Perlesmith PSSS3 Manual de usuario

Thank you for choosing our product! We strive to provide the best quality and

services for our customers. Would you kindly share your experience on Amazon if

you are satisﬁed? Should you have any issues, please don't hesitate to contact us.

Telephone：800-5566-806 Mon-Fri 10am - 6pm (PST) (USA) (CAN)

Email：[email protected] (US/CA/DE/UK/FR/IT/ES/JP/AU)

PSSS3

V1.0

SPEAKER FLOOR STAND

WARNING! SEVERE PERSONAL INJURY AND PROPERTY DAMAGE CAN RESULT FROM

IMPROPER INSTALLATION OR ASSEMBLY. READ THE FOLLOWING WARNINGS BEFORE

BEGINNING.

If you do not understand the instructions or have any concerns or questions, please contact us at

[email protected] or a qualiﬁed installer.

Do not install or assemble if the product or hardware is damaged or missing. Not all parts and

hardware included will be used. If you require replacement parts, please contact us at

[email protected].

This product may contain moving parts. Use with caution.

Please check www.perlesmith.com for more products and company information.

WARNING！

Screwdriver

TOOLS NEEDED (NOT INCLUDED)

x 2

Base

Post assembly

x 2

Post extension

Small Plate

x 2

05 Medium Plate

x 2 x 2

06 Large Plate 07

Vertical Plate

x 2

Velcro A and B

SUPPLIED PARTS

φ6.5

Washer

ABCEF

HARDWARE KIT

M6x12mm

Screw

1/4’’ x1/2’’ Plastic Nut M6

Nut

Screw

M5x15mm

x2 x2 x2 x2x2x2

STEP 1 Attach the Nails or Rubber Pads to the Base

Rotate and insert the rubber pads into the holes.

Used for carpet

Used for marble ﬂoors or wooden ﬂoors

Washer

M4x16mm

Wood Screw

φ4.7

Washer

x2 x6 x6 x6

G H J KI M N

Nail Nut Pad #6-32x1-1/4

Screw

Nut

x2 x2 x2 x2

STEP 2A Fasten the Post Extension to the Post Assembly

STEP 2B

Fasten the Post assembly to the base

Secure Speaker to Stand

STEP 2C

STEP 3

Adjust the Post Assembly to the Desired Height

Speaker option A1: Keyhole insert

1.Attach Vertical Plate [07] with the Screw M5x15 [A]

2. Thread plastic nut [C] to screw 1/4’’ x1/2’’ [B]

3. Insert screw [B] into the keyhole of the speaker

and fasten the plastic nut [C]

OPT

Lift Tighten

Loosen

Speaker Option A2: Keyhole Insert

Speaker Option A3: Wooden Shell

Speaker without Thread hole

OPT

Center line

D,L

E,M

F,N

Speaker Option B2: Speakers with Smooth Surface on the Bottom without Thread Holes

Speaker Option B1: Thread Holes Locate at the Bottom of the Speaker

Separate velcro

A and B [08],

remove the

paper.

Stick the vercro A and B [08] on

the square plate [04] or [05] or

[06] and the bottom of the

speaker.

Cut the over length

velcro if necessary.

Attach the speaker

to the plate [04] or

[05] or [06] .

OPT

Special screws

(Not included in

the hardware kit)

04 05 06

OPT

or or



STEP 4 Route the cables

Cable comes out from the base 01
