 30 Cupro, polyester, silk, triacetate, viscose, wool

••• (3 dots) 140 210 175 ± 35 Cotton, linen

2. Leakage current

Check that leakage current is within IEC requirement.

Measure leakage current between LIVE/NEUTRAL & EARTH.

IEC requirement is that at 230 V supply, the EARTH leakage current must be less than 0.75 mA.

3. Water leakage / Functionality

Check that there is no water leakage from any part of the product during operation.

Check that the functionality of the product (product dependent) eg. steaming, variable steam, SOS, ASO etc is working properly.

4. Loose part

Check that there are no loose parts eg. extra screw in the product that can cause short-circuit or product malfunction.

GC2510

4-5

PARTS LIST

RESISTOR

LAMP

FUSE

HEATING

UNIT

INPUT

THERMOSTAT

Pos Service code Description

4239 021 34520

4239 021 38760

4239 015 70150

4239 026 23350

4239 026 13220

4239 026 23430

4239 021 34200

4239 021 33880

4239 021 38720

4239 026 23510

4239 026 23490

4239 020 90560

4239 021 33830

4239 015 56440

4239 026 23410

4239 026 23420

4239 026 23370

4239 021 34720

4239 026 23440

4239 025 92070

4239 021 35540

4239 021 35560

4239 021 33970

4239 000 08850

4239 000 08380

4239 000 08660

4239 000 08550

4239 021 34740

4239 021 38700

4239 026 23990

4239 026 25260

Soleplate assy 230 V Ceralon

Soleplate m. a. 110 V

Ryton ring

Cover (non Drip-Stop)

Thermostat bush

Pilot lamp cover

Lamp assy

Water tank assy

Water tank assy 110 V

Plastic rattle spring

Tank seal

Pump assy (Spray)

1.2 cc Pump assy (SOS)

Dosing SOS seal

SOS knob

Spray knob

Inlay

Sub inlay assy

Backplate

Ball swivel

Thermostat dial printed ENG

Thermostat dial printed ITA/SPA/POR

Thermostat dial printed FRE/DUT

Cordset EU

Cordset UK

Cordset South Africa

Cordset 110 V

Dosing assy

Dosing assy 110 V

Aesthetic cover

Sub inlay cap

= changed

GC2510

5-5

EXPLODED VIEW

E2 E3
